World navies yesterday

1970



Italy 01 January 1970

SUBMARINES

SS Gato GUPPY IB 2 S510 Leonardo da Vinci 1943 1830/2440t, 93.6x8.2x5.2m, 4dg,4em(2), 4610/5400hp, 18/15kts, 82p, 90m; 10-533TT; BQR-2, BQS-2, SQR-3 sonars, SS, SV, BPS-1 radars
S511 Enrico Tazzoli 1942
Gato Fleet Snorkel 3 S507 Alfredo Cappellini 1945 2440t, 95.0x8.3x5.2m, 4dg,4em(2), 4610/2700hp, 20/10kts, 82p, 120m; 1x1-127/25(507), 10-533TT; BQR-2, BQS-2, SQR-3 radars, SS, ST, SV sonars
S508 Francesco Morosini 1944
S512 Evangelista Torricelli 1944
Flutto deries II 1 S503 Pietro Calvi 1961 905/1107t, 66.0x7.0x4.0m, 2dg, 3em(1), 2700/2700hp, 14/14kts, 60p, 120m; 4-533TT; radar, sonar
Toti 4 S505 Attilio Bagnolini 1968 535/591t, 46.2x4.7x4.0m, 2dg,1em(1), 2200hp, 9.7/14kts, 26p, 180m; 4-533TT; RM-20/SMG radar, IPD-64 sonar, ECM, IPD-64 CCS
S506 Enrico Toti 1968
S513 Enrico Dandolo 1968
S514 Lazzaro Mocenigo 1969

