World navies yesterday

1975



Taiwan 01 January 1975

SUBMARINES

SS Tench GUPPY II 2 S91 Hai Shih 1945 1870/2440t, 93.6x8.3x5.2m, 4dg/4em(2), 4610/5400hp, 18/15kts, 81p, 135(91)-120(92)m; 10-533TT; SS-2 radar, BQR-2B, BQS-4C, DUUG-1B sonars, WLR-1, WLR-3 ECM
S92 Hai Pao 1946

PRINCIPAL SURFACE COMBATANTS

DD Benson 3 DD14 Lo Yang 1940 2591(14,15)-2572(17)t, 106.2x11.0x4.0m, 4b,2gst, 50000hp, 35kts, 208p; 4x1-127/38, 2x2-40/60(14,15), (2x4+2x2)-40/60(17), 4x1-20/70(14,15), 2x2-20/70(17), 1x5-533TT(14,15), 6dct, 2dcr; SC, Mk 4 radars, sonar
DD15 Han Yang 1940
DD17 Nan Yang 1940
Fletcher 4 DD8 Kwei Yang 1943 3050t, 114.7x12.1x4.4m, 4b,2gst, 60000hp, 35kts, 275p; 5x1-127/38(8,18,19), 4x1-127/38(9), 3x2-76/50(9), (2x4+1x2)-40/60(8,18,19), 6x1-20/70(8,18,19), 1x5-533TT(19), 2x3-324TT(8,9), 2x24 Hedgehog ASWRL, 4dct(18,19), 2dcr; SPS-6(8,9,19), SPS-10, SPS-12(18), SPG-25, SPG-37 radars, SQS-29(8,9), SQS-4(18,19) sonar, BLR-1/2 ECM
DD9 Chiang Yang 1943
DD18 An Yang 1943
DD19 Kuen Yang 1943
Allen M. Sumner 6 DD1 Hsiang Yang 1944 3218t, 114.8x12.5x4.3m, 4b,2gst, 60000hp, 36.5kts, 336p; 3x2-127/38, (2x2+2x1)-76/50(1,6,10), (1x4+2x2)-40/60(2,3,5), 2x3-324TT, 2x24 Hedgehog ASWRL, 2dcr; SPS-6(1-3,5,6), SPS-10, SPS-40(10), SPG-25 radars, SQS-29 sonar, BLR-1 ECM
DD2 Heng Yang 1944
DD3 Hua Yang 1945
DD5 Yuen Yang 1944
DD6 Huei Yang 1944
DD10 Po Yang 1944
Allen M. Sumner FRAM-II 2 DD14 Lo Yang 1944 3210t, 114.8x12.5x4.3m, 4b,2gst, 60000hp, 33.4kts, 302p; 3x2-127/38, 2x3-324TT, 2x24 Hedgehog ASWRL, 1 helicopter(Hughes 500MD); SPS-10, SPS-29(14), SPS-37(17), SPG-25 radars, SQS-29 sonar, BLR-1 ECM
DD17 Nan Yang 1945
Gearing radar picket 1 DD7 Fu Yang 1945 3493t, 119.0x12.5x4.4m, 4b,2gst, 60000hp, 32kts, 302p; 2x2-127/38, 4x2-40/60, 4x1-12.7, 2x3-324TT, 2x24 Hedgehog ASWRL; SPS-10, SPS-37, SPG-25 radars, SQS-10, SQS-29 sonars, BLR-1 ECM
Gearing FRAM-II 1 DD11 Dang Yang 1947 3493t, 119.0x12.5x4.4m, 4b,2gst, 60000hp, 32kts, 302p; 2x2-127/38, 2x2-40/60, 4x1-12.7, 2x3-324TT, 1x24 Hedgehog ASWRL, 1 helicopter (Hughes 500MD); SPS-10, SPS-6C, SPG-25 radars, SQS-29 sonar
Gearing FRAM-I 3 DD12 Chien Yang 1946 3493t, 119.0x12.5x4.4m, 4b,2gst, 60000hp, 32kts, 310p; 1x8 ASROC ASuR(17)(12,21), 2x2-127/38, 2x2-40/60(20), 4x1-12.7(12,21), 2x3-324TT, 1helicopter (Hughes 500MD); SPS-29, SPS-37(12,21), SPS-40(20), SPG-25 radars, SQS-23 sonar, BLR-1 ECM
DD20 Lao Yang 1946
DD21 Liao Yang 1945
FF Evarts 1 DE21 Tai Kang 1943 1416t, 88.7x10.7x3.1m, 4dg,2em, 6000hp, 19.5kts, 156p; 4x1-76/50, 1x2-40/60, 10x1-20/70, 8dct, 2dcr; SA, SF radars, sonar
Cannon 1 DE24 Tai Hu 1943 1602t, 93.3x11.2x3.2m, 4dg,2em, 6000hp, 21kts, 186p; 2x1-127/38, (2x2+4x1)-40/60, 4x1-20/70, 2x3-324TT, 1x24 Hedgehog ASWRL, 2dcr; SA, SF radars, sonar
APD 12 APD215 Tien Shan 1945 2130t, 93.3x11.3x3.8m, 2b,2stg,2em, 12000hp, 23.6kts, 203p; 2x1-127/38, 3x2-40/60, 4x1-20/70, 2x3-324TT or 2x24 Hedgehog ASWRL, 2dcr; 2 LCVP, 162troops; SPS-5 radar, sonar
PF32 Yu Shan 1944
PF33 Hua Shan 1945
PF34 Wen Shan 1943
PF35 Fu Shan 1945
PF36 Lu Shan 1943
PF37 Shou Shan 1944
PF38 Tai Shan 1945
PF39 Heng Shan 1944
PF42 Kang Shan 1943
PF43 Chung Shan 1943
PF44 Kung Shan 1943
Rudderow 1 DE27 Tai Yuan 1944 1811t, 93.3x11.3x3.4m, 2b,2stg,2em, 12000hp, 23kts, 200p; 2x1-127/38, 2x2-40/60, 4x1-20/70, 2x3-324TT, 1x24 Hedgehog ASWRL, 2dcr; SPS-6, SPS-10 radars, sonar

