World navies yesterday

1990



Japan 01 January 1990

SUBMARINES

SS Uzushio 5 ATSS8001 Isoshio 1972 1850/2430t, 72.0x9.9x7.5m, 2dg,2em(1), 3400/7200hp, 12/20kts, 80p, 200m; 6-533TT; ZPS-4(8001,569,570), ZPS-5(571,572) radar, ZQQ-2(8001,569,570), ZQQ-3(571,572), SQS-36(J)(571,572) sonars, ZLA-5 ECM
SS569 Narushio 1973
SS570 Kuroshio 1974
SS571 Takashio 1976
SS572 Yaeshio 1978
Yushio 10 SS573 Yushio 1980 2200/2450(573-576)-2250/2500(577-582)t, 76.2x9.9x7.4m, 2dg,2em(1), 3400/7220hp, 12/20kts, 80p, 300(573,574)-350(575-582)m; 6-533TT(inc Sub-Harpoon SSM(4))(574,576,577-582), 6-533TT(573,575); ZPS-6 radar, ZQQ-3, ZQR-1 sonars, ZLA-6 ECM, ZYQ-1 CCS
SS574 Mochishio 1981
SS575 Setoshio 1982
SS576 Okishio 1983
SS577 Nadashio 1984
SS578 Hamashio 1985
SS579 Akishio 1986
SS580 Takeshio 1987
SS581 Yukishio 1988
SS582 Sachishio 1989