PRINCIPAL SURFACE COMBATANTS

CGH Andrea Doria 2 C553 Andrea Doria 1964 6500t, 149.3x17.3x5.0m, 4b,2gst, 60000hp, 30kts, 485p; 1x2 Terrier SAM(40), 8x1-76/62, 2x3-324TT, 4helicopters(AB-212); SPS-12, SPS-39A, SPQ-2, 2x SPG-55, 4x RTN-10X radars, SQS-39 sonar, SADOC CCS
C554 Caio Duilio 1964
Vittorio Veneto 1 C550 Vittorio Veneto 1969 8850t, 179.6x19.4x6.0m, 4b,2gst,m 73000hp, 30.5ktsm 550p; 1x2 Terrier/ASROC SAM/ASuM(40 Terrier, 20 ASROC), 8x1-76/62, 2x3-324TT, 9helicopters (9 AB-212); SPS-40, SPS-52, SPQ-2B, 2x SPG-55B, 4x RTN-10X radars, SQS-23 sonar, SADOC-1 CCS
CG Condottieri batch 5 1 C551 Giuseppe Garibaldi 1937 11117t, 187.0x18.9x6.8m, 6b,2gst, 85000hp, 29kts, 692p; 130belt, 55decks, 135turrets, 140CT; 4 Polaris A-1 SLBM (fitted for), 1x2 Terrier SAM(72), 2x2-135/45, 8x1-76/62; SPS-39, SPS-6, ARGO-5000, 2x SPG-55 radars
DDG Impavido 2 D570 Impavido 1963 3990t, 131.3x13.7x4.4m, 4b,2gst, 70000hp, 33kts, 340p; 1x1 Tartar SAM(40), 1x2-127/38, 4x1-76/62, 2x3-324TT, helodeck; SPS-12, SPS-39, SPQ-2, 2x SPG-51, Mk25, 4x SPG-34 radars, SQS-23 sonar
D571 Intrepido 1964
DD Laffey 1 D553 Artigliere 1942 2600t, 106.2x11.0x4.9m, 4b,2gst, 50000hp, 35kts, 208p; 4x1-127/38, 2x2-40/60, 7x1-20/70, 6dct, 2dcr; SC, Mk4 radars, sonar
Gleaves 1 D554 Aviere 1941 2572t, 106.2x11.0x4.0m, 4b,2gst, 50000hp, 35kts, 208p; 4x1-127/38, (2x4+2x2)-40/60, 2x2-20/70, 6dct, 2dcr; SC, Mk4 radars, sonar
Capitani Romani 2 D562 San Giorgio 1943 5600t, 142.2x14.4x6.4m, 2gt+4d(2)(562)-4b,2gst(563), 31000(562)-110000(563)hp, 28(562)-38.5(563)kts, 494p; 20turrets, 15CT; 2x2-127/38(562), 3x2-127/38(563), 3x1-76/62(562), (3x4+4x2)-40/60(563), 2x3-324TT(562), 1x3-305 Menon ASWRL, 4dct(563), 1dcr(563); SPS-6, SG-6B(563), SPQ-2(562), Mk12/22(563), 3x RTN-7X(562), Mk25(562) radars, SQS-11 sonar
D563 San Marco 1956
Impetuoso 2 D558 Impetuoso 1958 3810t, 127.6x13.2x4.5m, 4b,2gst, 65000hp, 34kts, 315p; 2x2-127/38, (2x4+4x2)-40/60, 2x3-324TT, 1x3-305 Menon ASWRL, 4dct, 1dcr; SPS-6, SG-6B, 4x SPG-34, Mk25 radars, SQS-4 sonar
D559 Indomito 1958
Fletcher 2 D560 Lanciere 1942 2950t, 114.8x12.1x5.5m, 4b,2gst, 60000hp, 35kts, 250p; 2x1-127/38, 2x2-76/50, 4x2-20/70, 4x1-533TT, 2x24-178 Hedgehog ASWRL; SPS-6, SPS-10, Mk25 radars, SQS-4 sonar
D561 Fante 1943
FF Cannon 3 F590 Aldebaran 1944 1602t, 93.3x11.2x3.2m, 4dg,2em, 6000hp, 21kts, 186p; 3x1-76/50, 3x2-40/60, 8x1-20/70, 1x24-178 Hedgehog ASWRL, 8dct, 2dcr; SPS-6, SMA radars, QGB sonar
F591 Altair 1944
F592 Andromeda 1943
Canopo 4 F551 Canopo 1958 2250t, 103.1x12.0x3.8m, 2b,2gst, 22000hp, 26kts, 207p; 2x2-76/62(554,555), 3x1-76/62(551,553), 2x2-40/70(554,555), 2x1-533TT(554,555), 2x3-324TT(551,553), 1x3-305 Menon ASWRL, 2dct; SPS-6, SG-6B, MLT-4(554,555), SPQ-2(551,553), RTN-7X(551), 2x RTN-7X(553) radars, SQS-11A, SQS-36(551,553) sonars
F553 Castore 1957
F554 Centauro 1957
F555 Cigno 1957
Carlo Bergamini 4 F593 Carlo Bergamini 1962 1650t, 94.0x11.4x3.1m, 4d(2), 16000hp, 25kts, 163p; 3x1-76/62(593,596), 2x1-76/62(594,595), 2x3-324TT, 1x1-305 Menon ASWRL, 1 helicopter (AB-204)(593,596)(AB-212((594,595); SPS-12, SPQ-2, RTN-10X radars, SQS-40 sonar, SPR-A ECM
F594 Virgilio Fasan 1962
F595 Carlo Margottini 1962
F596 Luigi Rizzo 1961
Alpino 2 F580 Alpino 1968 2700t, 113.3x13.1x3.8m, 2gt+4d(2), 31800hp, 29kts, 263p; 6x1-76/62, 2x3-324TT, 1x1-305 Menon ASWRL, 2helicopters(AB-212); SPS-12, SPQ-2, RTN-30X, 3x RTN-10X radars, SQS-43, SQA-10 sonars, SPR-A ECM, 2x SCLAR DL
F581 Carabiniere 1968
FS Gabbiano 14 F547 Crisalide 1952 728t, 64.4x8.7x2.5m, 2d/em, 3500/300hp, 18/6kts, 110p; 1x2-40/60(549,571,578-579), (1x2+1x1)-40/60(547,548,561,564,566, 570,578), 2x2-40/60(565,569,572,575,579), 2x1-20/70(549,571), 2x1-450TT, 1x24-178 Hedgehog ASWRL(547-549,561,564-566,569-572,578,579), 4dct, 1dcr(565,569,572,575,579), 2dcr(547-549,561,564,566,570,571,578), SO-13(547-549,561,566,569-571), SPS-6(575,579), NSM-8(565,572,578) radar, QCU-2 sonar
F548 Farfalla 1953
F549 Bombarda 1951
F561 Ibis 1943
F564 Scimitarra 1943
F565 Sibilla 1943
F566 Gru 1943
F569 Chimera 1943
F570 Urania 1943
F571 Gabbiano 1942
F572 Flora 1943
F575 Cormorano 1943
F578 Baionetta 1943
F579 Sfinge 1943
Albatros 4 F542 Aquila 1956 950t, 76.3x9.7x2.8m, 2d, 5200hp, 19kts, 110p; 3x1-40/70, 2x3-324TT, 2x24-178 Hedgehog ASWRL, 2dct, 1dcr; SPQ-2 radar, QCU-2 sonar
F543 Albatros 1955
F544 Alcione 1955
F545 Airone 1955
Pietro de Cristofaro 4 F540 Pietro de Cristofaro 1965 1020t, 80.2x10.0x2.5m, 2d, 8400hp, 23kts, 131p; 2x1-76/62, 2x3-324TT, 1x1-305 Menon ASWRL; SPQ-2, RTN-10 radars, 2x SQS-36 sonars
F541 Umberto Grosso 1966
F546 Licio Visintini 1966
F550 Salvatore Todaro 1966
Vedetta 1 F597 Vedetta 1955 400t, 53.1x7.3x3.1m, 4d(2), 3240hp, 19kts, 62p; 2x1-40/60, 2x1-20/70, 1x24-178 Hedgehog ASWRL, 2dct, 1dcr; QCU-2 sonar

