World navies yesterday

2010



United Kingdom 01 January 2010

SUBMARINES

SSBN Vanguard 4 S28 Vanguard 1993 14000/15850t, 149.3x12.8x10.1m, 1nr,2gst(1wj), 27500hp, /25kts, 143p, 230m; 16 Trident D-5 SLBM(16), 4-533TT; type 1007 radar, type 2054(type 2043, type 2044, type 2045)(30,31), type 2054(type 2043, type 2046, type 2081, type 2082)(28,29) sonar suite, UAC(3), UAP(3) ECM, 3x SSE Mk 10 dl, SAFS 3(30,31), DCC(BN)(30,31), SMCS NG(28,29), DCM4(28,29) CCS
S29 Victorious 1995
S30 Vigilant 1996
S31 Vengeance 1999
SSN Swiftsure 1 S104 Sceptre 1978 4200/4900t, 82.9x9.8x8.3m, 1nr,2gst(1), 15000hp, 20/28kts, 97p, 300m; 5-533TT(inc Sub-Harpoon SSM(4)); type 1007 radar, type 2007, type 2046, type 2072, type 2074, type 2077, type 2082 sonars, UAP ECM, SAWCS dl, type 2066, type 2071 td, DCB/DCG CCS
Trafalgar 6 S87 Turbulent 1984 4740/5208t, 85.4x9.8x8.3m, 1nr,2gst(1wj), 15000hp, 20/30kts, 97p, 300m;  5-533TT(inc Tomahawk CruM(4), Sub-Harpoon SSM(4)); type 1007 radar, type 2076 sonar suite(90-93), type 2007(87,88,92), type 2072(93), type 2019 PARIS(87,88), type 2026(87-89), type 2046(90-93), type 2027(87,88), type 2074(87,88), type 2082(90-93), BQS-15A(91) sonars, UAP(1) ECM, type 2071 dl, 2x SSE Mk8 dl, SMCS(87,88), SMCS NG(90-93) CCS
S88 Tireless 1985
S90 Torbay 1987
S91 Trenchant 1989
S92 Talent 1990
S93 Triumph 1991

AIRCRAFT CARRIERS

CVS Invincible 3 R05 Invincible 1980 20600t, 210.0x36.0x6.5m, 4gt(2), 112000hp, 28kts, 875p; 3x7-30/77(05,06), 3x6-20/76(07), 2x1-20/90(06,07), 18ac (Sea Harrier attackers, Sea King helicopters); type 996, type 1022, 2x type 1007, type 1008, 3x Goalkeeper(05,06), 3x Mk90(07) radars, type 2016 sonar, UAT(7)(05,07), UAT(8)(06), UAD/UAK(06), 4x DLH, 8x Sea Gnat dl, type 182 td, ADAWS 10 (05), ADIMP(06,07) CCS
R06 Illustrious 1982
R07 Ark Royal 1985
CVH Contender Bezant 1 A135 Argus 1982 28480t, 173.0x30.6x8.2m, 2dg,2em, 23400hp, 22kts, 108+137p; 2x1-20/90, 12hel(Sea King, Lynx, Gazelle); type 1006, type 1007, type 994 radars, UAN(1) ECM, 2x Shield dl, type 182 td

