Norway 01 January 1965
SUBMARINES
| SS | V | 1 | S304 | Uthaug | 1944 | |
662/740t, 62.3x4.9x4.7m, 2dg,2em, 615/825hp, 11.2/10kts, 33p, 90m; 1x1-76/45, 2x1-20/70, 4-533TT; type 267QW radar, sonars |
| Kobben | 4 | S316 | Kinn | 1964 | |
435/482t, 45.4x4.6x4.3m, 2dg,1em, 1200/1700hp, 13.5/17kts, 17p, 190m; 8-533TT; Calypso II radar, sonar, ECM, MSI-70U CCS | |
| S317 | Kya | 1964 | |||||
| S318 | Kobben | 1964 | |||||
| S319 | Kunna | 1964 |
PRINCIPAL SURFACE COMBATANTS
| DD | Cr | 4 | D303 | Oslo | 1947 |  |
2535t, 110.6x10.9x4.4m, 2b,2gst, 40000hp, 36.7kts, 186p; 4x1-114/45, 1x2-40/60, (2x2+2x1)-20/70, 1x4-533TT, 2dct, 2dcr; type 275, 277, 282, 291 radars, type 123, 127 sonars |
| D304 | Bergen | 1946 | |||||
| D305 | Trondheim | 1945 | |||||
| D306 | Stavanger | 1946 | |||||
| FF | Hunt 2 | 2 | F311 | Tromsø | 1942 |  |
1625t, 85.3x9.6x3.8m, 2b,2gst, 19000hp, 27kts, 168p; 2x2-102/45, 2x2-40/60, 2x3-305 Squid ASWRL, 2dct, 3dcr; type 271, 285, 291 radars, type 123A, 127 sonars |
| F312 | Haugesund | 1941 | |||||
| Canadian River | 2 | F313 | Draug | 1944 |  |
2360t, 91.8x11.2x4.9m, 2b,2vte, 5500hp, 20kts, 140p; 1x2-102/45, (1x2+4x1)-40/60, 2x3-305 Squid ASWRL; SU, SPQ-2, type 275, 262 radars, type 147, 162, 164B sonars, TDY-1 ECM | |
| F314 | Troll | 1944 | |||||
| FT | Barnegat | 1 | A537 | Haakon VII | 1945 |  |
2800t, 94.7x12.5x3.8m, 4dg,2em, 6080hp, 20kts, 215+86p; 1x1-127/38, (1x4+2x2)-40/60, 4x1-20/70, 2dct, 2dcr; radars, sonar |
PATROL AND COASTAL COMBATANTS
| PT | ELCO 80ft | 4 | P955 | Springer | 1945 |  |
61t, 24.4x6.3x1.6m, 3pe, 4500hp, 43kts, 17p; 1x1-40/60, 1x1-20/70, 2x2-12.7, 2-533TT; radar |
| P956 | Hai | 1945 | |||||
| P957 | Laks | 1945 | |||||
| P958 | Hval | 1945 | |||||
| Rapp | 6 | P351 | Rapp | 1952 |  |
72t, 26.5x7.0x1.5m, 4pe, 4800hp, 41kts, 18p; 1x1-40/60, 1x1-20/70, 4-533TT; radar | |
| P352 | Rask | 1953 | |||||
| P353 | Kvikk | 1954 | |||||
| P354 | Kjapp | 1955 | |||||
| P355 | Snar | 1955 | |||||
| P356 | Snøgg | 1955 | |||||
| Nasty | 1 | Nasty | 1958 |  |
76t, 24.5x7.5x2.1m, 2d, 5000hp, 43kts, 22p; 2x1-40/60, 4-533TT; radar | ||
| Tjeld | 16 | P343 | Tjeld | 1960 |  |
76t, 24.5x7.5x2.1m, 2d, 6200hp, 45kts, 22p; 1x1-40/60, 1x1-20/70, 4-533TT; Decca 1226 radar | |
| P344 | Skarv | 1960 | |||||
