World navies yesterday

1995



Italy 01 January 1995

SUBMARINES

SS Toti 2 S506 Enrico Toti 1968 535/591t, 46.2x4.7x4.0m, 2dg,1em, 2200hp, 9.7/14kts, 26p, 180m; 4-533TT; BPS-704 radar, IPD-64, MD-64 sonars, ECM, IPD-64 CCS
S513 Enrico Dandolo 1968
Sauro 4 S518 Nazario Sauro 1980 1456/1641t, 63.9x6.8x5.7m, 3dg,1em, 3515hp, 11/19.3kts, 49p, 250m; 6-533TT(inc Sub-Harpoon SSM(4))(518,519,521), 6-533TT(520); BPS-704 radar, IIPD-70/S, MD1000S, Velox M5 sonars, BLD-727 Thetis ECM, BSN-716(v)1(518,519,521), SISU-1(520) CCS
S519 Carlo Fecia di Cossato 1979
S520 Leonardo da Vinci 1981
S521 Guglielmo Marconi 1982
Pelosi 2 S522 Salvatore Pelosi 1988 1476/1680t, 64.4x6.8x5.7m, 3dg,1em, 3515hp, 12/20kts, 50p, 300m; 6-533TT(inc Sub-Harpoon SSM(4)); BPS-704 radar, IPD-70/S, MD100S, Velox M5 sonars, BLD-727 Thetis ECM, BSN-716(v)2 CCS
S523 Giuliano Prini 1989
Longobardo 1 S524 Primo Longobardo 1993 1653/1862t, 66.4x6.8x6.0m, 3dg/1em, 3265hp, 12/20kts, 50p, 300m; 6-533TT(inc Sub-Harpoon SSM(4)); BPS-704 radar, IPD-70/S, MD100S, Velox M5 sonars, BLD-727 Thetis ECM, BSN-716(v)2 CCS

AIRCRAFT CARRIERS

CV Garibaldi 1 C551 Giuseppe Garibaldi 1985 13850t, 180.2x30.4x6.7m, 4gt(2), 80000hp, 29.5kts, 825p; 4x2 Teseo Mk 2 SSM(4), 2x8 Albatros SAM(48), 3x2-40/70, 2x3-324TT, 16 helicopters (16 SH-3); SPN-749(v)2, SPS-702, SPS-768, SPS-774, SPS-52C, 3x SPG-74, 3x SPG-75, SPN-728(v)1 radars, DE-1160 sonar, SLQ-732 Nettuno ECM, 2x SCLAR dl, SLQ-25 td, IPN-20 CCS

