World navies yesterday

1950

Sweden 01 January 1950

SUBMARINES

SS	Delfinen	3	Del	Delfinen	1936		540/720t, 63.1x6.4x3.4m, 2d/em, 1200/800hp, 15/9kts, 34p, 60m; 1x1-57/55, 1x1-25/58, 4-533TT, 20mines
			Nkp	Nordkaperen	1936
			Spr	Springaren	1937
	Sjölejonet	9	Sle	Sjölejonet	1938		580/760t, 64.2x6.4x3.4m, 2d/em, 2100/1000hp, 16.2/10kts, 38p, 60m; 2x1-40/43, (4+1x2)-533TT
			Sbj	Sjöbjörnen	1939
			Shu	Sjöhunden	1939
			Sf	Svärdfisken	1941
			Tu	Tumlaren	1941
			Dy	Dykaren	1941
			Shä	Sjöhästen	1941
			Sor	Sjöormen	1941
			Sbo	Sjöborren	1942
	U1	9	U1	U1	1942		367/450t, 49.6x4.7x3.8m, 1dg/2em(2), 1350/hp, 13.8/7.5kts, 23p, 60m; 1x1-20/66, 4-533TT
			U2	U2	1943
			U3	U3	1943
			U4	U4	1944
			U5	U5	1944
			U6	U6	1944
			U7	U7	1944
			U8	U8	1944
			U9	U9	1944
	Neptun	3	Np	Neptun	1943		550/730t, 62.6x6.4x3.4m, 2d/em, 1800/1000hp, 15/10kts, 35p, 60m; 1x1-40/43, 1x1-20/66, 5-533TT, 20mines
			Nj	Najad	1943
			Nä	Näcken	1943

PRINCIPAL SURFACE COMBATANTS

BC	Äran	1	1	Manligheten	1904		3735t, 90.2x15.0x5.0m, 8b,2vte, 6500hp, 17kts, 275p; 175belt, 48deck, 190turrets, 200CT; 2x1-209/44, 6x1-152/44, 14x1-57/55, 4x1-40/60, 2x1-37/37, 2x1-25/58, 2-450TT
	Oscar II	1	1	Oscar II	1907		4850t, 95.6x15.4x5.5m, 10b,2vte, 9400hp, 18kts, 331p; 150belt, 50deck, 190turrets, 157CT; 2x1-209/44, 4x2-152/50, 2x2-75/60, 3x1-37/37, 1x2-25/58
	Sverige	3	1	Sverige	1917		7516(1)-7633(2,3)t, 120.0(1)-121.6(2,3)x18.6x6.3m, 4b,2gst(1)-8b,2gst(2,3), 23910hp, 22.5kts, 427p; 200belt, 45deck, 200turrets, 175CT; 2x2-283/45, (1x2+4x1)-152/50(2), 6x1-152/50(1,3), 2x2-75/60, 2x1-57/55, 3x2-40/60, 2x2-20/66(1), 7x1-20/66(2), (2x2+4x1)-20/66(3); radar
			2	Drottning Victoria	1921
			3	Gustaf V	1922
CA	Fylgia	1	1	Fylgia	1907		4980t, 117.3x14.8x6.1m, 4b,2vte, 13000hp, 23.5kts, 322p; 100belt, 35deck, 125turrets, 100CT; 4x2-152/50, 4x1-57/55, 2x2-40/60, 1x2-25/58, 1x1-20/66, 2x1-533TT, 2dcr
CL	Gotland	1	1	Gotland	1934		5550t, 134.8x15.4x4.5m, 4b,2gst, 33000hp, 27.5kts, 480p; 24belt, 25deck, 25turrets, 19CT; (2x2+2x1)-152/55, (1x2+2x1)-75/60, 4x2-40/60, (1x2+4x1)-25/58, 2x2-20/66, 2x3-533TT, 100mines; radar
	Tre Kronor	2	1	Göta Lejon	1947		9238t, 180.2x16.7x5.7m, 4b,2gst, 90000hp, 33kts, 783p; 90belt, 60decks, 125turrets, 20CT; (1x3+2x2)-152/53, 10x2-40/60, 7x1-20/66, 2x3-533TT, 120mines, 4dcr; radar
			2	Tre Kronor	1947
CM	Clas Fleming	1	1	Clas Fleming	1914		1850t, 86.0x10.4x4.3m, 2b/4dgg,2gst/gt, 7200hp, 20.3kts, 160p; 25deck, 75CT; 4x1-120/50, 3x1-40/60, 3x1-25/58, 200mines, 2dcr
DD	Ehrensköld	2	11	Ehrensköld	1927		1160t, 91.4x8.9x3.8m, 3b,2gst, 24000hp, 36kts, 120p; 3x1-120/45, 2x2-25/58, 2x3-533TT, 2dct, 2dcr, 20mines
			12	Nordenskjöld	1927
	Klas Horn	1	3	Klas Horn	1932		1190t, 92.4x8.9x3.7m, 3b,2gst, 26000hp, 37kts, 119p; 3x1-120/45, 2x2-25/58, 2x3-533TT, 2dct, 2dcr, 20mines
	Göteborg	6	5	Göteborg	1936		1184t, 94.6x9.0x3.8m, 3b,2gst, 32000hp, 39kts, 155p; 3x1-120/45, 2x2-25/58(5,6), 3x2-25/58(7-10), 2x3-533TT, 2dct, 2dcr, 20mines
			6	Stockholm	1937
			7	Malmö	1939
			8	Karlskrona	1940
			9	Gävle	1941
			10	Norrköping	1941
	Spica	2	27	Romulus	1935		995t, 80.4x8.2x3.1m, 2b,2gst, 19000hp, 34kts, 94p; 3x1-100/47, 3x2-20/65, 2x2-450TT, 2dct, 20mines
			28	Remus	1935
	Mode	4	29	Mode	1942		960t, 78.0x8.1x2.3m, 2b,2gst, 16000hp, 31kts, 100p; 3x1-105/50, 2x1-40/60, 2x1-20/66, 1x3-533TT, 2dct, 42mines
			30	Magne	1942
			31	Munin	1943
			32	Mjölner	1942
	Visby	4	11	Visby	1943		1320t, 98.0x9.0x3.8m, 3b,2gst, 32000hp, 39kts, 155p; 3x1-120/45, (1x2+2x1)-40/60, 4x1-20/66, 2x3-533TT, 2dct, 2dcr, 46mines
			12	Sundsvall	1943
			13	Hälsingborg	1943
			14	Kalmar	1944
	Öland	2	16	Öland	1947		2250t, 112.0x11.2x3.4m, 2b,2gst, 44000hp, 35kts, 210p; 2x2-120/45, 7x1-40/60, 8x1-20/66, 2x3-533TT, 2dct, 2dcr, 40mines
			17	Uppland	1948
FS	Jägaren	4	41	Jägaren	1934		310t, 51.9x6.0x2.8m, 2b,1gst(2), 3600hp, 23kts, 41p; 2x1-75/60, 2x1-25/58, 2dct
			42	Kaparen	1934
			43	Snapphanen	1936
			44	Väktaren	1935