PATROL AND COASTAL COMBATANTS

PC Sentinella 1 P499 Fulmine 1956 340t, 49.7x6.6x2.1m, 4d(2), 9000hp, 30kts, 60p; 1x1-76/62, 1x2-40/60, 2-450TT, 2dct
PT MS11 2 P472, 473 MS472, 473 1942 64t, 28.0x4.3x1.6m, 3d, 4500hp, 33kts, 19p; 1x1-40/60, 2-450TT, 8dc, mines
MS51 2 P474, 481 MS474, 481 1943 66t, 28.0x4.3x1.6m, 3d, 4500hp, 33kts, 19p; 1x1-40/60, 2-450TT, mines
Higgins 5 P441-443, 452, 453 MAS441-443, 452, 453 1942 - 1943 48t, 24.0x6.1x1.6m, 3pe, 4500hp, 34kts, 11p; 1x1-40/60(442,452), 3x1-20/70, 2-450TT(442,452); SPS-21 radar
MC490 1 P490 Folgore 1955 190t, 39.4x5.8x1.7m, 4d, 10000hp, 36kts, 39p; 2x1-40/60, 2-533TT
MC491 2 P491 Lampo 1963 196t, 43.0x6.3x1.5m, 1gt+2d(3), 11700hp, 39kts, 33p; 2x1-40/70, 2-533TT; 3ST7-250 radar
P492 Baleno 1965
MC590 2 P493 Freccia 1965 205t, 46.1x7.2x1.6m, 1gt+2d(3), 11850hp, 40kts, 37p; 1x5 Sea Killer SSM(5)(494), 2x1-40/70(494), 3x1-40/70(493); RTN-150 radar
P494 Saetta 1966

MINE WARFARE SHIPS

MSO Aggressive 4 M5430 Salmone 1956 735t, 52.3x10.4x4.0m, 2d, 1600hp, 14kts, 70p; 1x1-40/60, acoustic, magnetic, mechanical sweeps; SPS-53 radar, UQS-1 sonar
M5431 Storione 1956
M5432 Sgombro 1957
M5433 Squalo 1957
MSB Adjutant 36 M5501 Abete 1953 400t, 44.3x8.1x2.1m, 2d, 1200hp, 13kts, 39p; 1x2-20/70, acoustic, magnetic, mechanical sweeps; SPS-53 radar, UQS-1 sonar
M5502 Acacia 1953
M5503 Betulla 1953
M5504 Castagno 1955
M5505 Cedro 1954
M5506 Cillegio 1953
M5507 Faggio 1953
M5508 Frassino 1953
M5509 Gelso 1953
M5510 Larice 1953
M5511 Noce 1954
M5512 Olmo 1954
M5513 Ontano 1954
M5514 Pino 1954
M5515 Pioppo 1954
M5516 Platano 1954
M5517 Quercia 1954
M5521 Bambù 1956
M5522 Ebano 1956
M5523 Mango 1956
M5524 Mogano 1957
M5525 Palma 1957
M5526 Rovere 1957
M5527 Sandalo 1957
M5531 Agave 1955
M5532 Alloro 1955
M5533 Edera 1955
M5534 Gaggia 1956
M5535 Gelsomino 1955
M5536 Giaggiolo 1956
M5537 Glicine 1956
M5538 Loto 1957
M5539 Mirto 1955
M5540 Timo 1956
M5541 Trifoglio 1955
M5542 Vischio 1956
M5519 Mandorlo 1960
MSI Ham 20 M5450 Aragosta 1957 188t, 32.5x6.4x1.8m, 2d, 1000hp, 15kts, 14p; 1x1-20/70, mechanical sweep; BX-732 radar
M5451 Arsella 1957
M5452 Astice 1957
M5453 Attinia 1957
M5454 Calamaro 1957
M5455 Conchiglia 1957
M5456 Dromia 1957
M5457 Gambero 1957
M5458 Granchio 1957
M5459 Mitilo 1957
M5460 Ostrica 1957
M5461 Paguro 1957
M5462 Pinna 1957
M5463 Polipo 1957
M5464 Porpora 1957
M5465 Riccio 1957
M5466 Scampo 1957
M5467 Seppia 1957
M5468 Tellina 1957
M5469 Totano 1957