PRINCIPAL SURFACE COMBATANTS

CG Vittorio Veneto 1 C550 Vittorio Veneto 1969 8850t, 179.6x19.4x6.0m, 4b,2gst, 73000hp, 30.5kts, 550p; 4x1 Teseo Mk 2 SSM(4), 1x2 Standard SM-1ER SAM(40)/ASROC ASuR(20), 8x1-76/62, 3x2-40/70, 2x3-324TT, 9helicopters (9 AB-212 or 6 SH-3D); SPS-768, SPS-52, SPQ-2B, 2x SPG-55B, 4x RTN-10X, 2x SPG-74 radars, SQS-23 sonar, SADOC-1 CCS
DD Audace 2 D550 Ardito 1973 4400t, 136.6x14.4x4.6m, 4b,2gst, 73000hp, 33kts, 380p; 2x4 Teseo Mk 2 SSM(8), 1x1 Standard SM-1MR SAM(40), 1x8 Albatros SAM(16), 1x1-127/54, 4x1-76/62, 2x1-20/70, 2x3-324TT, 2helicopters (2 AB-212 or 1 SH-3D); SPS-768, SPS-774, SPS-52C, SPQ-2D, 2x SPG-51C, 3x SPG-76, SPN-748(550) radars, CWE-610 sonar, SLQ-732 Nettuno ECM, 2x SCLAR dl, SLQ-25 td, IPN-20 CCS
D551 Audace 1972
Luigi Durand de la Penne 2 D560 Luigi Durand de la Penne 1993 5400t, 147.7x16.1x5.1m, CODOG: 2gt/2d(2), 55000/12600hp, 32kts, 377p; 4x2 Teseo Mk 2 SSM(8), 1x1 Standard SM-1MR SAM(40), 1x8 Albatros SAM(16), 1x1-127/54, 3x1-76/62, 2x1-20/70, 2x3-324TT, 2 helicopters (2 AB-212 or 1 SH-3); SPN-748, SPN-703, SPS-702, SPS-774, SPS-768, SPS-52C, 2x SPG-51D, 3x SPG-76 radars, DE-1164, DE-1167 sonars, SLQ-732 Nettuno, SLQ-705 ECM, 2x Sagaie dl, SLQ-25 td, IPN-20 CCS
D561 Francesco Mimbelli 1993
FF Alpino 2 F580 Alpino 1968 2700t, 113.3x13.1x3.8m, CODAG:2gt+4d(2), 31800hp, 29kts, 263p; 6x1-76/62, 2x3-324TT, 1x1 Menon ASWRL, 2 helicopters (AB-212); SPS-12, SPN-748, RTN-30X, 3x RTN-10X radars, DE-1164, DE-1164VDS sonars, SLQ-747 ECM, 2x SCLAR dl
F581 Carabiniere 1968
Lupo 4 F564 Lupo 1977 2525t, 113.6x12.0x4.0m, CODOG: 2gt/2d, 50000/9900hp, 35.2kts, 184p; 4x2 Teseo Mk 2 SSM(8), 1x8 Sea Sparrow SAM(8), 1x1-127/54, 2x2-40/70, 2x3-324TT, 1 helicopter (AB-212); SPN-748, SPQ-2F, SPS-702, SPS-774, Mk 91 mod. 1, SPG-70, 2x SPG-74 radars, DE-1160B sonar, SLR-4 Newton, 2x SLQ-D ECM, 2x SCLAR dl, SLQ-25 td, SADOC-2 CCS
F565 Sagittario 1978
F566 Perseo 1980
F567 Orsa 1980
Maestrale 8 F570 Maestrale 1982 3200t, 122.7x12.9x4.1m, CODOG: 2gt/2d, 50000/11000hp, 32kts, 225p; 4x1 Teseo Mk 2 SSM(4), 1x8 Albatros SAM(24), 1x1-127/54, 2x2-40/70, 2-533TT, 2x3-324TT, 2 helicopters (AB-212); SPN-703, SPS-702, SPS-774, SPG-75, 2x SPG-74 radars, DE-1164 sonar suite, SLR-4 Newton, 2x SLQ-D ECM, 2x SCLAR(570,572-577), 2x Dagaie(571) dl, SLQ-25 td, SADOC-2 CCS
F571 Grecale 1983
F572 Libeccio 1983
F573 Scirocco 1983
F574 Aliseo 1983
F575 Euro 1984
F576 Espero 1985
F577 Zeffiro 1985
Artigliere 1 F582 Artigliere 1994 2525t, 113.2x12.0x3.8m, CODOG: 2gt/2d(2), 50000/10000hp, 35kts, 185p; 8x1 Teseo Mk 2 SSM, 1x8 Albatros SAM(8), 1x1-127/54, 2x2-40/70, 2x1-20/70, 1 helicopter (AB-212); SPS-774, SPQ-712, SPN-703, 2x SPG-70, 2x SPG-74 radars, SLQ-747 ECM, 2x SCLAR dl, SLQ-25 td, IPN-10 CCS
FS Minerva 8 F551 Minerva 1987 1285t, 86.6x10.5x3.2m, 2d, 11000hp, 25kts, 121p; 1x8 Albatros SAM(8), 1x1-76/62, 2x1-20/70, 2x3-324TT; SPN-728, SPS-774, SPG-76 radars, Pegaso NA-16 e/o, DE-1167 sonar, SLQ-747 ECM, 2x Super Barricade dl, SLQ-25 td, SADOC-2 CCS
F552 Urania 1987
F553 Danaide 1988
F554 Sfinge 1988
F555 Driade 1991
F556 Chimera 1991
F557 Fenice 1990
F558 Sibilla 1991

