World navies yesterday

1965



Taiwan 01 January 1965

PRINCIPAL SURFACE COMBATANTS

DD Kagero 1 DD12 Tanyang 1940 2600t, 118.5x10.8x3.8m, 3b,2gst, 52000hp, 35kts, 240p; 3x1-127/38, 2x1-76/50, 8x1-40/60, 4dct; SC-2 radar
Benson 2 DD14 Loyang 1940 2591t, 106.2x11.0x4.0m, 4b,2gst, 50000hp, 35kts, 208p; 4x1-127/38, 2x2-40/60, 4x1-20/70, 1x5-533TT, 6dct, 2dcr; SC, Mk 4 radars, sonar
DD15 Hanyang 1940
Gleaves 1 DD17 Nanyang 1940 2572t, 106.2x11.0x4.0m, 4b,2gst, 50000hp, 35kts, 208p; 4x1-127/38, (2x4+2x2)-40/60, 2x2-20/70, 6dct, 2dcr; SC, Mk4 radars, sonar
Bristol 1 DD16 Hsienyang 1942 2600t, 106.2x11.0x4.9m, 4b,2gst, 50000hp, 35kts, 208p; 3x1-127/38, 2x2-40/60, 7x1-20/70, 2dct, 2dcr, mechanical minesweeping gear; SC, Mk4 radars, sonar
FF Evarts 1 DE21 Taikang 1943 1416t, 88.7x10.7x3.1m, 4dg,2em, 6000hp, 19.5kts, 156p; 4x1-76/50, 1x2-40/60, 10x1-20/70, 8dct, 2dcr; SA, SF radars, sonar
Cannon 4 DE23 Taiho 1943 1602t, 93.3x11.2x3.2m, 4dg,2em, 6000hp, 21kts, 186p; 2x1-127/38, (2x2+4x1)-40/60, 4x1-20/70, 2x3-324TT, 1x24-178 Hedgehog ASWRL, 2dcr; SA, SF radars, sonar
DE24 Taihu 1943
DE25 Taitsang 1943
DE26 Taichao 1944
Castle 1 PF81 Tean 1944 1630t, 76.8x11.2x4.2m, 2b,1vte, 2750hp, 16.5kts, 120p; 1x1-120/45, 1x1-76/40, 2x2-40/60; radar
APD 1 APD215 Tienshan 1945 2130t, 93.3x11.3x3.8m, 2b,2stg,2em, 12000hp, 23.6kts, 203p; 1x1-127/38, 3x2-40/60, 4x1-20/70, 2x3-324TT, 2dcr; 4 LCVP, 162troops; SPS-5 radar, sonar

