World navies yesterday

1965



Thailand 01 January 1965

PRINCIPAL SURFACE COMBATANTS

FF Tachin 1 1 Meklong 1937 2000t, 82.0x10.4x3.1m, 2b,2vte, 2500hp, 17kts, 155p; 4x1-120/45, 2x1-40/60, 2x1-20/65, 2x2-450TT, mines, sweeps
Tacoma 2 1 Tachin 1943 2238t, 92.6x11.4x3.9m, 3b,2vte, 5500hp, 20kts, 190p; 3x1-76/50, 1x2-40/60, 9x1-20/70, 1x24-178 Hedgehog ASWRL, 8dct, 2dcr; SPS-5(1), SPS-6, SPS-10(2), Mk51 radars, sonar
2 Prasae 1944
Cannon 1 3 Pin Clao 1944 1602t, 93.3x11.2x3.2m, 4dg,2em, 6000hp, 21kts, 186p; 3x1-76/50, 3x2-40/60, 6x1-20/70, 1x24-178 Hedgehog ASWRL, 8dct, 2dcr; SC, SPS-5, Mk52, 2x Mk63 radars, SQS-11 sonar
FS Trad 7 11 Trad 1936 470t, 68.0x6.4x2.1m, 2b,2gst, 9000hp, 31kts, 70p; 3x1-76/40, 2x1-20/65, (2x2+2x1)-450TT
12 Puket 1936
13 Patani 1938
21 Surasdra 1938
22 Chandraburi 1938
23 Rayong 1938
31 Chunphorn 1938
Hunt 1 1 Chao Phraya 1919 840t, 70.4x8.7x2.2m, 2b,2vte, 2200hp, 16kts, 65p; 2x1-76/40, 1x1-40/39
Flower mod. 1 4 Bangpakong 1943 1370t, 62.5x10.1x4.4m, 2b,1vte, 2750hp, 16.5kts, 109p; 1x1-102/45, (1x2+2x1)-20/70, 1x24-178 Hedgehog ASWRL, 4dct, 2dcr; type 276, 291 radars, sonar

PATROL AND COASTAL COMBATANTS

PS Ratanakosindra 2 1 Ratanakosindra 1925 1000t, 53.0x11.3x3.3m, 2b,2vte, 850hp, 12kts, 102p; 2x1-152/50, 4x1-76/40, 4x1-40/39
2 Sukhotai 1930
PC PC 173' 7 1 Sarasin 1942 463t, 52.9x7.1x3.3m, 2d, 2880hp, 19kts, 65p; 1x1-76/50, 1x1-40/60, 5x1-20/70, 2x4-178 Mousetrap ASWRL, 2dct, 2dcr; SO radar, QCU-2 sonar
2 Thayanchon 1942
4 Phali 1944
5 Sukrip 1944
6 Tongpliu 1942
7 Liulom 1943
8 Longlom 1942
PT Klongyai 4 5 Klongyai 1937 135t, 42.0x4.6x1.5m, 2b,2gst, 1000hp, 19kts, 31p; 1x1-76/40, 2x1-20/65, 1x2-450TT
6 Takbai 1937
7 Kantang 1937
8 Sattahip 1958
PB Sarasindhu 2 2 Thiew Uthock 1936 50t, 21.9x3.9x1.0m, 2d, 150hp, 9kts; 1x1-20/70
3 Travane Vari 1936
CG 83' 2 11, 12   1953 63t, 25.3x4.3x1.6m, 2d, 1100hp, 18kts; 1x1-20/70, 2x4-178 Mousetrap ASWRL; radar, sonar
CG 95' 4 13   1954 105t, 29.0x5.8x1.6m, 4d(2), 2200hp, 18kts, 15p; 1x1-20/70, 2x4-178 Mousetrap ASWRL, 2dcr; SPN-21 radar, QCU sonar
14   1954
15   1954
16   1954
SC 110' 2 31   1955 125t, 33.9x5.2x1.8m, 2d, 18kts; 1x1-40/60, 3x1-20/70, 2x4-178 Mousetrap ASWRL, 2dct, 2dcr
32   1955

AMPHIBIOUS

LST LST1 2 1 Angthong 1944 4080t, 100.0x15.2x4.3m, 2d, 1800hp, 12.1kts, 125p; (1x2+5x1)-40/60(1), (2x2+4x1)-40/60(2), 12x1-20/70(1), 4x1-20/70(2); 20tanks, 163troops; SO-8(1), SPS-5(2) radar
2 Chang 1944
LSM LSM1 3 1 Kut 1944 1095t, 62.0x10.5x2.1m, 2d, 2800hp, 13kts, 60p; 1x2-40/60, 4x1-20/70; 5tanks, 54troops; SO-8 radar
2 Phai 1945
3 Kram 1945
LCU LCT(6) 6 8 Mataphon 1944 320t, 36.3x10.0x1.2m, 3d, 675hp, 8kts, 13p; 2x1-20/70; 4tanks
9 Rawi 1944
10 Adang 1944
11 Phetra 1944
12 Khorum 1944
13 Talibong 1944
LCI(L) 2 1 Prab 1944 385t, 48.9x7.2x1.6m, 8d(2), 2320hp, 15.5kts, 29p; 2x1-20/70; 209troops; SO radar
2 Sattakut 1944
LC LCVP 12 51-59, 510-512 L51-59, 510-512 1943-1945 13t, 11.2x3.2x0.9m, 2d, 300hp, 8kts, 3p; 2x1-12.7; 36troops

MINE WARFARE

ML Bangrachan 2 1 Bangrachan 1936 408t, 50.0ppx7.7x2.2m, 2d, 540hp, 13kts, 55p; 2x1-76/40, 2x1-20/70, 142mines
2 Nangsarai 1937
MSO Algerine VTE 1 1 Phosamton 1945 1335t, 68.6x10.8x3.3m, 2b,2vte, 2400hp, 16kts, 138p; 1x1-102/45, 3x1-20/70, 2dct, 2dcr, sweeps; radar, sonar
MSC YMS 1 4 Ta Din Daeng 1943 320t, 41.5x7.5x2.4m, 2d, 800hp, 14kts, 60p; 1x1-76/50, 2x1-20/70, 2dct, 2dcr, sweeps; SO radar
Bluebird 1 5 Ladya 1963 400t, 44.3x8.1x2.1m, 4d(2), 1000hp, 13kts, 43p; 1x2-20/70, sweeps; SPS-53 radar, UQS-1D sonar
MSB M1 5 1-5 M1-5 1945 No picture 30t, 17.0x5.3x1.4m, 2d, 10kts, 7p; 1x1-12.7, sweeps
M6 5 6-10 M6-10 1963-1964 No picture 21t, 15.3x4.0x1.3m, 1d, 85hp, 8kts, 6p; sweeps