PATROL AND COASTAL COMBATANTS

PS Cassiopea 4 P401 Cassiopea 1989 1475t, 79.8x11.8x3.5m, 2d, 7900hp, 20kts, 60p; 1x1-76/62, 2x1-20/70, 1 helicopter (AB-212); SPN-748, SPS-702, SPG-70 radars
P402 Libra 1991
P403 Spica 1991
P404 Vega 1992
Aggressive 2 P5432 Sgombro 1957 735t, 52.3x10.4x4.0m, 2d, 1600hp, 14kts, 70p; 1x1-40/60; SPN-703, BX-732 radar
P5433 Squalo 1957
PHM Sparviero 6 P421 Nibbio 1980 63t, 23.0x7.0x1.5m, CODOG:1d(1)/1gt(1wj), 165/5000hp, 40kts, 10p; 2x1 Teseo Mk 2 SSM(2), 1x1-76/62; SPQ-701, RTN-10X radars
P422 Falcone 1982
P423 Astore 1983
P424 Grifone 1983
P425 Gheppio 1983
P426 Condor 1984
PC Adjutant 4 P495 Bambù 1956 400t, 44.3x8.1x2.1m, 2d, 1200hp, 13kts, 39p; 1x2-20/70; BX-732 or 3ST7/DG radar
P496 Mango 1956
P497 Mogano 1957
P498 Palma 1957

AMPHIBIOUS

LPD San Giorgio 2 L9892 San Giorgio 1988 7665t, 133.3x20.5x5.3m, 2d, 16800hp, 21kts, 170p; 1x1-76/62, 2x1-20/70, 2x1-12.7, 3-5 helicopters (3 CH-47 or 3 SH-3 or 5 AB-212); 3 LCM, 4 LCVP, 36 APC, 345troops; SPS-702, SPN-748, RTN-10X radars, 2x SCLAR dl
L9893 San Marco 1988
San Giusto 1 L9894 San Giusto 1994 7960t, 137.0x25.0x6.0m, 2d, 16800hp, 21kts, 198p; 1x1-76/62, 2x2-20/70, 2x1-12.7, 3-5 helicopters (3 CH-47 or 3 SH-3D or 5 AB-212); 3 LCM(MTM), 3 LCVP(MTP), 34 APC, 349troops; SPS-702, SPN-753, SPG-70 radars, SLQ-747, SLR-730 ECM, 2x SCLAR dl, SLQ-25 td, SADOC 2 CCS
LSS MZ-A 1 A5341   1942 239t, 47.0x6.5x1.0m, 3d, 450hp, 11kts, 13p; 65t cargo
LCT(2) 1 A5331 MOC1201 1942 460t, 48.8x9.5x1.6m, 3d, 1380hp, 11kts, 12p; 2x1-20/70; 250t cargo
LCT(3) 4 A5332 MOC1202 1942 640t, 58.5x9.5x1.7m, 2d, 1000hp, 10.5kts, 12p; 4x1-20/70; 5tanks
A5333 MOC1203 1942
A5334 MOC1204 1942
A5335 MOC1205 1942
LC LCM(3) 7 MTM550-556   1942-1945 52t, 15.3x4.3x1.4m, 2d, 330hp, 8kts, 4p; 2x1-12.7; 1tank
LCM(6) 9 MTM541-549   1943-1945 56t, 17.1x4.3x1.2m, 2d, 450hp, 9kts, 5p; 2x1-12.7; 1tank
LCVP 6 MTP9726, 9731, 9748-9751   1943-1956 13t, 11.2x3.2x0.9m, 2d, 220hp, 8kts, 3p; 2x1-12.7; 36troops
MDN94 20 MDN94-104, 108, 109, 114-120   1985-1994 no picture 14t, 13.1x3.8x0.7m, 2d, 700hp, 22kts, 3p; 45troops
MEN217 9 MEN217-222, 227, 228, 551   1987-1993 no picture 65t, 18.5x5.1x0.9m, 2d, 560hp, 9kts, 3p; 80troops