PRINCIPAL SURFACE COMBATANTS

DD Ayanami 2 ASU7013 Oonami 1960 2500t, 109.0x10.7x3.7m, 2b,2gst, 35000hp, 32kts, 220p; 3x2-76/50, 1x4-533TT, 2-483TT(7013), 2x3-324TT(7014), 2x24 Hedgehog ASWRL, 2dct; OPS-1, OPS-15, SPG-34 radars, OQS-14 sonar, BLR-1 ECM
ASU7014 Makinami 1960
Akizuki 2 ASU7010 Akizuki 1960 2890t, 118.0x12.0x4.0m, 4b,2gst, 45000hp, 32kts, 330p; 2x1-127/54(7010), 3x1-127/54(3504), 2x2-76/50, 2x3-324TT, 1x4 type 71 ASWRL, 2x24 Hedgehog ASWRL, 2dct; OPS-1, OPS-15, SPG-34, SPG-35 radars, SQS-29, new towed(7010) sonar, BLR-1 ECM
TV3504 Teruzuki 1960
Amatsukaze 1 DDG163 Amatsukaze 1965 4000t, 131.0x13.4x4.2m, 2b,2gst, 60000hp, 33kts, 290p; 1x1 Standard SM-1MR SAM(40), 1x8 ASROC ASuR(8), 2x2-76/50, 2x3-324TT, 2x24 Hedgehog ASWRL; OPS-16, SPS-29A, SPS-52, 2x SPG-51C, SPG-34 radars, SQS-23 sonar, NOLR-6B, OLR-9B, OLT-3 ECM, 2x Mk 36 SRBOC dl
Yamagumo 6 DD113 Yamagumo 1966 2700t, 114.9x11.8x4.0m, 6d(2), 26500hp, 27kts, 210p; 1x8 ASROS ASuR(8), 2x2-76/50, 2x3-324TT, 1x4 type 71 ASWRL; OPS-11, OPS-17, SPG-34, SPG-35 radars, SQS-23(113-115), SQS-35(J)(113,114,120,121), OQS-3(119-121) sonars, NOLR-1B(113-115,119), NOLR-6(120,121) ECM
DD114 Makigumo 1966
DD115 Asagumo 1967
DD119 Aokumo 1972
DD120 Akigumo 1974
DD121 Yugumo 1978
Takatsuki 4 DD164 Takatsuki 1967 4500t, 136.0x13.4x4.4m, 2b,2gst, 60000hp, 32kts, 270p; 2x4 Harpoon SSM(8)(164,165), 1x8 Sea Sparrow SAM(16)(164,165), 1x8 ASROC ASuR(8), 1x1-127/54(164,165), 2x1-127/54(166,167), 1x6-20/76(165), 2x3-324TT, 1x4 type 71 ASWRL, 2 heldrones (DASH)(166,167); OPS-11B, OPS-17, SPG-35, FCS-2-12B(164,165), Mk 90(165) radars, OQS-3, SQS-35(J), OQR-1(164,165) sonars, NOLR-6C, OLT-3 ECM, 2x Mk 36 SRBOC dl(164,165), SLQ-25 td(164,165)
DD165 Kikuzuki 1968
DD166 Mochizuki 1969
DD167 Nagatsuki 1970
Minegumo 3 DD116 Minegumo 1968 2750t, 114.9x11.8x3.8m, 6d(2), 26500hp, 27kts, 205p; 1x8 ASROC ASuR(8), 1x1-76/62(118), 2x2-76/50(116,117), 1x1-76/50(118), 2x3-324TT, 1x4 type 71 ASWRL; OPS-11B, OPS-17, FC-2-12B(116,117), SPG-34(118) radars, OQS-3, SQS-35(J)(118) sonars, NOLR-5 ECM
DD117 Natsugumo 1969
DD118 Murakumo 1970
Haruna 2 DDH141 Haruna 1973 6300t, 153.0x17.5x5.1m, 2b,2gst, 70000hp, 32kts, 340p; 1x8 Sea Sparrow SAM(16), 1x8 ASROC ASuR(16), 2x1-127/54, 2x6-20/76, 2x3-324TT, 3 helicopters (HSS-2A); OPN-11, OPS-11C, FCS-2-12E, 2x Mk 90, 2x FCS-1A radars, OQS-3 sonar, NOLQ-1-3, OLR-9 ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, OYQ-6 CCS
DDH142 Hiei 1974
Tachikaze 3 DDG168 Tachikaze 1976 4800t, 143.0x14.3x4.6m, 2b,2gst, 70000hp, 32kts, 277p; 1x1 Harpoon SSM / Standard SM-1MR SAM(4+36), 1x8 ASROC ASuR(16), 2x1-127/54, 2x6-20/76, 2x3-324TT; OPS-16D(168), OPS-11(168,169), SPS-52B(168,169), SPS-52C(170), OPS-18(169), SPG-51C, FCS-1A(168,169), FCS-2-21(170), 2x Mk 90 radars, OQS-3(168,169), OQS-4(I)(170) sonar, NOLR-5(170), NOLR-6(168), NOLQ-1(169), OLR-9B, OLT-3(168) ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, OYQ-1B(168), OYQ-2(169), OYQ-4(170) CCS
DDG169 Asakaze 1979
DDG170 Sawakaze 1983
Shirane 2 DDH143 Shirane 1980 6800t, 158.8x17.5x5.3m, 2b,2gst, 70000hp, 32kts, 360p; 1x8 Sea Sparrow SAM(24), 1x8 ASROC ASuR(16), 2x1-127/54, 2x6-20/76(144), 2x3-324TT, 3 helicopters (HSS-2); OPN-8, OPS-12, OPS-28, WM-25, 2x FCS-1A, 2x Mk90(144) radars, OQS-101, SQS-35(J), SQR-18A sonars, NOLQ-1, OLR-9B ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, OYQ-3 CCS
DDH144 Kurama 1981