PATROL AND COASTAL COMBATANTS

PS Auk 3 PCE66 Wu Sheng 1945 1250t, 67.4x9.8x3.3m, 2dg,2em, 2880hp, 18kts, 80p; 2x1-76/50, 2x2-40/60, 2x2-20/70, 2x3-324TT, 1x24 Hedgehog ASWRL, 2dcr; SPS-5 radar, SQS-17 sonar
PCE67 Ju Yong 1945
PCE70 Ping Jing 1942
PC PGM 1 PC117 Zhu Jiang 1945 463t, 52.9x7.1x3.3m, 2d, 2880hp, 19kts, 65p; 1x1-76/50, 1x2-40/60, 6x1-20/70, 1x2-60/12mortar, 2x1-12.7; radar
PT PT1 2 PT1, 2   1957 no picture 40t, 21.6x6.1xm, 3pe, 40kts, 12p; 1x1-40/60, 1x2-20/70, 2-450TT; radar
PTC32 2 PTC32, 33   1957 46t, 21.6x5.8x1.5m, 3pe, 42kts, 12p; 1x1-20/70, 2x2-12.7, 2-450TTT; radar
PTC34 2 PTC34, 35   1957 53t, 24.1x7.1x1.7m, 3pe, 39kts, 12p; 1x1-40/60, 2x1-12.7, 2-450TT
PB PB60 22 PB60-81   1971-1973 no picture 11t, 12.8xxm, 2d, 1300hp, 32kts; 1x1-40/60; radar
PTC38 1 PTC38   1962 no picture 30t, 21kts; 1x1-40/60, 1x1-20/70; radar
Chie Kuo 2 PTC35 Chie Kuo 1969 no picture 32t, 19.3x5.7x1.4m, 2d, 1300hp, 22kts, 8p; 4x1-12.7; radar
PTC36   1969