PATROL AND COASTAL COMBATANTS

PS PCE 2 PCE62 Shanhai 1943 903t, 56.2x10.1x2.9m, 2d, 2000hp, 15.1kts, 96p; 2x1-76/50, 2x2-40/60, 2x1-20/70; SF radar
PCE68 Weiyuan 1943
Admirable 8 PCE43 Yongsheng 1943 945t, 56.2x10.1x3.0m, 2d, 2000hp, 15.1kts, 96p; 2x1-76/50, 2x2-40/60, 2x1-20/70; radar
PCE44 Yongshun 1943
MSF45 Yongding 1943
MSF47 Yongjia 1944
MSF48 Yongxiu 1944
PCE49 Yongshou 1944
MSF50 Yongfeng 1944
PCE51 Yongchang 1945
Auk 2 PCE45 Jianmen 1944 1250t, 67.4x9.8x3.3m, 2dg,2em, 2880hp, 18kts, 80p; 2x1-76/50, 2x2-40/60, 2x2-20/70, 2x3-324TT, 1x24-178 Hedgehog ASWRL, 2dcr; SPS-5 radar, SQS-17 sonar
PCE66 Wusheng 1945
PT PT1 2 PTC11   1957 No picture 40t, 21.6x6.1xm, 3pe, 40kts, 12p; 1x1-40/60, 1x2-20/70, 2-450TT
  PTC12   1957
Vosper 70ft 2 PTC32   1957 46t, 21.6x5.8x1.5m, 3pe, 42kts, 12p; 1x1-20/70, 2x2-12.7, 2-450TT
PTC33   1957
ELCO 80ft 2 PTC34   1957 53t, 24.1x7.1x1.7m, 3pe, 39kts, 12p; 1x1-40/60, 2x1-12.7, 2-450TT
PTC35   1957
PC PC 173ft 15 PC105 Peijiang 1942 463t, 52.9x7.1x3.3m, 2d, 2880hp, 19kts, 65p; 1x1-76/50, 1x1-40/60, 4x1-20/70, 2x4-178 Mousetrap ASWRL, 2dct, 2dcr; radar, sonar
PC108 Xianjiang 1943
PC109 Zijiang 1943
PC110 Yuanjiang 1943
PC111 Lijiang 1943
PC113 Gongjiang 1943
PC114 Bojiang 1943
PC115 Changjiang 1943
PC116 Qingjiang 1943
PC118 Zhangjiang 1943
PC119 Dongjiang 1944
PC120 Xijiang 1944
PC122 Beijiang 1944
PC124 Ganjiang 1943
PC125 Tuojiang 1943
PGM 173ft 1 PC117 Zhujiang 1945 463t, 52.9x7.1x3.3m, 2d, 2880hp, 19kts, 65p; 1x1-76/50, 1x2-40/60, 6x1-20/70, 1x2-60/12 mortar, 2x1-12.7; radar
PB HDML 6 1, 2, 4-7 Fang 1,, 2, 4-7 1941-1944 54t, 22.0x4.8x1.4m, 2d, 300hp, 11.8kts, 10p; 2x1-20/70, 2dcr
SC 8 SC102 Chuchien 102 1942 136t, 33.8x5.5x2.0m, 2d, 1000hp, 16kts, 27p; 1x1-40/60, 3x1-20/70, 2x4-178 Mousetrap ASWRL, 2dct, 2dcr; radar, QC sonar
SC103 Chuchien 103 1942
4   1942
5   1942
6   1943
7   1942
8   1942
9   1943
PTC38 1 PTC38   1962 No picture 30t, 21kts; 1x1-40/60, 1x1-20/70; radar