MINE WARFARE

MSO Aggressive 2 M5430 Salmone 1956 735t, 52.3x10.4x4.0m, 2d, 1600hp, 14kts, 70p; 1x1-40/60, mechanical, magnetic, acoustic minesweeping gear; SPN-703, BX-732 radar, UQS-1 sonar
M5431 Storione 1956
Lerici 4 M5550 Lerici 1985 572t, 50.0x9.6x2.6m, 1d, 1840hp, 15kts, 48p; 1x1-20/70, MIN-77 USV, Pluto USV, mechanical minesweeping gear, decompression chamber; SPN-703 radar, SQQ-14IT sonar
M5551 Sapri 1985
M5552 Milazzo 1985
M5553 Vieste 1985
Gaeta 6 M5554 Gaeta 1992 696t, 52.5x9.9x2.8m, 1d, 1985hp, 15kts, 51p; 1x1-20/70, MIN Mk 2 USV, Pluto+ USV, mechanical minesweeping gear, decompression chamber; SPN-753, SPN-754 radars, SQQ-14T sonar
M5555 Termoli 1992
M5556 Alghero 1993
M5557 Numana 1993
M5558 Crotone 1994
M5559 Viareggio 1994
MSC Adjutant 3 M5504 Castagno 1955 400t, 44.3x8.1x2.1m, 2d, 1200hp, 13kts, 39p; 1x2-20/70, divers; BX-732 or 3ST7/DG radar, UQS-1 sonar
M5509 Gelso 1953
M5516 Platano 1954