Hatsuyuki 12 DD122 Hatsuyuki 1982 3700(122-128)-3800(129-132)t, 131.7x13.7x4.1(122-128)-4.3(129-132)m, COGOG:2gt/2gt(2), 50000/10000hp, 30kts, 170p; 2x4 Harpoon SSM(8), 1x8 Sea Sparrow SAM(18)(122,123), 1x8 Sea Sparrow SAM(124-132), 1x1-76/62, 2x6-20/76(124-132), 2x3-324TT, 1 helicopter (HSS-2); OPS-18-1, OPS-14B, FCS-2-21A, FCS-2-12(122,123), FCS-2-12A(124-130), FCS-2-12C(131,132), 2x Mk 90(124-126) radars, OQS-4A sonar, NOLQ-6C, OLT-3 ECM, 2x Mk 36 SRBOC dl, type 3 td, OYQ-5(122-128), OYQ-6(129-132) CCS
DD123 Shirayuki 1983
DD124 Mineyuki 1984
DD125 Sawayuki 1984
DD126 Hamayuki 1983
DD127 Isoyuki 1985
DD128 Haruyuki 1985
DD129 Yamayuki 1985
DD130 Matsuyuki 1986
DD131 Setoyuki 1986
DD132 Asayuki 1987
DD133 Shimayuki 1987
Hatakaze 2 DDG171 Hatakaze 1986 5600t, 150.0x16.4x4.8m, COGAG:2gt+2gt(2), 72000hp, 30kts, 260p; 2x4 Harpoon SSM(8), 1x1 Standard SM-1MR SAM(40), 1x8 ASROC ASuR(8), 2x1-127/54, 2x6-20/76, 2x1-12.7, 2x3-324TT, heldeck; OPS-28B, OPS-11C, SPS-52C, 2x SPG-51C, 2x FCS-2-21C, 2x Mk 90 radars, OQS-4-1 sonar, NOLQ-1-3, OLR-9B ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, OYQ-4-1 CCS
DDG172 Shimakaze 1988
Asagiri 4 DD151 Asagiri 1988 4900t, 136.5x14.6x4.5m, COGAG:4gt(2), 54000hp, 30kts, 220p; 2x4 Harpoon SSM(8), 1x8 Sea Sparrow SAM(18), 1x8 ASROC ASuR(16), 1x1-76/62, 2x6-20/76, 2x3-324TT, 1helicopter (SH-60); OPS-14C, OPS-28C, OPS-20, FCS-2-12E, FCS-2-22A, 2x Mk 90 radars, OQS-4A sonar, NOLR-6C ECM, 2x Mk 36 SRBOC dl, SLQ-25 td, OYQ-7 CCS
DD152 Yamagiri 1989
DD153 Yugiri 1989
DD154 Amagiri 1989
FF Isuzu 4 ASU7015 Isuzu 1961 1700t, 97.0x10.4x3.5m, 4d(2)(7015,213,214)-2d(3505), 16000(7015,3505)-17000(213,214)hp, 26kts, 160p; 2x2-76/50, 1x4-533TT(7016,7017), 2x3-324TT, 1x4 type 71 ASWRL, 1dct(7015,214), 1dcr(7015,214); OPS-2, OPS-16, SPG-34 radars, SQS-11(7015,3505), OQS-12(213,214), SQR-4(7015,3505), OQY-2(213,214), SQA-4(7015,3505), OQA-1(213) sonars, NOLR-1 ECM
TV3505 Mogami 1961
DE213 Kitakami 1964
DE214 Ooi 1964
Chikugo 11 DE215 Chikugo 1971 1800t, 93.0x10.8x3.5m, 4d(2), 17000hp, 28kts, 160p; 1x8 ASROC ASuR(8), 1x2-76/50, 1x2-40/60, 2x3-324TT; OPS-14, OPS-16, FCS-1B radars, OQS-3A, SQS-35(J)(221-225) sonars, NOLR-1B(215-218), NOLR-5(219-225) ECM
DE216 Ayase 1971
DE217 Mikumo 1971
DE218 Tokachi 1972
DE219 Iwase 1972
DE220 Chitose 1973
DE221 Niyodo 1974
DE222 Teshio 1975
DE223 Yoshino 1975
DE224 Kumano 1975
DE225 Noshiro 1977
Ishikari 1 DE226 Ishikari 1981 1450t, 84.5x10.0x3.5m, CODOG:1gt/1d(2), 28390/5000hp, 25kts, 90p; 2x4 Harpoon SSM(8), 1x1-76/62, 2x3-324TT, 1x4 type 71 ASWRL; OPS-19B, OPS-28-1, FCS-2-21B radars, OQS-4 sonar, NOLQ-6B, OLT-3, OLR-9B ECM, 2x Mk 36 SRBOC dl, SLQ-25 td, OYQ-5 CCS
Yubari 2 DE227 Yubari 1983 1760t, 91.0x10.8x3.6m, CODOG:1gt/1d(2), 28390/5000hp, 25kts, 98p; 2x4 Harpoon SSM(8), 1x1-76/62, 2x3-324TT, 1x4 type 71 ASWRL; OPS-19B, OPS-28C, FCS-2-21B radars, OQS-4 sonar, NOLQ-6B, OLT-3, OLR-9B ECM, 2x Mk 36 SRBOC dl, SLQ-25 td, OYQ-5 CCS
DE228 Yubetsu 1984
Abukuma 1 DE229 Abukuma 1989 2550t, 109.0x13.4x3.8m, CODOG:2gt/2d(2), 27000/6000hp, 27kts, 120p; 2x4 Harpoon SSM(8), 1x8 ASROC ASuR(8), 1x1-76/62, 1x6-20/76, 2x3-324TT; OPS-14C, OPS-28D, FCS-2-21, Mk 90 radars, OQS-8 sonar, NOLQ-6C, OLT-3 ECM, 2x Mk 36 SRBOC dl, OYQ-6 CCS
FFT Katori 1 TV3501 Katori 1969 4100t, 127.5x15.0x4.3m, 2b,2gst, 20000hp, 25kts, 295+165p; 2x2-76/50, 2x3-324TT, 1x4 type 71 ASWRL, heldeck; SPS-12, OPS-17, SPG-34 radars, SQS-4 sonar, NOLR-1B ECM