AMPHIBIOUS

LCC LST(2) 19 LCC1 Gaoxiong 1944 4080t, 1000x15.2x4.3m, 2d, 1800hp, 12.1kts, 125p; (2x2+2x1)-40/60, 2x1-20/70, 4x1-12.7; SPS-10, SPS-12 radars
LSD Ashland 1 LSD191 Donghai 1944 9375t, 139.5x22.0x4.8m, 2b,2qpe, 7400hp, 15.4kts, 254p; (2x4+2x2)-40/60; 3 LCT(6) or 14 LCM(3), 332troops; SPS-5, nav. radars
LST LST(2) 18 LST201 Zhonghai 1944 4080t, 1000x15.2x4.3m, 2d, 1800hp, 12.1kts, 125p; (2x2+6x1)-40/60, 12x1-20/70; 4 LCVP, 20tanks, 163troops; SO radar
LST203 Zhongding 1944
LST204 Zhongxing 1944
LST205 Zhongjian 1944
LST206 Zhongji 1944
LST208 Zhongxun 1944
LST209 Zhonglian 1945
LST210 Zhongrong 1944
LST216 Zhongguang 1943
LST217 Zhongzhao 1943
LST218 Zhongqi 1943
LST221 Zhongquan 1944
LST222 Zhongsheng 1944
LST223 Zhongfu 1944
LST224 Zhongcheng 1945
LST225 Zhongqiang 1945
LST226 Zhongzhi 1945
LST227 Zhongming 1945
LST228 Zhongsu 1944
LST229 Zhongwang 1944
LST230 Zhongbang 1944
LST231 Zhongye 1945
LSM LSM1 12 LSM341 Meizhen 1944 1095t, 62.0x10.5x2.1m, 2d, 2800hp, 13kts, 60p; 1x2-40/60, 4x1-20/70; 5tanks, 54troops; SO radar
LSM343 Meiyi 1944
LSM344 Meipeng 1945
LSM345 Meiheng 1945
LSM347 Meisong 1945
LSM349 Meijian 1944
LSM350 Meihua 1944
LSM351 Meicheng 1944
LSM352 Meigong 1945
LSM353 Meiping 1945
LSM354 Meiwei 1945
LSM355 Meihan 1945
LSS LCI(L) 6 LCI261 Lianzhu 1943 385t, 48.9x7.2x1.6m, 8d(2), 2320hp, 15.5kts, 29p; 5x1-20/70; 209troops; SO radar
LCI262 Lianli 1944
LCI263 Lianshen 1944
LCI264 Lianhua 1944
LCI265 Lianzhen 1944
LCI266 Lianqiang 1944
LCT(6) 17 LCU481 Hequn 1944 320t, 36.3x10.0x1.2m, 3d, 675hp, 8kts, 13p; 2x1-20/70; 4tanks
LCU482 Hezhong 1944
LCU483 Hecheng 1944
LCU484 Hezhong 1944
LCU485 Hezhang 1943
LCU486 Hezhen 1944
LCU487 Hezhi 1944
LCU494 Hechun 1944
LCU495 Heyong 1944
LCU496 Hejian 1944
LCU401 Heqi 1944
LCU402 Hehui 1944
LCU403 Heyao 1944
LCU404 Hedeng 1944
LCU405 Hefeng 1944
LCU406 Hechao 1944
LCU407 Heteng 1944
Heshan 6 LCU488 Heshan 1955 360t, 36.3x10.4x1.8m, 3d, 675hp, 10kts, 15p; 3x1-20/70; 3tanks; radar
LCU489 Hechuan 1955
LCU490 Hesheng 1955
LCU491 Heheng 1955
LCU492 Hemao 1955
LCU493 Heshou 1955
LC LCVP 100 1-100   1943-1945 13t, 11.2x3.2x0.9m, 2d, 220hp, 8kts, 3p; 2x1-12.7; 36troops
LCM(3) 2 1, 2   1942-1944 52t, 15.3x4.3x1.4m, 2d, 330hp, 8kts, 4p; 2x1-12.7; 1tank
LCM(6) 50 1-50   1962-1964 62t, 17.1x4.4x1.5m, 2d, 450hp, 9kts, 9p; 2x1-12.7; 1tank
LCF LCS(L) 3 LCI271 Lianzhi 1944 387t, 48.2x7.2x1.7m, 8d(2), 2320hp, 15.5kts, 71p; (2x2+1x1)-40/60(271,272), 3x2-40/60(273), 4x1-20/70, 10x1-127 RL; radar
LCI272 Lianren 1944
LCI273 Lianyong 1945

MINE WARFARE

ML LSM1 1 CMC348 Meihe 1944 1095t, 62.0x10.5x2.1m, 2d, 2800hp, 13kts, 60p; 1x2-40/60, 4x1-20/70, mines; SO radar
MSC Bluebird 4 MSC155 Yungping 1954 400(155,156)-390(157,158)t, 44.3x8.1x2.1m, 2d, 1200(155,156)-880(157,158)hp, 13kts, 39p; 1x2-20/70, mechanical, acoustic, magnetic minesweeping gear; SPS-53 radar, UQS-1 sonar
MSC156 Yungan 1954
MSC157 Yungnien 1959
MSC158 Yungchou 1959
MSB MSML 12 MSML1-12   1943-1945 No picture 24t, 15.3x4.0x1.3m, 1d, 60hp, 8kts, 4p; mechanical minesweeping gear
MSB1 1 MSB12   1945 42t, 17.5x4.8x1.3m, 2d, 300hp, 12kts, 6p; mechanical minesweeping gear