COAST GUARD

PC Ingianni 1 CP409 Giulio Ingianni 1992 no picture 205t, 34.6x7.1x2.1m, 2d, 5820hp, 22kts, 13p; 1x1-20/70; Decca 20V90, Decca 2050/6 radars
PB CP226 2 CP226, 227   1963 no picture 15t, 13.1x4.8x1.5m, 2d, 740hp, 20kts
CP228 3 CP228-230   1965-1966 no picture 15t, 13.4x4.8x1.3m, 2d, 900hp, 24kts, 7p
CP231 8 CP231-238   1968-1970 no picture 16t, 13.4x4.8x1.3m, 2d, 900hp, 26kts, 7p; radar
Florillo 1 CP307 Michele Florillo 1968 no picture 85t, 26.7x5.6x1.6m, 3d, 2450hp, 24kts, 5p; radar
CP239 4 CP239, 241-243   1973-1974 no picture 24t, 16.8x5.0x1.7m, 2d, 1520hp, 28.6kts; radar
CP2006 4 CP2006-2009   1973-1974 no picture 11t, 12.5x3.6x1.1m, 2d, 540(2006,2007)-660(2008,2009)hp, 24kts, 4p
CP2010 8 CP2010-2017   1973-1975 no picture 11t, 12.5x3.6x1.1m, 2d, 470(2010,2011)-420(2012-2014)hp, 24kts, 4p
CP2024 1 CP2024   1973 no picture 15t, 13.7x3.8x1.3m, 2d, 700hp, 24kts, 4p
CP2018 6 CP2018-2023   1974-1975 no picture 10t, 12.5x3.6x1.1m, 2d, 570hp, 21kts, 4p
Gregoretti 1 CP312 Bruno Gregoretti 1975 no picture 65t, 23.2x5.3x1.4m, 3d, 1750hp, 20kts, 11p; radar
CP2025 7 CP2025-2031   1975-1976 no picture 10t, 12.5x3.6x1.0m, 2d, 570(2025)-660(2026-2031)hp, 22kts, 4p
CP2032 4 CP2032-2035   1975-1976 no picture 16t, 12.5x3.6x1.0m, 2d, 660(2032,2033,2035)-570(2034)hp, 22kts, 4p
CP244 1 CP244   1976 no picture 13.4x4.9xm, 2d, 1520hp; radar
CP245 1 CP245   1976 no picture 16.8x5.0xm, 2d, 1520hp; radar
CP2036 10 CP2036-2045   1976-1978 no picture 11t, 12.5x3.6x1.0m, 2d, 6660hp, 22kts, 4p
CP246 1 CP246   1977 no picture 10.0x4.9xm, 2d, 1520hp; radar
Novaro 1 CP313 Dante Novaro 1977 no picture 57t, 22.8x6.1x1.7m, 2d, 2760hp, 25kts, 11p; radar
CP2046 3 CP2046-2048   1978 no picture 12t, 12.5x3.6x1.1m, 2d, 660hp, 20kts, 4p
CP2049 17 CP2049-2065   1978-1979 no picture 12t, 12.6x3.6x1.1m, 2d, 690hp, 23kts, 4p
CP2066 3 CP2066-2068   1979-1980 no picture 13t, 12.6x3.6x1.1m, 2d, 690hp, 23kts, 4p
CP247 7 CP247-253   1980-1981 no picture 22t, 15.0x4.9x1.6m, 2d, 1380hp, 29.5kts, 7p; radar
CP2069 9 CP2069-2077   1980-1983 no picture 13t, 12.6x3.6x1.0m, 2d, 690hp, 23kts, 4p; radar
CP2078 6 CP2078-2083   1983-1991 no picture 13t, 12.6x3.6x1.2m, 2d, 690hp, 22.4kts, 4p; radar
CP254 4 CP254, 255, 259, 260   1984-1989 no picture 23t, 15.1x5.3x1.0m, 2d, 1500hp, 31kts, 7p; radar
CP256 3 CP256-258   1985 no picture 23t, 16.0x5.3x1.0m, 2d(2wj), 1700hp, 32kts, 7p; radar
CP2201 5 CP2201-2205   1986 no picture 15t, 12.6x3.6x1.2m, 2d, 20kts, 4p; radar
CP314 5 CP314-318   1988-1991 no picture 45t, 18.1x5.8x1.2m, 2d, 1700hp, 20kts, 7+20p; radar
Cavallari 4 CP401 Oreste Cavallari 1989 no picture 130t, 28.6x6.2x2.0m, 4d(2), 3520hp, 22kts, 11+50p; Decca, nav. radars
CP402 Renato Pennetti 1990
CP403 Walter Fachin 1990
CP404 Gaetano Magliano 1991
Mazzinghi 4 CP405 Francesco Mazzinghi 1991 no picture 136t, 29.5x6.7x1.8m, 4d(2), 5500hp, 22kts, 16+50p; Decca radar
CP406 Antonio Scialoja 1991
CP407 Michele Lolini 1991
CP408 Mario Grabar 1992