PATROL AND COASTAL COMBATANTS

PT 11-go 5 PT811 11-go 1971 140t, 35.0x9.2x1.2m, CODAG: 2d+2gt(3), 10500(811)-11000(812-815)hp, 40kts, 28p; 2x1-40/60, 4-533TT; OPS-13 radar
PT812 12-go 1972
PT813 13-go 1972
PT814 14-go 1974
PT815 15-go 1975
PB 19-go 9 PB919-927 19-go-27-go 1971-1973 no picture 20t, 17.0x4.3x0.7m, 2d, 760hp, 20kts, 6p; 1x1-20/70, 1x1-12.7; OPS-29(920-927) radar

AMPHIBIOUS

LST Atsumi 3 LST4101 Atsumi 1972 2470t, 89.0x13.0x2.8m, 2d, 4400hp, 13kts, 100p; 2x2-40/60; 2 LCVP, 1 LCM, 20vehicles, 130troops; OPS-9 radar
LST4102 Motobu 1973
LST4103 Nemuro 1977
Miura 3 LST4151 Miura 1975 3200t, 98.0x14.0x3.0m, 2d, 4400hp, 14kts, 118p; 1x1-76/50, 1x2-40/60; 2 LCVP, 2 LCM(6), 10tanks, 200troops; OPS-18, OPS-14, FCS-1B(4151), Mk34(4152,4153) radars
LST4152 Ojika 1976
LST4153 Satsuma 1977
LSM Yura 2 LSU4171 Yura 1981 590t, 58.0x9.5x1.7m, 2d, 3000hp, 12kts, 32p; 1x3-20/76; 70troops, cargo; OPS-9B radar
LSU4172 Noto 1981
1-go 1 LC2001 1-go 1988 no picture 540t, 52.0x8.7x1.6m, 2d, 3000hp, 12kts, 28p; 1x3-20/76; 60troops, cargo; OPS-9B radar
LC YF2121 1 YF2121   1989 56t, 17.1x4.4x1.2m, 2d, 450hp, 10kts, 4p; 80troops

MINE WARFARE

ML Soya 1 MMC951 Soya 1971 3300t, 99.0x15.0x4.2m, 4d(2), 6400hp, 18kts, 180p; 1x2-76/50, 2x1-20/70, 2x3-324TT, 226mines, heldeck; OPS-14, OPS-17, FCS-1B radars, SQS-11A, ZQS-1B sonars
Hayase 1 MST462 Hayase 1971 3050t, 99.0x14.5x4.2m, 4d(2), 6400hp, 18kts, 180p; 1x2-76/50, 2x1-20/70, 2x3-324TT, 200mines, heldeck; OPS-14, OPS-17, SPG-34 radars, SQS-11A, ZQS-1B sonars
MSC Takami 19 YAS82 Takami 1969 425t, 52.0x8.8x2.4m, 2d, 1440hp, 14kts, 45p; 1x1-20/70, mechanical, magnetic, acoustic minesweeping gear(475,640-648), decompression chamber(82-90); OPS-9 radar, ZQS-2(475,640-648) sonar, drone control equipment(475)
YAS83 Iou 1970
YAS84 Miyake 1970
MST475 Utone 1970
YAS85 Awaji 1971
YAS86 Toushi 1971
YAS87 Teuri 1972
YAS88 Murotsu 1972
YAS89 Tashiro 1973
YAS90 Miyato 1973
MSC640 Takane 1974
MSC641 Muzuki 1974
MSC642 Yokose 1975
MSC643 Sakate 1975
MSC644 Oumi 1976
MSC645 Fukue 1976
MSC646 Okitsu 1977
MSC647 Hashira 1978
MSC648 Iwai 1978
Hatsushima 23 MSC649 Hatsushina 1979 520(649-669)-550(670,671)t, 55.0(649-669)-58.0(670,671)x9.4x2.5(649-669)-2.9(670,671)m, 2d, 1440(649-665)-1400(666-671)hp, 14kts, 45p; 1x3-20/76, S-4 USV, mechanical, magnetic, acoustic minesweeping gear; OPS-9 radar, ZQS-2B sonar
MSC650 Ninoshima 1979
MSC651 Miyajima 1980
MSC652 Enoshima 1980
MSC653 Ukishima 1980
MSC654 Oshima 1981
MSC655 Niijima 1981
MSC656 Yakushima 1982
MSC657 Narushima 1982
MSC658 Chichijima 1983
MSC659 Torishima 1983
MSC660 Hahajima 1984
MSC661 Takashima 1984
MSC662 Nuwajima 1985
MSC663 Etajima 1985
MSC664 Kamijima 1986
MSC665 Himejima 1986
MSC666 Ogishima 1986
MSC667 Moroshima 1986
MSC668 Yurishima 1988
MSC669 Hikojima 1988
MSC670 Awashima 1989
MSC671 Sakushima 1989
MSB 7-go 6 MSB707-712 7-go-12-go 1973-1975 58t, 22.5x5.4x1.0m, 2d, 480hp, 11kts, 10p; mechanical or acoustic minesweeping gear