AMPHIBIOUS

LCC LST 1 LCC1 Kao Hsiung 1944 4080t, 100.0x15.2x4.3m, 2d, 1800hp, 12.1kts, 125p; (2x2+2x1)-40/60, 2x1-20/70, 4x1-12.7; SPS-10, SPS-12 radars
LSD Ashland 1 LSD191 Dong Hai 1944 9375t, 139.5x22.0x4.8m, 2b,2QuiPE, 7400hp, 15.4kts, 254p; (2x4+2x2)-40/60; 3 LCT(6), 332troops; SPS-5, nav. radars
LST LST(2) 22 LST201 Chung Hai 1944 4080t, 100.0x15.2x4.3m, 2d, 1800hp, 12.1kts, 125p; (2x2+6x1)-40/60, 12x1-20/70; 6 LCVP, 20tanks, 163troops; SO radar
LST203 Chung Ting 1944
LST204 Chung Hsing 1944
LST205 Chung Chien 1944
LST206 Chung Chi 1944
LST208 Chung Shun 1944
LST209 Chung Lien 1945
LST210 Chung Yung 1944
LST216 Chung Kuang 1943
LST217 Chung Suo 1943
LST218 Chung Chi 1943
LST221 Chung Chuan 1944
LST222 Chung Sheng 1944
LST223 Chung Fu 1944
LST224 Chung Cheng 1945
LST225 Chung Chiang 1945
LST226 Chung Chih 1945
LST227 Chung Ming 1945
LST228 Chung Shu 1944
LST229 Chung Wan 1944
LST230 Chung Pang 1944
LST231 Chung Yeh 1945
LSM LSM 4 LSM341 Mei Chin 1944 1095t, 62.0x10.5x2.1m, 2d, 2800hp, 13kts, 60p; 1x2-40/60, 4x1-20/70; 5tanks, 54troops; SO radar
LSM347 Mei Song 1945
LSM353 Mei Ping 1945
LSM356 Mei Le 1945
LSS LCT(6) 14 LCU481 He Qin 1944 320t, 36.3x10.0x1.2m, 3d, 675hp, 8kts, 13p; 2x1-20/70; 4tanks
LCU482 He Zhong 1944
LCU483 He Cheng 1944
LCU484 He Zhong 1944
LCU485 He Zhang 1943
LCU494 He Chun 1944
LCU495 He Yong 1944
LCU496 He Jian 1944
LCU401 He Qi 1944
LCU402 He Hui 1944
LCU403 He Yao 1944
LCU405 He Feng 1944
LCU406 He Chao 1944
LCU407 He Teng 1944
Ho Shan 6 LCU488 Ho Shan 1955 350t, 36.3x10.4x1.6m, 3d, 675hp, 10kts, 15p; 2x2-20/70; 3tanks; radar
LCU489 Ho Chuan 1955
LCU490 Ho Seng 1955
LCU491 Ho Meng 1955
LCU492 Ho Mou 1955
LCU493 Ho Shou 1955
LC LCVP 120 1-120   1943-1945 13t, 11.2x3.2x0.9m, 2d, 220hp, 8kts, 3p; 2x1-12.7; 36troops
LCM(3) 8 1-8   1942-1944 52t, 15.3x4.3x1.4m, 2d, 330hp, 8kts, 4p; 2x1-12.7; 1tank
LCM(6) 250 1-250   1955-1974 62t, 17.1x4.4x1.5m, 2d, 450hp, 9kts, 9p; 2x1-12.7; 1tank
type 272 30 1-30   1970-1974 13t, 11.2x3.2x0.9m, 2d, 450hp, 15kts, 3p; 2x1-12.7; 36troops

MINE WARFARE

MSC Bluebird 14 MSC155 Yung Ping 1954 400(155,156)-390(157-168)t, 44.3x8.1x2.1m, 2d, 1200((155,156)-880(157-168)hp, 13kts, 39p; 1x2-20/70, magnetic, acoustic, mechanical minesweeping gear; SPS-53 radar, UQS-1 sonar
MSC156 Yung An 1954
MSC157 Yung Nien 1959
MSC158 Yung Chou 1959
MSC159 Yung Hsin 1965
MSC160 Yung Ju 1965
MSC161 Yung Lo 1966
MSC162 Yung Fu 1953
MSC163 Yung Ching 1953
MSC164 Yung Shan 1953
MSC165 Yung Cheng 1953
MSC166 Yung Chi 1954
MSC167 Yung Jen 1954
MSC168 Yung Sui 1954
MSB MSML1 12 MSML1-12   1943-1945 no picture 24t, 15.3x4.0x1.3m, 1d, 60hp, 8kts, 4p; mechanical minesweeping gear
MSB1 1 MSB12   1945 42t, 17.5x4.8x1.3m, 2d, 300hp, 12kts, 6p; mechanical minesweeping gear

CUSTOMS

PC PC 3 1 Dong Jiang 1944 463t, 52.9x7.1x3.3m, 2d, 2880hp, 19kts, 65p; 1x1-76/50, 1x1-40/60, 4x1-20/70, 2x4 Mousetrap ASWRL, 2dct, 2dcr; radar, sonar
  Xi Jiang 1944
  Bei Jiang 1944
