Mexico 01 January 1965
PRINCIPAL SURFACE COMBATANTS
FF | APD | 4 | H3 | California | 1945 | 2130t, 93.3x11.3x3.8m, 2b,2stg,2em, 12000hp, 20kts, 204p; 1x1-127/38, 3x2-40/60, 6x1-20/70; 4LCVP, 162troops; SC radar | |
H4 | Papaloapan | 1945 | |||||
H5 | Tehuantepec | 1945 | |||||
H6 | Usumacinta | 1945 | |||||
Guanajuato | 3 | C7 | Guanajuato | 1936 | 1950t, 80.4x11.5x3.1m, 2d, 5000hp, 14kts, 140p; 1x1-102/45, 2x1-20/70, 2x2-13.2, 2dct; 230troops, 40horses; radar | ||
C8 | Querétaro | 1936 | |||||
C9 | Potosi | 1936 | |||||
Durango | 1 | B1 | Durango | 1936 | 2000t, 92.4x12.2x3.1m, 2b,2gst, 6500hp, 20kts, 141p; 2x1-102/45, 2x1-57/40, 3x1-20/70, 2x2-13.2, 2dct; 490troops, 80horses; radar |
PATROL AND COASTAL COMBATANTS
PS | PCE | 5 | 1 | Pedro Sainz de Baranda | 1944 | 903t, 56.2x10.1x2.9m, 2d, 2000hp, 15.1kts, 96p; 1x1-76/50, 3x2-40/60(1-3,5), 3x1-40/60(4), 4x1-20/70(1,2,5), 5x1-20/70(4), 4dct; radar, sonar | |
2 | David Porter | 1944 | |||||
3 | Virgilio Uribe | 1943 | |||||
4 | Blas Godínez | 1943 | |||||
5 | Tomás Marín | 1944 | |||||
Admirable | 20 | D1 | DM01 | 1943 | 945t, 56.2x10.1x3.0m, 2d, 2000hp, 15kts, 96p; 1x1-76/50, 2x2-40/60, 4x2-20/70; SO, SPS-5 radars | ||
D2 | DM02 | 1944 | |||||
D3 | DM03 | 1944 | |||||
D4 | DM04 | 1944 | |||||
D5 | DM05 | 1944 | |||||
D6 | DM06 | 1944 | |||||
D7 | DM07 | 1944 | |||||
D8 | DM08 | 1944 | |||||
D9 | DM09 | 1944 | |||||
D10 | DM10 | 1944 | |||||
D11 | DM11 | 1944 | |||||
D12 | DM12 | 1944 | |||||
D13 | DM13 | 1943 | |||||
D14 | DM14 | 1944 | |||||
D15 | DM15 | 1944 | |||||
D16 | DM16 | 1944 | |||||
D17 | DM17 | 1944 | |||||
D18 | DM18 | 1944 | |||||
D19 | DM19 | 1944 | |||||
D20 | DM20 | 1945 | |||||
PC | G20 | 1 | G28 | GC28 | 1936 | 180t, 46.6x5.0x1.6m, 2d, 3000hp, 26kts, 21p; 3x1-20/70, 2x2-12.7, 2dct | |
PC | 5 | G30 | GC30 | 1943 | 463t, 52.9x7.1x3.3m, 2d, 2880hp, 19kts, 65p; 1x1-76/50, 1x1-40/60, 5x1-20/70, 2x4-178 Mousetrap ASWRL, 2dct, 2dcr; SO radar, sonar | ||
G33 | GC33 | 1945 | |||||
G35 | GC35 | 1944 | |||||
G37 | GC37 | 1943 | |||||
G38 | GC38 | 1944 |