MARITIME SAFETY AGENCY

WPSO Izu 2 PL31 Izu 1967 2081t, 95.5x11.6x3.8m, 4d(2), 12000hp, 24.6kts, 72p; 1x1-40/60; 2x radars
PL32 Miura 1969
Soya 1 PLH01 Soya 1978 4089t, 98.6x15.6x5.2m, 2d, 15600hp, 21kts, 71p; 1x1-40/60, 1x1-20/70, 1helicopter (Bell 212); 2x JMA1596, JMA1576 radars
Tsugaru 6 PLH02 Tsugaru 1979 4037t, 105.4x14.6x4.9m, 2d, 15600hp, 22kts, 71p; 1x1-40/60(02,03), 1x1-35/90(04-07), 1x1-20/70(02,05-07), 1 helicopter (Bell 212); JMA1596, JMA1576, hel.control radars
PLH03 Osumi 1979
PLH04 Uraga 1980
PLH05 Zao 1983
PLH06 Chikuzen 1983
PLH07 Settsu 1984
Mizuho 2 PLH21 Mizuho 1986 5300t, 130.0x15.5x5.3m, 2d, 18200hp, 23kts, 130p; 1x1-35/90, 1x3-20/76, 2helicopters (Bell 212); 2x JMA3000, JMA8303 radars
PLH22 Yashima 1988
WPS Nojima 1 PL12 Ojika 1963 1113t, 69.0x9.2x3.2m, 2d, 3000hp, 18.1kts, 73p; radar
Kojima 1 PL21 Kojima 1964 1201t, 69.6x10.3x3.2m, 1d, 2600hp, 17kts, 60+47p; 1x1-40/60, 1x1-20/70, 1x1-12.7; 2x radars
Erimo 2 PL13 Erimo 1965 1010t, 76.6x9.2x3.0m, 2d, 4800hp, 19.8kts, 72p; 1x1-76/50, 1x1-20/70; JMA1576, JMA1596 radars
PL14 Satsuma 1966
Daio 2 PL15 Daio 1973 1206t, 76.6x9.6x3.2m, 2d, 8120hp, 20.4kts, 45p; 1x1-40/60, 1x1-20/70; JMA1596, JMA1576 radars
PL16 Muroto 1974
Kunashiri 7 PM65 Kunashiri 1969 574t, 58.0x7.4x2.4m, 2d, 2600(65-68)-3000(70-72)hp, 17(65-68)-17.5(70-72)kts, 40p; 1x1-20/70; JMA1576, JMA1596 radars
PM66 Minabe 1970
PM67 Sarobetsu 1971
PM68 Kamishima 1972
PM70 Miyake 1973
PM71 Awaji 1973
PM72 Yaeyama 1972
Bihoro 20 PM73 Bihoro 1974 657t, 63.4x7.8x2.5m, 2d, 3000hp, 18kts, 34p; 1x1-20/70; 2x JMA159B radars
PM74 Kuma 1974
PM75 Fuji 1975
PM76 Kabashima 1975
PM77 Sado 1975
PM78 Ishikari 1976
PM79 Abakuma 1976
PM80 Isuzu 1976
PM81 Kikuchi 1976
PM82 Kuzuryu 1976
PM83 Horobetsu 1977
PM84 Shirakami 1977
PM85 Sagami 1976
PM86 Tone 1976
PM87 Yoshino 1977
PM88 Kurobe 1977
PM90 Chikuma 1978
PM91 Yamakuni 1978
PM92 Katsura 1978
PM93 Shinano 1978
Shiretoko 28 PL101 Shiretoko 1978 1360t, 77.8x9.6x3.4m, 2d, 7000hp, 20kts, 41p; 1x1-40/60(101-117,119-121,123), 1x1-35/90(118,122,124-128), 1x1-20/70(101-104); JMA1594, JMA1576 radars
PL102 Esan 1978
PL103 Wakasa 1978
PL104 Yahiko 1978
PL105 Motobu 1978
PL106 Rishiri 1979
PL107 Matsushima 1979
PL108 Iwaki 1979
PL109 Shikine 1979
PL110 Suruga 1979
PL111 Rebun 1979
PL112 Chokai 1979
PL113 Ashizuri 1979
PL114 Oki 1979
PL115 Noto 1979
PL116 Yonakuni 1979
PL117 Kudaka 1980
PL118 Shimokita 1980
PL119 Suzuka 1980
PL120 Kunisaki 1980
