World navies yesterday

1975



Italy 01 January 1975

SUBMARINES

SS Balao Fleet Snorkel 2 S507 Alfredo Cappellini 1945 1830/2440t, 95.0x8.3x5.2m, 4dg,4em(2), 4610/2700hp, 20/10kts, 82p, 120m; 1x1-127/25(507), 10-533TT; SS, ST, SV radars, BQR-2, BQS-2, SQR-3 sonars
S512 Evangelista Torricelli 1944
Toti 4 S505 Attilio Bagnolini 1968 535/591t, 46.2x4.7x4.0m, 2dg,1em, 2200hp, 9.7/14kts, 26p, 180m; 4-533TT; BPS-704 radar, IPD-64, MD-64 sonars, ECM, IPD-64 CCS
S506 Enrico Toti 1968
S513 Enrico Dandolo 1968
S514 Lazzaro Mocenigo 1969
Balao GUPPY II 2 S501 Primo Longobardo 1949 1975/2450t, 99.5x8.2x5.2m, 4dg/4em(2), 4610/5400hp, 17.2/14.5kts, 86p, 135m; 10-533TT; BPS-1, BPS-4, BPS-5 radars, BQR-2, BQS-2, SQR-3, BQG-4 sonars
S502 Gianfranco Gazzana Priaroggia 1948
Tang 2 S515 Livio Piomatra 1952 1821/2500t, 84.8x8.3x5.2m, 3dg,2em, 4500/5600hp, 15.5/16kts, 83p, 210m; 8-533TT; BPS-12 radar, BQS-4, BQR-2 sonars
S516 Romeo Romei 1952