| P345 | Teist | 1960 | |||||
| P346 | Jo | 1961 | |||||
| P347 | Lom | 1961 | |||||
| P348 | Stegg | 1961 | |||||
| P349 | Hauk | 1961 | |||||
| P350 | Falk | 1961 | |||||
| P357 | Ravn | 1961 | |||||
| P381 | Hai | 1964 | |||||
| P382 | Sel | 1963 | |||||
| P383 | Hval | 1964 | |||||
| P384 | Laks | 1964 | |||||
| P388 | Gribb | 1962 | |||||
| P389 | Geir | 1962 | |||||
| P390 | Erle | 1962 | |||||
| PG | Storm | 1 | P960 | Storm | 1963 |  |
125t, 36.6x6.2x1.5m, 2d, 7200hp, 37kts, 19p; 1x1-76/50, 1x1-40/70; Decca 909, WM26 radars |
AMPHIBIOUS
| LCU | LCU1476 | 1 | A30 | Tjeldsund | 1953 |  |
347t, 35.1x10.4x1.6m, 3d, 675hp, 8kts, 14p; 2x1-20/70; 4tanks |
MINE WARFARE
| ML | LCT(4) | 2 | N35 | Vargsund | 1945 |  |
640t, 57.1x11.8x1.4m, 2d, 920hp, 10kts, 12p; 2x1-20/70, 80mines |
| N36 | Reinøsund | 1945 | |||||
| Auk | 4 | N47 | Tyr | 1942 |  |
1250t, 67.4x9.8x3.4m, 2dg,2em, 2070hp, 16kts, 83p; 1x1-76/50, 1x1-40/60(50), 2x2-20/70(47-49), 2x24-178 Hedgehog ASWRL(47-49), 1x6-375 Terne III ASWRL(50), 3dct, 80mines; radar, sonar(47-49), Terne III(50) sonar | |
| N48 | Gor | 1942 | |||||
| N49 | Brage | 1944 | |||||
| N50 | Uller | 1942 | |||||
| Borgen | 1 | N51 | Borgen | 1960 |  |
282t, 31.3x8.0x3.4m, 2d(2vs), 660hp, 9kts; 1x1-20/70, 10mines; radar | |
| MSO | Aggressive | 2 | M950 | Lågen | 1955 |  |
735t, 52.3x10.4x4.0m, 4d(2), 2280hp, 14kts, 70p; 1x1-40/60, 2x1-12.7, sweeps; SPS-53 radar, UQS-1 sonar |
| M951 | Namsen | 1955 | |||||
| MSC | Bluebird | 7 | M311 | Sauda | 1953 |  |
400t, 44.3x8.1x2.1m, 2d, 880hp, 12kts, 39p; 1x2-20/70, sweeps; Decca RM707 radar, UQS-1 sonar |
| M312 | Sira | 1955 | |||||
| M315 | Ogna | 1955 | |||||
| M316 | Vosso | 1955 | |||||
| M331 | Tista | 1955 | |||||
| M332 | Kvina | 1955 | |||||
| M334 | Utla | 1955 |
COAST GUARD
| PSO | Nornen | 1 | W300 | Nornen | 1963 |  |
1060t, 61.5x10.0x4.8m, 4d(2), 3500hp, 17kts, 32p; 1x1-76/50, helodeck; radar, sonar |
| Farm | 2 | W301 | Farm | 1962 |  |
600brt, 54.3x8.2x4.9m, 2d(1), 2400hp, 16kts, 29p; 1x1-76/50; radar, sonar | |
| W302 | Heimdal | 1962 | |||||
| Andenes | 3 | W303 | Andenes | 1957 |  |
750t, 56.8x9.3x4.8m, 1d, 2300hp, 16kts, 29p; 1x1-76/50; radar, sonar | |
| W304 | Senja | 1957 | |||||
| W305 | Nordkapp | 1957 |
