World navies yesterday

2000



Spain 01 January 2000

SUBMARINES

SS Delfín 4 S61 Delfín 1973 869/1069t, 57.8x6.8x5.3m, 2dg,2em, 1300/1600hp, 13.2/15.5kts, 47p, 300m; 12-533TT; DRUA-33 radar, DUUA-2A, DSUV-22, DSUV-62C(63) sonars, Manta-E ECM
S62 Tonina 1973
S63 Marsopa 1975
S64 Narval 1975
Galerna 4 S71 Galerna 1983 1490/1750t, 67.9x6.8x5.4m, 2dg,1em, 3600/4600hp, 12/20.5kts, 54p, 300m; 4-533TT; DRUA-33C radar, DUUA-2A/B, DSUV-22, DUUX-2A(71,73), DUUX-5(72,74), DSUV-62(73) sonars, (73), Manta-E(71,72,74), ACRUX(71,72,74) ECM
S72 Siroco 1983
S73 Mistral 1985
S74 Tramontana 1986

AIRCRAFT CARRIERS

CVL Príncipe de Asturias 1 R11 Príncipe de Asturias 1988 17188t, 195.1x30.0x6.7m, 2gt(1), 46400hp, 26kts, 763p; 4x12-20/120, 17aircraft(8 AV-8B, 8 SH-3D, 4 AB-212, 1 SH-3D AEW); Raycass 5, SPS-55, SPS-52D, SPN-35A, RAN-12L/X, 4x VPS-2 radars, Nettunel, Deneb ECM, 6x Mk 36 SRBOC dl, SLQ-25 td, NTDS CCS

PRINCIPAL SURFACE COMBATANTS

FF Baleares 5 F71 Baleares 1973 4177t, 133.6x14.3x4.6m, 2b,1gst, 35000hp, 28kts, 256p; 2x4 Harpoon SSM(8), 1x1 Standard SM-1MR SAM(16), 1x8 ASROC ASuR(16), 1x1-127/54, 2x12-20/120, 2x1-12.7, 4-324TT; SPS-10, SPS-52B, SPG-51C, SPG-53B, Decca 1226, RAN-12L/X, 2x VPS-2 radars, DE1160C, SQS-35A sonars, Deneb Mk 1500/1600 ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, Tritan-1 CCS
F72 Andalucía 1974
F73 Cataluña 1975
F74 Asturias 1975
F75 Extremadura 1976
O. H. Perry 6 F81 Santa María 1986 4017(81-84)-4107(85,86)t, 138.8x14.3x4.5m, 2gt(1), 41000hp, 29kts, 223p; 1x1 Harpoon SSM(8)/Standard SM-1MR SAM(32), 1x1-76/62, 1x12-20/120, 2x3-324TT, 2helicopters (SH-60B); Raytheon 1650/9xR, SPS-55, SPS-49(v)4(81-84), SPS-49(v)5(85,86), SPS-67(81-84), Raycass(85,86), Mk 92 mod.2(81-84), Mk 92 mod.6(85,86), STIR Mk 54 mod.0, RAN-12L/X, VPS-2 radars, Enosa(85,86) e/o, DE1160B, SQR-19(v) TASS sonars, Elnath, Rigel(81-83), Nettunel Mk 3000(84-86) ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, NTDS(81-84), SYS-2(85,86) CCS
F82 Victoria 1987
F83 Numancia 1988
F84 Reina Sofía 1990
F85 Navarra 1994
F86 Canarias 1994
FS Descubierta 6 F31 Descubierta 1978 1640t, 88.9x10.4x4.0m, 4d(2), 18000hp, 26kts, 118+30p; 2x4 Harpoon SSM(8), 1x8 Albatros SAM(24), 1x1-76/62, 2x1-40/70, 2x3-324TT, 1x2-375 Bofors ASWRL; DA-05/2, ZW-06/2, WM22/41(31,32), WM25(33-36), Furuno radars, DE1160C sonar, Deneb Mk Mk 1600, Canopus Mk 1600 ECM, 2x Mk 36 dl, SLQ-25 td, Tritan IV CCS
F32 Diana 1979
F33 Infanta Elena 1980
F34 Infanta Cristina 1980
F35 Cazadora 1981
F36 Vencedora 1982