PRINCIPAL SURFACE COMBATANTS

CG Giuseppe Garibaldi 1 C551 Giuseppe Garibaldi 1937 11117t, 187.0x18.9x6.8m, 8b,2gst, 100000hp, 34kts, 692p; 130belt, 55decks, 135turrets, 140CT; 1x2 Terrier SAM(72), 2x2-135/45, 8x1-76/62; SPS-39, SPS-6, ARGO-5000, 2x SPG-55 radars
Andrea Doria 2 C553 Andrea Doria 1964 6500t, 149.3x17.3x5.0m, 4b,2gst, 60000hp, 30kts, 485p; 1x2 Terrier SAM(40), 8x1-76/62, 2x3-324TT, 4helicopters(AB-212); SPS-12, SPS-39A, SPQ-2, 2x SPG-55, 4x RTN-10X radars, SQS-39 sonar, SADOC CCS
C554 Caio Duilio 1964
Vittorio Veneto 1 C550 Vittorio Veneto 1969 8850t, 179.6x19.4x6.0m, 4b,2gst, 73000hp, 30.5kts, 550p; 1x2 Terrier SAM(40)/ASROC ASuR(20), 8x1-76/62, 2x3-324TT, 9helicopters (9 AB-212 or 6 SH-3D); SPS-40, SPS-52, SPQ-2B, 2x SPG-55B, 4x RTN-10X radars, SQS-23 sonar, SADOC-1 CCS
DD Capitani Romani 1 D562 San Giorgio 1943 5600t, 142.2x14.4x6.4m, CODAG:2gt+4d(2), 31000hp, 28kts, 494+130p; 2x2-127/38, 3x1-76/62, 2x3-324TT, 1x3 Menon ASWRL; SPS-6, SPQ-2, 3x RTN-7X, Mk 25 radars, SQS-11 sonar
Impetuoso 2 D558 Impetuoso 1958 3810t, 127.6x13.2x4.5m, 4b,2gst, 65000hp, 34kts, 315p; 2x2-127/38, (2x4+4x2)-40/60, 2x3-324TT, 1x3 Menon ASWRL, 4dct, 1dcr; SPS-6, SG-6B, 4x SPG-34, Mk 25 radars, SQS-4 sonar
D559 Indomito 1958
Impavido 2 D570 Impavido 1963 3990t, 131.3x13.7x4.4m, 4b,2gst, 70000hp, 33kts, 340p; 1x1 Tartar SAM(40), 1x2-127/38, 4x1-76/62, 2x3-324TT, heldeck; SPS-12, SPS-39, SPQ-2, 2x SPG-51, Mk 25, 4x SPG-34 radars, SQS-23 sonar
D571 Intrepido 1964
Fletcher 2 D555 Geniere 1944 3005(555)-2950(561)t, 114.7(555)-114.8(561)x12.1x4.2m, 4b,2gst, 60000hp, 38(555)-35(561)kts, 273(555)-250(561)p; 4x1-127/38(555), 2x1-127/38(561), 3x2-76/50(555), 2x2-76/50(561), 7x1-20/70(555), 4x2-20/70(561), 4x1-533TT(561), 2x24 Hedgehog ASWRL(561), 6dct(555), 2dcr(555); SPS-6, SPS-10, Mk 25 radars, SQS-4 sonar
D561 Fante 1943
Audace 2 D550 Ardito 1973 4400t, 136.6x14.4x4.6m, 4b,2gst, 73000hp, 33kts, 380p; 1x1 Tartar SAM(40), 2x1-127/54, 4x1-76/62, 4-533TT, 2x3-324TT, 2helicopters (2 AB-212 or 1 SH-3D); SPS-12(550), RAN-3(551), SPS-52B, SPQ-2, 2x SPG-51B, 3x RTN-10X, SPN-748(550) radars, CWE-610 sonar, 2x SCLAR dl, SADOC CCS
D551 Audace 1972
FF Cannon 1 F590 Aldebaran 1944 1602t, 93.3x11.2x3.2m, 4dg,2em, 6000hp, 21kts, 186p; 3x1-76/50, 3x2-40/60, 8x1-20/70, 1x24 Hedgehog ASWRL, 8dct, 2dcr; SPS-6, SMA radars, QGB sonar
Canopo 4 F551 Canopo 1958 2250t, 103.1x12.0x3.8m, 2b,2gst, 22000hp, 26kts, 207p; 3x1-76/62, 2x3-324TT, 1x3 Menon ASWRL, 2dct; SPS-6, SG-6B, SPQ-2, RTN-7X radars, SQS-11A, SQS-36 sonars
F553 Castore 1957
F554 Centauro 1957
F555 Cigno 1957
Bergamini 4 F593 Carlo Bergamini 1962 1650t, 94.0x11.4x3.1m, 4d(2), 16000hp, 25kts, 163p; 2x1-76/62, 2x3-324TT, 1x1 Menon ASWRL, 1 helicopter (AB-212); SPS-12, SPQ-2, RTN-10X radars, SQS-40 sonar, SPR-A ECM
F594 Virgilio Fasan 1962
F595 Carlo Margottini 1962
F596 Luigi Rizzo 1961
Alpino 2 F580 Alpino 1968 2700t, 113.3x13.1x3.8m, CODAG:2gt+4d(2), 31800hp, 29kts, 263p; 6x1-76/62, 2x3-324TT, 1x1 Menon ASWRL, 2 helicopters (AB-212); SPS-12, SPN-748, RTN-30X, 3x RTN-10X radars, SQS-43, SQA-10 sonars, SPR-A ECM, 2x SCLAR dl
F581 Carabiniere 1968
FS Gabbiano 3 F549 Bombarda 1951 728t, 64.4x8.7x2.5m, 2d, 3500hp, 18kts, 110p; 1x2-40/60(549), 2x2-40/60(569,579), 2x1-20/70(549), 2x1-450TT, 1x24 Hedgehog ASWRL, 4dct, 2dcr(549), 1dcr(569,579); SO-13(549,569), SPS-6(579) radar, QCU-2 sonar
F569 Chimera 1943
F579 Sfinge 1943
Albatros 4 F542 Aquila 1956 950t, 76.3x9.7x2.8m, 2d, 5200hp, 19kts, 110p; 3x1-40/70, 2x3-324TT, 2x24 Hedgehog ASWRL, 2dct, 1dcr; SPQ-2 radar, QCU-2 sonar
F543 Albatros 1955
F544 Alcione 1955
F545 Airone 1955
De Cristofaro 4 F540 Pietro De Cristofaro 1965 1020t, 80.2x10.0x2.5m, 2d, 8400hp, 23kts, 131p; 2x1-76/62, 2x3-324TT, 1x1 Menon ASWRL; SPQ-2, RTN-10 radars, SQS-36, SQS-36VDS sonars
F541 Umberto Grosso 1966
F546 Licio Visintini 1966
F550 Salvatore Todaro 1966