AMPHIBIOUS

LST LST(2) 1 A5306 Anteo 1943 3640t, 100.0x15.2x4.3m, 2d, 1800hp, 12.1kts, 125p; (1x2+5x1)-40/60, 2x1-20/70; 20tanks, 163troops; SU radar
LSM Quarto 1 A5302 Quarto 1968 980t, 69.0x9.6x1.8m, 3d, 2300hp, 13kts; 2x2-40/70; 2 LCVP, tanks, troops; SPQ-2, RAN-3L radars
LPA Stromboli 1 A5329 Stromboli 1953 6160t, 102.0x14.0x7.0m, 3b,1gst, 3700hp, 13.5kts; 1x1-100/47, 4x1-40/60; 4 LCM, 1 LCVP, cargo, troops
Kenneth Whiting 1 A5314 Andrea Bafile 1944 12610t, 150.0x21.2x7.2m, 2b,1gst, 8500hp, 16.5kts, 58p; 2x1-127/38, 2helicopters (AB-212 ); RIBs, diving equipment; radar
LKA Vesuvio 1 A5330 Vesuvio 1955 6160t, 102.0x14.0x7.0m, 3b,1gst, 3700hp, 13.5kts; 1x1-100/47, 4x1-40/60; 4 LCM, 1 LCVP, cargo, troops
Etna 1 A5328 Etna 1944 13910t, 139.9x19.2x7.9m, 2b,1gst, 6000hp, 16.5kts, 404p; 2x2-40/60; 6 LCM(6), 2 LCM(3), 13 LCVP, 1 LCPL, 4900t of cargo, 78troops; SPS-6 radar
LPR Barnegat 1 A5301 Pietro Cavezzale 1943 2800t, 94.7x12.5x3.7m, 4dg,2em, 6080hp, 16kts, 200p; 1x1-76/50, 1x2-40/60, diving equipment, RIBs; SPS-6, Jason radars
LCU MZ-A 5 A5341 MTC1001 1942 239t, 47.0x6.5x1.0m, 3d, 450hp, 11kts, 13p; 1x1-76/40, 2x1-20/65; 200men
A5343 MTC1003 1942
A5344 MTC1004 1942
A5345 MTC1005 1942
A5346 MTC1006 1942
MZ-B 3 A5347 MTC1007 1943 279t, 46.5x6.5x1.0m, 3d, 450hp, 11kts, 13p; 1x1-76/40, 2x1-20/65; 200men
A5348 MTC1008 1943
A5349 MTC1009 1943
MFP-A,C 2 A5353 MTC1103 1943 220t, 47.0x6.5x1.5m, 3d, 390hp, 10.5kts, 21p; 1x1-37/83, 2x1-20/65; 3tanks
A5357 MTC1107 1942
MFP-DM 1 A5351 MTC1101 1945 256t, 49.8x8.6x1.4m, 3d, 390hp, 8kts, 21p; 1x1-37/83, 2x1-20/65; 3tanks
LCT(2) 3 A5331 MOC1201 1942 460t, 48.8x9.5x1.6m, 3d, 1380hp, 11kts, 12p; 2x1-20/70; 3tanks
A5337 MOC1207 1942
A5338 MOC1208 1942
LCT(3) 4 A5332 MOC1202 1942 640t, 58.5x9.5x1.7m, 2d, 1000hp, 10.5kts, 12p; 4x1-20/70; 5tanks
A5333 MOC1203 1942
A5334 MOC1204 1942
A5335 MOC1205 1942
LFR LCS(L)3 6 L9851 Alano 1944 387t, 48.2x7.2x1.7m, 8d(2), 2320hp, 15.5kts, 71p; (2x2+1x1)-40/60, 4x1-20/70, 10x1-127 Mk7 RL; SU radar
L9852 Bracco 1944
L9853 Mastino 1944
L9854 Molosso 1944
L9855 Segugio 1944
L9856 Spinone 1944
LC LCM(3) 20   MTM9901 - 9920 1942 - 1945 52t, 15.3x4.3x1.4m, 2d, 330hp, 8kts, 4p; 2x1-12.7; 1tank
LCM(6) 9   MTM9921 - 9929 1943 - 1945 56t, 17.1x4.3x1.2m, 2d, 450hp, 9kts, 5p; 2x1-12.7; 1tank
LCVP 20   MTP9701 - 9720 1943 - 1945 13t, 11.2x3.2x0.9m, 2d, 220hp, 8kts, 3p; 2x1-12.7; 36troops or 1light tank

COAST GUARD

PB CP228 3 CP228-230 No picture 1966 - 1967 No picture 15t, 13.4x4.8x1.3m, 2d, 900hp, 24kts, 7p
CP231 6 CP231-236 No picture 1966 - 1969 No picture 16t, 13.4x4.8x1.3m, 2d, 900hp, 26kts, 7p

CUSTOMS SERVICE

PB G70 2 G70, 71 Gabriele, Grasso 1966 - 1967 No picture 54t, 23.2x6.6x1.0m, 3d, 2500hp, 34.2kts, 11p; 1x1-12.7; SC-1210 radar
