Sabha 2000
| Name | No | Yard No | Builder | Laid down | Launched | Comm | Fate |
| صبحى [Sabha] (ex-Jack Williams) | 90 | 379 | General Dynamics Bath Iron Works, USA | 25.2.1980 | 30.8.1980 | 19.9.1981 // 13.9.1996 | in service (2020) |
|
Displacement standard, t |
2769 |
|
Displacement full, t |
3658 |
|
Length, m |
125.9 wl 135.6 oa |
|
Breadth, m |
13.7 |
|
Draught, m |
5.80 mean 6.70 max |
|
No of shafts |
1 |
|
Machinery |
2 General Electric LM-2500 gas turbines |
|
Power, h. p. |
41000 |
|
Max speed, kts |
29 |
|
Fuel, t |
gas turbine oil 587 |
| Endurance, nm(kts) | 4200(20) |
|
Armament |
1 x 1 Harpoon SSM / Standard SM-1MR SAM (4 RGM-84 + 36 RIM-66), 1 x 1 - 76/62 Mk 75, 1 x 6 - 20/76 Mk 15 Phalanx CIWS, 4 x 1 - 12.7/90, 2 x 3 - 324 Mk 32 TT, 2 helicopters (AS.365F Dauphin) |
|
Electronic equipment |
SPS-55, SPS-49(v)4, Mk 92 Mod.4, SPG-60, Mk 90 radars, SQQ-89(v)2 sonar suite (SQS-56 hull-mounted sonar + SQR-18A towed array), SLQ-32(v)2 ECM suite, 2x Mk 36 SRBOC decoy RL, SLQ-25 Nixie torpedo decoy, NTDS CCS |
|
Complement |
215 |
Project history: Former USN Oliver H. Perry-class frigate.
Modernizations: None.
Naval service: No significant events.
Sabha 2003