PATROL AND COASTAL COMBATANTS

PHM Sparviero 1 P420 Sparviero 1974 63t, 23.0x7.0x1.5m, CODOG:1d(1)/1gt(1wj), 165/5000hp, 40kts, 10p; 2x1 Otomat SSM(2), 1x1-76/62; SPQ-701, RTN-10X radars
PT MS type 1 1 P473 MS473 1942 64t, 28.0x4.3x1.6m, 3d, 4500hp, 33kts, 19p; 1x1-40/60, 2-450TT
MS type 2 2 P474 MS474 1943 66t, 28.0x4.3x1.6m, 3d, 4500hp, 33kts, 19p; 1x1-40/60, 2-450TT
P481 MS481 1943
MC490 1 P490 Folgore 1955 190t, 39.4x5.8x1.7m, 4d, 10000hp, 36kts, 39p; 2x1-40/60, 2-533TT; radar
MC491 2 P491 Lampo 1963 196t, 43.0x6.3x1.5m, CODAG:1gt+2d(3), 11700hp, 39kts, 33p; 2x1-40/70, 2-533TT; 3ST7-250 radar
P492 Baleno 1965
MC590 2 P493 Freccia 1965 205t, 46.1x7.2x1.6m, CODAG:1gt+2d(3), 11850hp, 40kts, 37p; 3x1-40/70 or (1x1-40/70, 4-533TT); RTN-150 radar
P494 Saetta 1966
PC PC 1 F597 Vedetta 1955 400t, 53.1x7.3x3.1m, 4d(2), 3240hp, 19kts, 62p; 2x1-40/60, 2x1-20/70, 1x24 Hedgehog ASWRL, 2dct, 1dcr; QCU-2 sonar
PB Higgins 78ft 3 P441 MS441 1942 48t, 24.0x6.1x1.6m, 3pe, 4500hp, 34kts, 11p; 1x1-40/60, 3x1-20/70; SPS-21 radar
P443 MS443 1942
P453 MS453 1943

AMPHIBIOUS

LST De Soto County 2 L9890 Grado 1958 7854t, 134.8x18.9x4.1m, 6d(2), 15000hp, 17.2kts, 185p; 3x2-76/50, heldeck; 4 LCVP, 23 tanks, 634 troops; 3RM20 radar
L9891 Caorle 1957
LSM Quarto 1 L9881 Quarto 1968 980t, 69.0x9.6x11.8m, 3d, 2300hp, 13kts; 2x2-40/70; 2 LCVP, tanks, troops; SPQ-2, RAN-3L radars
LPA Barnegat 1 A5301 Pietro Cavezzale 1943 2800t, 94.7x12.5x3.7m, 4dg,2em, 6080hp, 16kts, 200p; 1x1-76/50, 1x2-40/60; divers; SPS-6, Jason radars
Kenneth Whiting 1 L9871 Andrea Bafile 1944 12610t, 150.0x21.2x7.2m, 2b,1gst, 8500hp, 16.5kts, 58p; 2x1-127/38, 2 helicopters (AB-212); special troops; radar
LKA Andromeda 1 L9870 Etna 1944 13910t, 139.9x19.2x7.9m, 2b,1gst, 6000hp, 16.5kts, 404p; 2x2-40/60; 6 LCM(6), 2 LCM(3), 13 LCVP, 1 LCPL, 4900t cargo, 78troops; SPS-6 radar
LSS MZ-A 5 A5341   1942 239t, 47.0x6.5x1.0m, 3d, 450hp, 11kts, 13p; 65t cargo
A5343   1942
A5344   1942
A5345   1942
A5346   1942
MZ-B 3 A5347   1943 279t, 46.5x6.5x1.0m, 3d, 450hp, 11kts, 13p; 65t cargo
A5348   1943
A5349   1943
LCT(2) 3 A5331 MOC1201 1942 460t, 48.8x9.5x1.6m, 3d, 1380hp, 11kts, 12p; 2x1-20/70; 250t cargo
A5337 MOC1207 1942
A5338 MOC1208 1942
LCT(3) 4 A5332 MOC1202 1942 640t, 58.5x9.5x1.7m, 2d, 1000hp, 10.5kts, 12p; 4x1-20/70; 5tanks
A5333 MOC1203 1942
A5334 MOC1204 1942
A5335 MOC1205 1942
LC LCM(3) 18 MTM9901, 9902, 9904, 9905, 9907-9920   1942-1945 52t, 15.3x4.3x1.4m, 2d, 330hp, 8kts, 4p; 2x1-12.7; 1tank
LCM(6) 9 MTM9921-9929   1943-1945 56t, 17.1x4.3x1.2m, 2d, 450hp, 9kts, 5p; 2x1-12.7; 1tank
LCVP 54 MTP9701-9754   1943-1956 13t, 11.2x3.2x0.9m, 2d, 220hp, 8kts, 3p; 2x1-12.7; 36troops