PATROL AND COASTAL COMBATANTS

PSO Chilreu 1 P61 Chilreu 1988 2100t, 67.8x11.0x4.7m, 1d, 2460hp, 15kts, 34p; 2x1-12.7; 2x Selesmar radars
Alborán 1 P62 Alborán 1997 2000t, 65.9x10.5x4.4m, 1d, 3000hp, 15kts, 32+22p; 2x1-12.7, heldeck; FAR-2825, FR-2130S radars
PS Serviola 4 P71 Serviola 1991 1150t, 68.7x10.4x3.4m, 2d, 7500hp, 20kts, 42p; 1x1-76/50, 2x1-12.7, heldeck; Decca 2459, Decca 2690 radars, Alcor-C(71,73), MSP4000(72,74) e/o, ULQ-13(71) ECM, Hispani Mini CCS
P72 Centinela 1991
P73 Vigía 1992
P74 Atalaya 1992
PC Anaga 10 P21 Anaga 1980 350t, 44.4x6.6x2.6m, 1d, 4500hp, 20kts, 25p; 1x1-76/50, 1x1-20/70; 2x Decca 1226 radars
P22 Tagomago 1981
P23 Marola 1981
P24 Mouro 1981
P25 Grosa 1981
P26 Medas 1981
P27 Ízaro 1981
P28 Tabarca 1981
P29 Deva 1982
P30 Bergantín 1982
PB Cabo Fradera 1 P201 Cabo Fradera 1963 no picture 28t, 17.8x4.2x0.8m, 2d, 280hp, 10kts, 9p
Barceló 6 P11 Barceló 1976 134t, 43.2x5.8x1.8m, 2d, 7320hp, 36.5kts, 19p; 1x1-40/70, 1x1-20/90, 2x1-12.7; Raytheon 1620 radar, CSEE e/o
P12 Laya 1976
P13 Javier Quiroga 1977
P14 Ordóñez 1977
P15 Acevedo 1977
P16 Cándido Pérez 1977
PVC11 2 P101, 114   1978-1979 no picture 22t, 15.9x4.4x1.3m, 2d, 1024hp, 27kts, 7p; 1x1-12.7; Decca 110 radar
Conejera 4 P31 Conejera 1981 85t, 32.2x5.3x1.4m, 2d, 2800hp, 25kts, 12p; 1x1-20/70; Furuno radar
P32 Dragonera 1981
P33 Espalmador 1982
P34 Alcanada 1982
Toralla 2 P81 Toralla 1987 no picture 78t, 28.5x6.5x1.5m, 2d, 2200hp, 20kts, 13p; 1x1-12.7; Decca 1070, Koden radars
P82 Formentor 1989