PRINCIPAL SURFACE COMBATANTS

DD Sheffield Batch 2 4 D89 Exeter 1980 4250t, 125.0x14.3x4.3m, COGOG:2gt/2gt(2), 54400/8200hp, 28kts, 253p; 1x2 Sea Dart SAM(22), 1x1-114/55, 2x6-20/76, 2x1-20/90(89,90,92), 4x1-20/90(91), 1hel(Lynx); type 1022, type 996, type 1007, type 1008, 2x type 909, 2x Mk 90 radars, type 162M, type 2050 sonars, UAA(2)(91,92), UAT(5)(89,90) ECM, 4x DLD(91,92), 2x Corvus(89,90) dl, 2x DEC laser dazzlers, 4x DLF(2) fd, type 182 td, ADAWS-7(91,92), ADAWS-7 Mod.1(89,90) CCS
D90 Southampton 1981
D92 Liverpool 1982
D91 Nottingham 1983
Sheffield Batch 3 4 D95 Manchester 1982 4775t, 141.1x14.9x4.2m, COGOG:2gt/2gt(2), 54400/10680hp, 29.5kts, 253p; 1x2 Sea Dart SAM(22), 1x1-114/55, 2x6-20/76, 2x1-20/90, 2x3-324TT, 1hel(Lynx); type 1022, type 996, type 1007, type 1008, 2x type 909, 2x Mk 90 radars, 2x Rademac 2100 e/o detectors, type 162M, type 2050 sonars, UAT(5) ECM, 4x DLB dl, 4x DLJ(2) fd, 2x DEC laser dazzlers, type 2070 td, ADAWS-8 CCS
D96 Gloucester 1985
D97 Edinburgh 1985
D98 York 1985
Daring 1 D32 Daring 2009 7450t, 152.4x21.2x5.5m, 2gtg+2dg,2em, 68000hp, 30kts, 190+45p; 2x4 Harpoon SSM(8), 6x8 Sea Viper SAM VLS(32 Aster-30, 16 Aster-15), 1x1-114/55, 2x1-30/75, 2x6-20/76, 1hel(Merlin); type 1045, type 1046, type 1008, 2x type 1047 radars, 2x EOGS 2500 e/o directors, type 2100 sonar, EWCP ECM, 4x DLH dl, type 2170 SSTD td, 2x DLF(3) fd, CMS-1 CCS
FF Cornwall 4 F99 Cornwall 1988 4850t, 148.1x14.8x5.4m, COGAG:2gt+2gt(2), 48220hp, 30kts, 232p; 2x4 Harpoon SSM(8), 2x6 Sea Wolf SAM(72), 1x1-114/55, 1x7-30/77, 2x1-30/75, 2x1-20/90(87), 2x3-324TT, 2hel(Lynx) or 1hel(Sea King); type 967M, type 968, 2x type 911, Goalkeeper, type 1006 radars, type 2016(99), type 2050(85-87), type 2031Z sonars, 2x GSA.8 e/o directors, UAT(5/6), UAD/UAK, ECM, 4x DLB dl, 4x DLF(2) fd, 2x DEC laser dazzlers, type 182 td, CACS5 CCS
F85 Cumberland 1989
F86 Campbeltown 1989
F87 Chatham 1990
Norfolk 13 F231 Argyll 1991 4300t, 133.0x16.1x4.3m, CODLAG:2gt+4dg,2em, 41540(229,231,232,234-236)-56300(237-239,78,79,81-83)hp, 28(229,231,232,234-236)-30(237-239,78,79,81-83)kts, 169p; 2x4 Harpoon SSM(8), 1x32 Sea Wolf SAM VLS(32), 1x1-114/55, 2x1-30/75, 2x1-20/90, 4-324TT, 1hel(Lynx)(78,79,231,235,236), 1hel(Merlin)(81-83,229,234,237-239); type 996(2), 2x type 911, type 1007, type 1008 radars, type 2050NE, type 2031Z(78,79,229,231,234-238), type 2087(81-83,239) sonars, GSA8 e/o director, UAT(5/6), UAD/UAK, 2x type 675(78,79,229,231,234-236), 2x type 695(81-83,237-239) ECM, 4x DLB(78,79,229,231,234-236), 4x DLH(81-83,237-239) dl, 2x DEC laser-dazzlers, 4x DLF(2) fd, type 182(78,79,229,231,234-236), type 2070(237,238), type 2170 SSTDS(81-83,239) td, SSCS DNA(1) CCS
F229 Lancaster 1992
F234 Iron Duke 1993
F235 Monmouth 1993
F236 Montrose 1994
F237 Westminster 1994
F238 Northumberland 1994
F239 Richmond 1995
F82 Somerset 1996
F81 Sutherland 1997
F78 Kent 2000
F79 Portland 2001
F83 St. Albans 2002

PATROL AND COASTAL COMBATANTS

PS Castle 2 P258 Leeds Castle 1981 1550t, 81.0x11.5x3.4m, 2d, 5640hp, 20kts, 45p; 1x1-30/75, heldeck; type 994, type 1006 radars, UAN-1 ECM, 4x DLE dl, 2x DLF fd
P265 Dumbarton Castle 1982
Tyne 3 P281 Tyne 2003 1800t, 79.8x13.6x4.2m, 2d, 11280hp, 20kts, 45+3p; 1x1-20/85; 2x Nucleus-3 5000 radars
P282 Severn 2003
P283 Mersey 2004
Clyde 1 P257 Clyde 2007 1850t, 81.5x13.6x4.2m, 2d, 11280hp, 20kts, 36+20p; 1x1-30/75, heldeck; Terma-Scanter 4100 radar
PB Archer 16 P163 Express 1988 49t, 20.8x5.8x1.8m, 2d, 1590(exc274,275)-2000(274,275)hp, 22.5(exc274,275)-25(274,275)kts, 5+13p; Decca 1216 radar
P164 Example 1986
P165 Explorer 1985
P167 Exploit 1988
P264 Archer 1985
P270 Biter 1985
P272 Smiter 1986
P273 Pursuer 1988
P274 Tracker 1998
P275 Raider 1998
P279 Blazer 1988
P280 Dasher 1988
P291 Puncher 1988
P292 Charger 1988
P293 Ranger 1988
P294 Trumpeter 1988
Grey Fox 2 P284 Scimitar 1988 no picture 24t, 16.0x4.4x1.2m, 2d, 740hp, 32kts, 5+30p; Bridgemaster 360 radar
P285 Sabre 1988