MINE WARFARE

MSO Aggressive 4 M5430 Salmone 1956 735t, 52.3x10.4x4.0m, 2d, 1600hp, 14kts, 70p; 1x1-40/60, mechanical, magnetic, acoustic minesweeping gear; SPS-53 radar, UQS-1 sonar
M5431 Storione 1956
M5432 Sgombro 1957
M5433 Squalo 1957
MSC Adjutant 31 M5501 Abete 1953 400t, 44.3x8.1x2.1m, 2d, 1200hp, 13kts, 39p; 1x2-20/70, mechanical, magnetic, acoustic minesweeping gear; SPS-53 radar, UQS-1 sonar
M5504 Castagno 1955
M5505 Cedro 1954
M5507 Faggio 1953
M5508 Frassino 1953
M5509 Gelso 1953
M5510 Larice 1953
M5511 Noce 1954
M5512 Olmo 1954
M5513 Ontano 1954
M5514 Pino 1954
M5516 Platano 1954
M5517 Quercia 1954
M5519 Mandorlo 1960
M5521 Bambù 1956
M5522 Ebano 1956
M5523 Mango 1956
M5524 Mogano 1957
M5525 Palma 1957
M5527 Sandalo 1957
M5531 Agave 1955
M5532 Alloro 1955
M5533 Edera 1955
M5534 Gaggia 1956
M5535 Gelsomino 1955
M5536 Giaggiolo 1956
M5537 Glicine 1956
M5538 Loto 1957
M5540 Timo 1956
M5541 Trifoglio 1955
M5542 Vischio 1956
MSI Ham 11 M5450 Aragosta 1957 188t, 32.5x6.4x1.8m, 2d, 1000hp, 15kts, 14p; 1x1-20/70, mechanical minesweeping gear; BX-732 radar
M5452 Astice 1957
M5454 Calamaro 1957
M5457 Gambero 1957
M5458 Granchio 1957
M5459 Mitilo 1957
M5462 Pinna 1957
M5463 Polipo 1957
M5464 Porpora 1957
M5465 Riccio 1957
M5466 Scampo 1957

COAST GUARD

PB CP226 2 CP226, 227   1963 no picture 15t, 13.1x4.8x1.5m, 2d, 740hp, 20kts
CP228 3 CP228-230   1965-1966 no picture 15t, 13.4x4.8x1.3m, 2d, 900hp, 24kts, 7p
CP231 8 CP231-238   1968-1970 no picture 16t, 13.4x4.8x1.3m, 2d, 900hp, 26kts, 7p; radar
Florillo 1 CP307 Michele Florillo 1968 no picture 85t, 26.7x5.6x1.6m, 3d, 2450hp, 24kts, 5p; radar
CP239 5 CP239-243   1973-1974 no picture 24t, 16.8x5.0x1.7m, 2d, 1520hp, 28.6kts; radar
CP2006 4 CP2006-2009   1973-1974 no picture 11t, 12.5x3.6x1.1m, 2d, 540(2006,2007)-660(2008,2009)hp, 24kts, 4p
CP2010 5 CP2010-2014   1973-1974 no picture 11t, 12.5x3.6x1.1m, 2d, 470(2010,2011)-420(2012-2014)hp, 24kts, 4p
CP2024 1 CP2024   1973 no picture 15t, 13.7x3.8x1.3m, 2d, 700hp, 24kts, 4p
CP2018 3 CP2018-2020   1974 no picture 10t, 12.5x3.6x1.1m, 2d, 570hp, 21kts, 4p

CUSTOMS

PB USCG 4 1 Alberti 1943 no picture 28t, 19.3xxm, 20kts
2 Lippi 1943
3 De Santis 1943
4 Cerretto 1943
S-boot 2 1 Paolini 1943 no picture 60t
2 Trezza 1943
Cappelletti 3 1 Cappelletti 1954 no picture 40t, 22.0xxm, 16.6kts
2 Garzone 1954
3 Miccoli 1954
GL.201 6 GL.201-206   1956 no picture 14t, 15.3xxm, 16.5kts
GL.303 29 GL.303-331   1956-1959 no picture 16t, 15.5x4.9x1.1m, 2d, 880hp, 31kts, 7p; Raytheon 2502 radar
Corrubia 2 1 Corrubia 1958 no picture 79t, 31.5xxm, 25kts; 1x1-20/70
2 Giudice 1958
Monti 2 1 Monte Cimone 1959 no picture 109t, 33.5xxm, 24.3kts; 1x1-20/70
2 Monte Sperone 1959
Gabriele 2 G70 Gabriele 1967 no picture 54t, 23.2x6.6x1.0m, 3d, 2500hp, 34.2kts, 11p; 1x1-12.7; SC-1210 radar
G71 Grasso 1967
Dark 8 G72 Calabrese 1956 64t, 21.8x5.9x1.8m, 2d, 5000hp, 40kts, 15p; 1x1-20/70; radar
G73 Inzucchi 1956
G74 La Spina 1956
G75 Sanna 1956
G76 Urso 1956
G77 Vitali 1956
G78 Genna 1956
G79 Laganà 1956
Meattini 11 G10 Meattini 1970 no picture 40t, 20.1x5.2x0.9m, 2d, 2500hp, 35.4kts, 11p; 1x1-12.7; SC-1210 radar
G11 Amici 1970
G12 Di Bartolo 1972
G13 RD36 1972
G14 Gori 1973
G15 Ramaci 1973
G16 Denaro 1973
G17 Bambace 1974
G19 Steri 1974
G20 Cotugno 1974
G21 Manoni 1974