AMPHIBIOUS

LPD Galicia 1 L51 Galicia 1998 13800t, 163.1x25.0x5.2m, 4d(2), 21800hp, 20kts, 116p; 2x1-20/90, 6 helicopters (6 AB-212 or 4 SH-3); 4 LCM or 2 LCAC, 33 tanks, 543troops; 2x Kelvin Hughes, VPS-2 radars, Aldebaran ECM, 4x Mk 36 SRBOC dl, SLQ-25 td
LST Newport 2 L41 Hernán Cortés 1972 8550t, 171.3x21.2x5.3m, 6d(2), 16500hp, 22kts, 255p; 2x1-20/90, 1x6-20/76, 4x1-12.7, heldeck; 2 LCVP, 2 LCP, 29tanks, 431troops; LN-66, SPS-10F radars, Deneb ECM
L42 Pizarro 1972
LPA Paul Revere 1 L22 Aragón 1954 16838t, 172.0x23.2x7.9m, 2b,1gst, 22000hp, 22kts, 307p; 4x2-76/50, heldeck; 1657troops, 1900t cargo, 7 LCM(6), 5 LCVP, 3 LCP(L); SPS-40, SPS-10, 4x SPG-34 radars, WLR-1, ULQ-6 ECM, 4x Mk 36 SRBOC dl
LSS LCU1466 2 L71   1953 347t, 35.1x10.4x1.6m, 3d, 675hp, 8kts, 6p; 2x1-20/70; 4tanks
L72   1953
LC LCVP 14 1-14   1943-1945 13t, 11.2x3.2x0.9m, 2d, 220hp, 8kts, 3p; 2x1-12.7; 36troops
E81 8 L81   1975 116t, 22.4x6.4x1.8m, 2d, 600hp, 10kts, 5p; 54t cargo
L82   1975
L83   1975
L84   1975
L85   1975
L86   1975
L87   1988
L88   1988
L601 16 L161-167, 261-267, 601, 602   1984-1989 56t, 17.1x4.4x1.5m, 2d, 330hp, 10.2kts, 3p; 80troops
LCVP Mk 7(E) 4 1-4   1987 12t

MINE WARFARE

MSO Aggressive 2 M42 Guadalmedina 1954 735t, 52.3x10.4x4.0m, 4d(2), 2280hp, 14kts, 70p; 1x1-20/70, 2x1-12.7, Pluto USV, acoustic, magnetic, mechanical minesweeping gear; RM1226, TM626 radars, SQQ-14 sonar
M43 Guadalquivir 1956
Segura 2 M31 Segura 1999 550t, 54.0x10.7x2.2m, 2d(2vs), 1525hp, 14kts, 41p; 1x1-20/90, 2 Pluto Plus USV; type 1007 radar, Alcor-C e/o, SQQ-32(SP) sonar, SMYC/CM CCS
M32 Sella 1999
MSC Adjutant 6 M21 Júcar 1956 400t, 44.3x8.1x2.1m, 2d, 880(21,22,27)-1000(24-26)hp, 12(21,22,27)-12.5(24-26)kts, 39p; 1x2-20/70, acoustic, magnetic, mechanical minesweeping gear; RM914 radar, UQS-1 sonar
M22 Ebro 1958
M24 Tajo 1959
M25 Genil 1959
M26 Odiel 1959
M27 Sil 1955

GUARDIA CIVIL

PB L01 12 L01-12   1991-1995 no picture 14t, 11.9x3.8x0.7m, 2d, 1360hp, 38kts, 4p; Ericsson radar
M01 14 M01-14   1991-1996 no picture 18t, 16.5x3.8x0.7m, 2d((2wj), 1360hp, 40kts, 4p; 1x1-12.7; Ericsson radar
Salema 1 A01 Salema 1999 no picture 52t, 22.2x6.0x1.8m, 2d, 1100hp, 20kts, 8p; 1x1-12.7; radar
Tinecheyde 2 M15 Tinecheyde 1999 no picture 19t, 17.4x3.8x0.8m, 2d(2wj), 200hp, 40kts, 5p; 1x1-12.7; Ericsson radar
M16 Almirante Díz Pimienta 1999