AMPHIBIOUS

LPH Ocean 1 L12 Ocean 1999 21758t, 203.4x36.1x6.7m, 2d, 23904hp, 19kts, 490p; 4x2-20/85, 3x6-20/76, 18ac(Sea King, Lynx helicopters); 4 LCVP Mk 5, 2 Griffon LCAC, 80vehicles, 500troops; type 1007, type 1008, type 996(2), 3x Mk 90 radars, UAT(4), 2x type 675 ECM, 8x DLJ(2) dl, 2x DLH dl, type 2170 td, ADAWS 2000 Mod. 1 CCS
LPD Albion 2 L14 Albion 2003 18500t, 176.0x28.9x7.2m, 4dg,2em, 16320hp, 18kts, 325p; 2x7-30/77, 2x1-20/85, 4hel(Merlin); 4 LCU Mk 10, 4 LCVP Mk 5, 70vehicles, 305troops; 2x type 1007, type 1008, type 996(2), 2x Goalkeeper radars, UAT(4) ECM, 8x DLJ(2) dl, type 2170 td, ADAWS 2000 Mod. 1 CCS
L15 Bulwark 2005
LSD Bay 4 L3006 Largs Bay 2006 16160t, 176.6x26.4x5.8m, 4dg,2em(2az), 9000hp, 18kts, 67p; heldeck; 1 LCU Mk 10, 36tanks, 356troops, 200t cargo; 2x radars
L3007 Lyme Bay 2007
L3008 Mounts Bay 2006
L3009 Cardigan Bay 2006
LC LCM(9) 3 L705   1965 no picture 176t, 27.5x6.8x1.6m, 2d, 624hp, 10kts, 6p; 2tanks
L709   1966
L711   1965
Arromanches 6 L107 Andalsnes 1984 no picture 290t, 33.3x8.3x1.5m, 2d, 660hp, 9.2kts, 6p; 100t cargo; Bridgemaster-E 180 radar
L109 Akyab 1984
L110 Aachen 1987
L111 Arezzo 1987
L105 Arromanches 1987
L113 Audemer 1987
LCVP Mk 4 11 LCVP8401, 8402, 8407, 8409, 8411-8413, 8619-8622   1985-1987 no picture 16t, 13.0x3.2x0.8m, 2d, 440hp, 20kts, 3p; 35troops; Raytheon radar
LCVP Mk 5 23 LCVP9473, 9673-9692, 9707, 9708   1996-2004 no picture 23t, 15.3x4.2x0.6m, 2d, 860hp, 25kts, 3p; 35troops; Raytheon 40 radar
LCU Mk 10 10 9730 LCU01 1999 no picture 240t, 29.8x7.4x1.5m, 2d, 1090hp, 12kts, 7p; 1tank; radar
9731 LCU02 1999
9732 LCU03 2003
9733 LCU04 2003
9734 LCU05 2004
9735 LCU06 2004
9736 LCU07 2004
9737 LCU08 2004
9738 LCU09 2005
9739 LCU10 2005

MINE WARFARE

MSO Hunt 8 M30 Ledbury 1981 725t, 60.0x9.9x2.2m, 2d, 1900hp, 17kts, 45p; 1x1-30/75, 2x Seafox USV, mechanical, acoustic, magnetic minesweeping gear, 2x FAST minesweeping drones(30); type 1006(4) radar, type 2193, Mil Cross sonars, 2x DLJ(2) fd, 2x DLK dl, NAUTIS III CCS
M31 Cattistock 1982
M33 Brocklesby 1983
M34 Middleton 1984
M37 Chiddingfold 1984
M38 Atherstone 1987
M39 Hurworth 1985
M41 Quorn 1989
MSC Sandown 8 M104 Walney 1993 484t, 52.5x10.5x2.3m, 2d(2vs), 2024hp, 15kts, 34p; 1x1-30/75, 1x Seafox C USV; type 1007 radar, type 2093 sonar, NAUTIS-3 CCS
M106 Penzance 1998
M107 Pembroke 2000
M108 Grimsby 1999
M109 Bangor 2000
M110 Ramsey 2001
M111 Blyth 2001
M112 Shoreham 2002

AIRCRAFT



NAVY

Ship-based

 13 Harrier GR.8/9A, 2 Harrier T.10, 71 Lynx HAS.3/HMA.8, 42 Merlin HM.1, 15 Sea King HAS.5, 13 Sea King AEW.7

Land-based combat capable

 12 Hawk T.1
Royal Marines ship-based 6 Lynx AH.7, 37 Sea King HC.4

ARMY

Combat capable

66 AH-64D Apache WAH.1, 133 SA-341 Gazelle, 77 Lynx AH.7, 22 Lynx AH.9

AIR FORCE

Combat capable

13 Typhoon F.2, 15 Typhoon T.1/1A, 12 Tornado F.3, 28 Typhoon FGR.4, 2 Typhoon T.3, 113 Tornado GR.4, 55 Harrier GR.7/7A/9/9A, 24 Tornado GR.4A, 5 Sentinel RMK.1, 4 Shadow R.1, 11 Nimrod MR.2, 3 Nimrod R.1, 7 E-3D Sentry, 117 Hawk T.1/1A/1W, 6 Hawk 128, 9 Harrier T.10/12, 3 MQ-9 Predator B

MARINES

equipment 150 BvS-10 Viking APC, 81mm mortars, Milan ATGW, HVM SP SAM, 4 MAMBA radars