CUSTOMS

PC Zara 2 P01 Antonio Zara 1990 335t, 51.0x7.5x1.9m, 2d, 6600hp, 28kts, 32p; 1x2-30/82; SPN-748, SPN-751 radars, 2x CSDA-10 e/o, IPN-10 CCS
P02 Giuseppe Vizzari 1990
PB Gabriele 2 G70 Gabriele 1967 no picture 54t, 23.2x6.6x1.0m, 3d, 2500hp, 34.2kts, 11p; 1x1-12.7; SC-1210 radar
G71 Grasso 1967
Dark 1 G79 Laganà 1956 64t, 21.8x5.9x1.8m, 2d, 5000hp, 40kts, 15p; 1x1-20/70; radar
Meattini 57 G10 Meattini 1970 no picture 40t, 20.1x5.2x0.9m, 2d, 2500hp, 35.4kts, 11p; 1x1-12.7; SC-1210 radar
G11 Amici 1970
G12 Di Bartolo 1972
G13 RD36 1972
G14 Gori 1973
G15 Ramaci 1973
G16 Denaro 1973
G17 Bambace 1974
G18 Arcioni 1975
G19 Steri 1974
G20 Cotugno 1974
G21 Manoni 1974
G22 Giannotti 1975
G23 Carrrubba 1975
G24 Uglielmi 1975
G25 Salone 1975
G26 Esposito 1975
G27 Russo 1975
G28 Ruviani 1975
G29 Rando 1975
G30 Cicalese 1975
G31 Sessa 1975
G32 Coppola 1975
G33 Rizzi 1975
G34 D'Aleo 1975
G35 Baccile 1975
G36 Cavatorto 1975
G37 Fusco 1975
G38 De Turris 1975
G39 Chiaramida 1975
G40 Cavalieri d'Oro 1976
G41 Bianca 1976
G42 Nuvoletta 1976
G43 Preite 1976
G44 Mazzeo 1976
G45 Previti 1976
G46 Silanos 1976
G47 Ignesti 1976
G48 Barreca 1976
G49 Ciraulo 1976
G50 D'Agostino 1976
G51 Fiore 1975
G52 Nuziale 1975
G53 Tavano 1976
G54 De Alexandris 1978
G55 Stefanini 1977
G56 Tridenti 1977
G57 Fazio 1977
G58 Atzei 1977
G59 Cicalè 1977
G60 Fidone 1977
G61 Sguazzin 1977
G62 Tavormina 1978
G63 Colombina 1978
G64 Darida 1978
G65 Pizzighella 1978
G66 Sciuto 1978
V5800 34 V5800-5833   1979-1981 no picture 16t, 12.6x3.6x1.2m, 2d, 1000hp, 26kts, 5p; Furuno radar
Genna 1 G72 Genna 1980 no picture 120t, 32.2x7.2x3.1m, 3d, 2940hp, 35kts, 11p; 1x1-20/70; 2x FR-711 radars
Bigliani 2 G80 Bigliani 1987 no picture 85t, 26.4x7.0x1.1m, 2d, 7680hp, 45kts, 12p; 1x1-30/82; SPN-749, BX-3072A radars, Medusa Mk 1, SVIR e/o,
G81 Cavaglia 1987
V5000 2 V5000, 5100   1988-1992 no picture 27t, 16.5x4.6x1.2m, 2d(2wj), 2200hp, 52kts, 5p; BX-732 radar
Corrubia 2 G90 Corrubia 1990 no  picture 83t, 26.2x7.4x1.1m, 2d, 6400hp, 43kts, 13p; 1x1-30/82; GEMANT 2V1, SC-1410 radars, Medusa Mk 2, SVIR e/o
G91 Giudice 1991
Galiano 6 G82 Galiano 1991 no picture 85t, 27.0x7.0x1.2m, 2d, 7680hp, 43kts, 12p; 1x1-30/82; SPN-749, BX-3072A radars, Medusa Mk 1, SVIR e/o
G83 Macchi 1991
G84 Smalto 1991
G85 Fortuna 1992
G86 Buonocore 1992
G87 Squitieri 1992
V5001 8 V5001-5008   1993-1994 no picture 27t, 16.2x4.5x1.0m, 2d(2wj), 2500hp, 54kts, 5p; BX-732 radar



AIRCRAFT



NAVY

Ship-based

3 AV-8B Harrier II, 2 TAV-8B Harrier II, 30 SH-3D Sea King, 54 AB-212

ARMY

Land-based combat capable

3- SM-1019, 25 A-109, 17 A-129, 116 AB-206

AIR FORCE

Combat capable

91 Tornado, 140 F-104SA, 22 TF-104G, 65 AMX, 2 AMX-T, 15 G-91Y, 43 G-91T, 87 MB-339, 18 Atlantic, 1 G-222GE, 8 PD-808 ECM

CARABINIERI

Combat capable

24 A-109

PUBLIC SECURITY GUARD

Combat capable

12 A-109

FINANCE GUARDS

Combat capable

15 A-109, 38 NH-500C, 16 NH-500D, 12 NH-500M

MARINES

equipment 30 VCC-1, 10 LVTP-7 APC, 16 81mm mortars, 8 106mm RCL, 6 Milan ATGW