PL121 Genkai 1980
PL122 Goto 1980
PL123 Koshiki 1980
PL124 Hateruma 1980
PL125 Katori 1980
PL126 Kunigami 1980
PL127 Etomo 1982
PL128 Mashu 1982
Takatori 2 PM89 Takatori 1978 631t, 46.5x9.2x3.9m, 2d, 3000hp, 15.7kts, 34p; JMA1596, JMA1576 radars
PM94 Kumano 1979
Teshio 14 PM01 Teshio 1980 670(01-11,13,14)-692(12)t, 67.8x7.9x2.7m, 2d, 3000hp, 18kts, 33p; 1x3-20/76; 2x JMA159B radars
PM02 Oirase 1980
PM03 Echizen 1980
PM04 Tokachi 1981
PM05 Hitachi 1981
PM06 Okitsu 1981
PM07 Isazu 1982
PM08 Chitose 1982
PM09 Kuwano 1983
PM10 Sorachi 1984
PM11 Yubari 1985
PM12 Motoura 1986
PM13 Kano 1986
PM14 Sendai 1988
Nojima 1 PL01 Nojima 1989 1500t, 87.0x10.5x3.5m, 2d, 7000hp, 20kts, 39p; 1x3-20/76, heldeck; 2x JMA1596 radars
WPC Yahagi 1 PM69 Misasa 1970 377t, 50.3x7.3x2.2m, 2d, 1400hp, 15.5kts, 44p; 1x1-20/70; radar
Matsuura 3 PM62 Amami 1965 455t, 55.3x7.0x2.3m, 2d, 1800(62,63)-2600(64)hp, 16.8(62,63)-17(64)kts, 40p; 1x1-20/70; radar
PM63 Natori 1966
PM64 Karatsu 1967
WPB Hidaka 9 PS35 Rokko 1964 169t, 33.8x6.3x1.8m, 1d, 700hp, 13.5kts, 17p; 1x1-12.7; radar
PS36 Takanawa 1964
PS38 Kunimi 1965
PS39 Takatsuki 1965
PS41 Kamui 1966
PS43 Ashitaka 1967
PS44 Kurama 1967
PS45 Ibuki 1968
PS46 Toumi 1968
Matsuyuki 2 PC48 Hamagiri 1970 no picture 65t, 21.0x5.1x1.1m, 2d, 2200(52)-1140(48)hp, 14.6(48)-20(52)kts, 1x1-12.7; MD808 radar
PC52 Hamanami 1971
Bisan 1 PS48 Shiramine 1969 no picture 85t, 26.0x5.6x0.9m, 2d, 2200hp, 23kts, 14p; 1x1-12.7; MD808 radar
Choyokaze 95 CL50 Suzukaze 1969 no picture 24t, 15.0x4.1x0.9m, 2d, 500hp, 18.4kts, 6p; radar
CL51 Urakaze 1969
CL53 Sugikaze 1969
CL54 Fujikaze 1970
CL55 Miyakaze 1969
CL57 Chinukaze 1969
CL59 Nachikaze 1970
CL65 Tomakaze 1970
CL66 Hibakaze 1970
CL67 Yurikaze 1970
CL68 Sumikaze 1971
CL69 Kashima 1970
CL70 Takekaze 1971
CL71 Kinukaze 1971
CL72 Shigikaze 1971
CL73 Uzukaze 1971
CL74 Akikaze 1970
CL75 Setokaze 1970
CL76 Kurekaze 1971
CL77 Mojikaze 1971
CL78 Satakaze 1970
CL79 Kirikaze 1971
CL80 Kamikaze 1971
CL81 Umikaze 1971
CL82 Yumekaze 1971
CL83 Makikaze 1971
CL84 Hakaze 1971
CL85 Shachikaze 1971
CL86 Himekaze 1971
CL87 Isekaze 1971
CL88 Komakaze 1971
CL89 Kishikaze 1971
CL90 Mayakaze 1971
CL91 Kikukaze 1971
CL92 Hirokaze 1971
CL93 Kibikaze 1971
CL94 Ashikaze 1971
CL95 Otokaze 1971
CL96 Kurikaze 1971
CL97 Imakaze 1971
CL98 Terukaze 1972
CL100 Tokitsukaze 1972
CL101 Tsukikaze 1972
CL102 Awakaze 1972
CL103 Nomakaze 1972
CL104 Miokaze 1972
CL106 Kiikaze 1972
CL108 Tamatsukaze 1972
