Australia 01 January 1970
SUBMARINES
| SS | Oxley | 4 | 57 | Oxley | 1967 | |
2030/2410t, 88.5x8.1x5.6m, 2d/em, 3680/6000hp, 12/17kts, 64p, 230m; 8-533TT; type 1006 radar, type 187C, 197, 2007, BQQ-4 Micropuffs sonars |
| 59 | Otway | 1968 | |||||
| 70 | Ovens | 1969 | |||||
| 60 | Onslow | 1969 |
AIRCRAFT CARRIERS
| CVL | Magnificent mod. | 1 | 21 | Melbourne | 1955 |  |
19966t, 213.8x38.4x7.8m, 4b,2gst, 42000hp, 24kts, 1417p; (4x2+4x1)-40/60, 24aircraft(Sea Venom fighters, Gannet ASW planes, Wessex helicopters); type 3x 277Q, 293Q, 978, LW-02, ZW, SPN-35 radars, ECM |
PRINCIPAL SURFACE COMBATANTS
| DDG | Perth | 3 | 38 | Perth | 1965 |  |
4526t, 133.2x14.3x4.6m, 4b,2gst, 70000hp, 33kts, 350p; 1x1 Tartar SAM(40), 2x1 Ikara ASuM(26), 2x1-127/54, 2x3-324TT; SPS-4-, SPS-52B, SPS-10, 2x SPG-51C, SPG-53A radars, SQQ-23F sonar |
| 39 | Hobart | 1965 | |||||
| 41 | Brisbane | 1967 | |||||
| DD | Battle batch 3 | 2 | 37 | Tobruk | 1950 |  |
3450t, 115.5x12.5x4.7m, 2b,2gst, 50000hp, 35.7kts, 332p; 2x2-120/45(37), 1x2-120/45(59), (3x2+6x1)-40/60(37), 2x1-40/60(59), 2x5-533TT(37), 1x3-305 Squid ASWRL; type 262, 275, 277, 291, 293 radars, type 170, 174 sonars |
| 59 | Anzac | 1951 | |||||
| Daring | 3 | 08 | Vendetta | 1958 |  |
3600t, 118.9x13.1x4.1m, 2b,2gst, 54000hp, 34.7kts, 320p; 3x2-120/45, (2x2+2x1)-40/60(08,11), (1x2+2x1)-40/60(154), 1x5-533TT(08), 1x3-305 Squid ASWRL; type 275(08,11), 262, 293, 277(154), 291(154), 903(1954) radars, type 170, 174/177 sonars | |
| 11 | Vampire | 1959 | |||||
| 154 | Duchess | 1952 | |||||
| FF | Q | 3 | 02 | Queenborough | 1942 |  |
2850t, 109.2x10.9x4.3m, 2b,2gst, 40000hp, 36.7kts, 195p; 1x2-102/45, (1x2+3x1)-40/60, 2x3-305 Squid ASWRL(01), 2x3-305 Limbo ASWRL(02-04); type 262, 278, 293 radars, type 170, 174 sonars |
| 03 | Quiberon | 1942 | |||||
| 04 | Quickmatch | 1942 | |||||
| River | 3 | 174 | Barcoo | 1944 |  |
2180t, 91.8x11.2x3.9m, 2b,2vte, 5500hp, 20kts, 140p; 1x2-102/45, 1x1-40/60(174,363), 2x3-305 Squid ASWRL, 8dct, 2dcr; type 272, 275(174,363), 291 radars, sonars | |
| 363 | Hawkesbury | 1944 | |||||
| 532 | Macquarie | 1945 | |||||
| River modified | 1 | 408 | Culgoa | 1947 |  |
2187t, 91.7x11.1x3.9m, 2b,2vte, 5500hp, 19kts, 177p; 2x2-102/45, 3x1-40/60, 2x2-20/70, 1x24-178 Hedgehog ASWRL, 4dct, 2dcr; type 275, 277, 291 radars, sonars | |
| Yarrra | 2 | 45 | Yarra | 1961 |  |
