I 1875
|
Names |
I (Yard no 32) |
|
Builders |
Thornycroft, Chiswick, UK: I |
|
Completed |
1875: I |
|
Losses |
none |
|
Transfers |
none |
|
Discarding |
1907: I |
|
Displacement normal, t |
8 |
|
Displacement full, t |
10 |
|
Length, m |
20.7 |
|
Breadth, m |
2.61 |
|
Draught, m |
1.23 |
|
No of shafts |
1 |
|
Machinery |
1 VSE, 1 locomotive boiler |
|
Power, h. p. |
184 |
|
Max speed, kts |
18 |
|
Fuel, t |
coal |
|
Endurance, nm(kts) |
|
|
Armament |
2 spar torpedoes |
|
Complement |
9 |
Project history: Thornycroft-built prototype, launched 19.6.1875. In service the boat reached only 13kts at 90hp.
Modernizations: 1893: - spar torpedoes; + light gun
Naval service: In 1893 Torpedoboot I was transferred to Danube Flotilla to serve as patrol boat.
I 1900