CL109 Miyokaze 1972
CL110 Ayakaze 1972
CL111 Mitsukaze 1972
CL112 Hatakaze 1972
CL113 Numakaze 1972
CL114 Soyokaze 1972
CL115 Minekaze 1972
CL116 Okitsukaze 1972
CL117 Deigo 1972
CL118 Yuuna 1972
CL119 Adan 1972
CL120 Horokaze 1973
CL121 Somakaze 1973
CL122 Hatsukaze 1973
CL123 Sasakaze 1973
CL124 Hagikaze 1973
CL125 Tonekaze 1973
CL126 Shizukaze 1973
CL127 Murokaze 1973
CL129 Yamakaze 1973
CL130 Hikokaze 1973
CL131 Takakaze 1973
CL132 Murakaze 1973
CL133 Nomokaze 1973
CL134 Kumokaze 1973
CL135 Yanakaze 1973
CL136 Yurakaze 1973
CL137 Washikaze 1973
CL138 Kushikaze 1973
CL139 Hoshikaze 1973
CL140 Getto 1973
CL141 Iwakaze 1975
CL142 Matsukaze 1975
CL143 Oitsukaze 1975
CL144 Arakaze 1974
CL145 Tanikaze 1974
CL146 Kochikaze 1974
CL147 Okikaze 1975
CL148 Suwakaze 1975
CL149 Sachikaze 1975
CL150 Natsukaze 1975
CL151 Harukaze 1974
CL152 Rindo 1976
CL153 Sawakaze 1976
CL154 Kaido 1976
CL155 Nadeshiko 1976
CL156 Yamazakura 1976
Matsunami 1 PC53 Matsunami 1971 no picture 84t, 25.0x6.0x1.3m, CODOD:2d/1d(3), 2200/180hp, 20.7kts, 30p; radar
Shikinami 17 PC54 Shikinami 1971 no picture 64t, 21.0x5.3x1.2m, 2d, 2200hp, 25kts, 10p; 1x1-12.7; MD806 radar
PC55 Tomonami 1971
PC56 Wakanami 1971
PC57 Isenami 1972
PC58 Takanami 1971
PC59 Mutsuki 1972
PC60 Mochizuki 1972
PC61 Haruzuki 1972
PC62 Kiyozuki 1972
PC63 Urazuki 1973
PC66 Uranami 1973
PC67 Tamanami 1973
PC68 Minegumo 1973
PC69 Kiyonami 1973
PC70 Okinami 1974
PC71 Wakagumo 1974
PC74 Asoyuki 1975
Nogekaze 4 CL99 Nogekaze 1972 no picture 29t, 16.0x4.1x0.8m, 2d, 500hp, 16.6kts, 6p; radar
CL105 Kusuaze 1972
CL107 Itokaze 1972
CL128 Kawakaze 1973
Akizuki 12 PC64 Akizuki 1974 no picture 77t, 26.0x6.3x1.1m, 3d, 3000hp, 22kts, 10p; 1x1-12.7; FRA Mk 2 radar
PC65 Shinonome 1974
PC72 Urayuki 1975
PC73 Iseyuki 1975
PC75 Hatagumo 1976
PC76 Makigumo 1976
PC77 Hamazuki 1976
PC78 Isozuki 1977
PC79 Shimanami 1977
PC80 Yuzuki 1979
PC81 Tamanami 1981
PC82 Awagiri 1983
Murakumo 23 PC201 Murakumo 1978 no picture 125t, 31.0x6.3x1.7m, 2d, 4800hp, 31kts, 11p; 1x1-12.7; radar
PC202 Kitagumo 1978
PC203 Yukigumo 1978
PC204 Asagumo 1978
PC205 Hayagumo 1979
PC206 Akigumo 1979
PC207 Yaegumo 1979
PC208 Natsugumo 1979
PC209 Yamagiri 1979
PC210 Kawagiri 1979
PC211 Teruzuki 1979
PC212 Natsuzuki 1979
PC213 Miyazuki 1980
PC214 Njigumo 1981
PC215 Tatsugumo 1981
PC216 Hamayuki 1981
PC217 Isonami 1981
PC218 Nagozuki 1981
PC219 Yaezuki 1981
PC220 Yamayuki 1982
PC221 Komayuki 1982
PC222 Umigiri 1983