2560t, 112.7x12.5x3.9m, 2b,2gst, 30000hp, 29kts, 231p; 1x4 SeaCat GWS22 SAM(24), 1x1 Ikara ASuM(30), 1x2-120/45, 1x3-305 Limbo ASWRL; type 275, 293, 277, 978, LW-02 radars, type 162, 170, 177M, 185 sonars | |
| 46 | Parramatta | 1961 | |||||
| Stuart | 2 | 48 | Stuart | 1963 |  |
2560t, 112.7x12.5x3.9m, 2b,2gst, 30000hp, 29kts, 235p; 1x4 SeaCat GWS22 SAM(24), 1x1 Ikara ASuM(30), 1x2-120/45, 1x3-305 Limbo ASWRL, type 975, 974, 977, 293, 978, 904, 994 radars, type 162, 170, 177M, 185 sonars | |
| 49 | Derwent | 1964 |
PATROL AND COASTAL COMBATANTS
| PB | HDML | 3 | 1321, 1324, 1325 | SDML1321,1324,1325 | 1943 - 1944 |  |
54t, 22.0x4.8x1.4m, 2d, 300hp, 11.5kts, 10p; 2x1-20/70, 8dc; type 291 radar |
| Attack | 20 | 90 | Attack | 1968 |  |
146t, 32.8x6.1x2.1m, 2d, 3500hp, 21-24kts, 19p; 1x1-40/60, 2x1-12.7; RM916 radar | |
| 81 | Acute | 1968 | |||||
| 82 | Adroit | 1968 | |||||
| 83 | Advance | 1968 | |||||
| 84 | Aitape | 1967 | |||||
| 85 | Samarai | 1968 | |||||
| 86 | Archer | 1968 | |||||
| 87 | Ardent | 1968 | |||||
| 88 | Arrow | 1968 | |||||
| 89 | Assail | 1968 | |||||
| 91 | Aware | 1968 | |||||
| 92 | Ladava | 1967 | |||||
| 93 | Lae | 1968 | |||||
| 94 | Madang | 1968 | |||||
| 95 | Bandolier | 1968 | |||||
| 97 | Barbette | 1968 | |||||
| 98 | Barricade | 1968 | |||||
| 99 | Bombard | 1968 | |||||
| 100 | Buccaneer | 1969 | |||||
| 101 | Bayonet | 1969 |
AMPHIBIOUS SHIPS AND CRAFT
| CVL-AP-AK | Magnificent | 1 | R17 | Sydney | 1949 |  |
17780t, 211.8x24.4x7.0m, 4b,2gst, 40000hp, 25kts, 1300p; 4x1-40/60; 6 LCPU, vehicles, troops, helicopters; 2x type 277Q, 293M, 960/281BQ, 961 radars |
| LC | LCM(8) | 12 | AB1050 | Coconut Queen | 1967 |  |
116t, 22.7x6.4x1.4m, 4d(2), 600hp, 11kts, 3p; 55t of cargo |
| AB1051 | 1967 | ||||||
| AB1052 | 1967 | ||||||
| AB1053 | Sea Widow | 1967 | |||||
| AB1054 | 1967 | ||||||
| AB1055 | 1967 | ||||||
| AB1056 | 1967 | ||||||
| AB1057 | 1967 | ||||||
| AB1058 | 1967 | ||||||
| AB1059 | 1967 | ||||||
| AB1060 | 1967 | ||||||
| AB1061 | 1967 |
MINE WARFARE SHIPS
| MCH | Ton | 1 | M1121 | Curlew | 1954 |  |
425t, 46.3x8.8x2.5m, 2d, 3000hp, 15kts, 29p; 1x1-40/60, diving equipment; type 978 radar, type 193 sonar |
| MSC | Ton | 5 | M1102 | Snipe | 1954 |  |
425t, 46.3x8.8x2.5m, 2d, 3000hp, 15kts, 29p; 2x1-40/60, mechanical sweeps; type 978 radar |
| M1139 | Hawk | 1955 | |||||
| M1152 | Teal | 1955 | |||||
| M1183 | Ibis | 1956 | |||||
| M1185 | Gull | 1955 |