CUSTOMS

PS Cóndor III 1 1 Cóndor III 1975 no picture 1600t, 59.8x11.3x4.3m, 2d, 2700hp, 14kts, 12p; 2x radars
Petrel 1 1 Petrel 1993 no picture 1600t, 72.5x12.0xm, d, 3500hp, 14kts, 19p; heldeck; 2x radars
PB VC1 1 1 Albatros III 1958 80t, 31.8x4.7x1.7m, 2d, 2700hp, 28kts, 15p; 1x1-20/70; radar
Aguilcho 4 1 Gavilán I 1975 no picture 65t, 28.0x5.2x1.3m, 2d, 2750(1,2)-3920(3-5)hp, 30(1,2)-24(3-5)kts, 14p; 1x1-20/70(1,2), 1x1-12.7(3-5); radar(1,2), MRD38(3-5), BX-3532R(3-5) radars
2 Gavilán II 1976
3 Gavilán III 1983
4 Gavilán IV 1987
Águila 1 1 Águila 1974 no picture 80t, 32.0x5.8x1.6m, 2d, 2750hp, 29kts, 16p; 1x1-20/70; RM926 radar
Cárabo 1 1 Cárabo 1978 no picture 60t, 24.4x5.2xm, 2d, 1350hp, 17kts
Halcón II 2 1 Halcón II 1980 no picture 70t, 25.2x6.1xm, 2d, 3200hp, 28kts; 1x1-12.7; MRD38, BX-3532R radars
2 Halcón III 1983
Alcaraván I 5 1 Alcaraván I 1984 no picture 85t, 28.5x6.5x1.8m, 2d, 3750(1)-3920(2-5)hp, 28kts, 14p; 1x1-12.7; MRD38, BX-3532R radars
2 Alcaraván II 1984
3 Alcaraván III 1985
4 Alcaraván IV 1986
5 Alcaraván V 1987
VA II 4 1 VA II 1985 no picture 24t, 15.7x4.1x1.2m, 2d, 1400hp, 23kts; radar
2 VA III 1985
3 VA IV 1985
4 VA V 1985
HJ I 10 1 HJ I 1986 no picture 20t, 14.0x3.8x0.7m, 2d(2wj), 2000hp, 50kts, 5p; MTR-114 radar
2 HJ II 1986
3 HJ III 1986
4 HJ IV 1986
5 HJ V 1986
6 HJ VI 1986
7 HJ VII 1986
8 HK VIII 1987
9 HK IX 1987
10 HK X 1987
Alca I 2 1 Alca I 1989 no picture 24t, 17.0x4.7x0.8m, 2000hp, 35kts
2 Alca III 1989
Cormorán 1 1 Cormorán 1990 no picture 22t, 17.0x40x1.0m, 2d, 2800hp, 55kts, 5p; radar
Cóndor V 1 1 Cóndor V 1992 no picture 14.0x4.0xm, 1300hp, 35kts
Neblí I 1 1 Beblí I 1993 no picture 51t, 22.6x6.5x1.7m, 3d(2+2wj), 3830hp, 50kts; radar
HJ A 1 1 HJ A 1994 no picture 15t, 1980hp, 50kts
Alcaudon 2 1 Alcaudon 1998 no picture 19t, 2300hp, 55kts
2 Fenix 1999
Colimbo II 1 1 Colimbo II 1999 no picture 19t, 2300hp, 52kts
Milano II 1 1 Milano II 1999 no picture 15t, 2300hp, 50kts



AIRCRAFT



NAVY

Ship-based

 9 AV-8B, 8 AV-8B+, 8 SH-3H, 3 SH-3D AEW, 10 AB-212, 10 Hughes 500, 6 SH-60B

ARMY

Land-based combat capable

45 HA-15/HR-15

AIR FORCE

Combat capable

90 EF/A-18A/B, 35 F-5B, 42 Mirage F-1CE, 4 Mirage F-1BE, 19 Mirage F-1EE, 14 RF-4C, 2 P-3A, 5 P-3B, 6 C-212 recce, 2 C-212EW, 2 Cessna 560 Citation recce, 2 Falcon 20 EW

MARINES

equipment 16 M-60A3 MBT, 17 Scorpion lt tk, 16 LVTP-7 AAV, 4 BLR AFV, 12 M-56 105mm howitzers, 6 M109A 155mm SP howitzers, 24 TOW-2, 18 Dragon ATGW, C-90C 90mm RL, 12 Mistral SAM