PC223 Asagiri 1983
Yamayuri 64 CL201 Yamayuri 1978 no picture 40t, 18.0x4.3x0.8m, 2d, 900hp, 20kts, 6p; radar
CL202 Tachibana 1978
CL203 Komakusa 1979
CL204 Shiragiku 1979
CL205 Yaguruma 1979
CL206 Hamanasu 1979
CL207 Suzuran 1979
CL208 Isogiku 1979
CL209 Isegiko 1979
CL210 Ayame 1979
CL211 Ajisai 1979
CL212 Himawari 1979
CL213 Hazakura 1979
CL214 Hinagiku 1979
CL215 Hamagiku 1979
CL216 Fuyume 1979
CL217 Tsubaki 1979
CL218 Sazanka 1979
CL219 Aoi 1979
CL220 Suisen 1979
CL221 Yaezakura 1979
CL222 Akebi 1979
CL223 Shirahagi 1980
CL224 Benibana 1980
CL225 Muratsubaki 1979
CL226 Tsutsuji 1980
CL227 Ashibi 1979
CL228 Satozakura 1980
CL229 Yukisubaki 1980
CL230 Satsuki 1980
CL231 Ezogiku 1980
CL232 Akashio 1980
CL233 Kozakura 1980
CL234 Shirame 1980
CL235 Sarubia 1980
CL236 Suiren 1980
CL237 Hatsugiku 1981
CL238 Hamayura 1981
CL239 Airisu 1982
CL240 Yamabuki 1981
CL241 Shirayuri 1982
CL242 Karatachi 1981
CL243 Kobai 1982
CL244 Hamayuu 1982
CL245 Sasayuri 1983
CL246 Kosumosu 1983
CL247 Shiogiku 1982
CL248 Yamahagi 1982
CL249 Mokuren 1983
CL250 Isofuji 1983
CL251 Tamatsubaki 1984
CL252 Yodoki 1983
CL253 Iozakura 1983
CL254 Himetsubaki 1984
CL255 Tokikusa 1984
CL256 Mutsugiku 1984
CL257 Terugiko 1984
CL258 Mayazakura 1984
CL259 Yamagiko 1985
CL260 Tobiume 1985
CL261 Kotozakura 1985
CL262 Minogiku 1985
CL263 Kuroyuri 1984
CL264 Chiyogiku 1988
Akagi 7 PS101 Akagi 1980 no picture 189t, 35.0x6.3x1.3m, 2d, 4800(101-105)-4400(106,107)hp, 26.5(101-105)-27(106,107)kts, 12p; 1x1-12.7; radar
PS102 Tsukuba 1982
PS103 Kongo 1987
PS104 Katsuragi 1988
PS105 Hiromine 1988
PS106 Shizuki 1988
PS107 Takachiho 1988
Mihashi 2 PS01 Mihashi 1988 no picture 200t, 43.0x7.5x1.7m, 3d(2+1wj), 8800hp, 34kts, 13p; 1x1-12.7; Furuno radar
PS02 Saroma 1989
Shimagiri 3 PC83 Shimagiri 1985 no picture 50t, 23.0x5.3x1.9m, 3d, 3000hp, 30kts, 10p; 1x1-20/70(85), 1x1-12.7(83,84); FRA 10 Mk 2 radar
PC84 Setogiri 1985
PC85 Hayagiri 1985
Isokaze 2 CL01 Isokaze 1989 no picture 21t, 17.0x4.3x1.0m, 2d, 900hp, 20kts, 5p; radar
CL02 Hayakaze 1989



AIRCRAFT

NAVY

Ship-based

 117 HSS-2A/B, 2 SH-60, 5 KV-107A, 4 S-80

Land-based combat capable

 59 P-3C, 30 P-2J, 2 EP-2J, 1 EP-3C, 10 OH-6D/J

ARMY

Land-based combat capable

50 AH-1S, 171 OH-6D/J

AIR FORCE

Combat capable

70 F-1, 133 F-4EJ, 136 F-15J/DJ, 14 RF-4EJ, 10 E-2C, 1 C-1 EW, 4 YS-11 EW, 40 T-1A/B, 50 T-2

MARITIME SAFETY AGENCY

Ship-based

32 Bell 212, 4 Bell 206, 2 Hughes 369



© Ivan Gogin, 2017