PATROL AND COASTAL COMBATANTS

PC	-	6	J21	Granat	1935		440t, 1vte, 800hp, 10kts; 1x1-57/55
			J22	Harpun	1925		440t, 1vte, 800hp, 10kts; 1x1-57/55
			J71	Kanon	1924		300t, 1vte, 700hp, 10kts; 1x1-57/55
			J72	Krut	1924		300t, 1vte, 700hp, 10kts; 1x1-57/55
			1	Styrbjörn	1923		350t, 1vte, 800hp, 10kts; 1x1-57/55
			2	Starkodder	1925		357t, 1vte, 800hp, 10kts; 1x1-57/55
PT	T15	4	T15-18		1941		23t, 18.7x4.6x1.5m, 2pe, 2300hp, 45kts, 11p; 1x1-20/66, 2-450TT
	T21	11	T21-31		1942-1943		27t, 20.0x5.0x1.5m, 2pe, 3000hp, 49kts, 11p; 1x1-20/66, 2-533TT
PB	Asköfjärd	3	V71-73	Asköfjärd, Baggensfjärd, Nämdöfjärd	1931-1932	No picture	25t, 19.3x3.8x1.5m, 1d, 92hp, 11.5kts, 7p; 1x1-37/39
	Kanholmsfjärd	3	V74-76	Kanholmsfjärd, Lidöfjärd, Edöfjärd	1933	No picture	28t, 21.2x3.8x1.5m, 1d, 92hp, 11.5kts, 7p; 1x1-37/39
	SVK1	5	SVK1-5		1944	No picture	19t, 16.5x3.7x1.2m, 1d, 100hp, 10.5kts, 12p; 1x1-20/66
	V51	6	V51		1944		145t, 32.0x5.3x2.2m, 1b,1vte, 400hp, 11kts, 12p; 1x1-20/66
			V52		1945
			V53		1945
			V54		1945
			V55		1944
			V56		1945

AMPHIBIOUS

MINE WARFARE

ML	Mul3	1	Mul3	Mul3	1879	No picture	190t, 6.5kts; mines
	Mul5	4	Mul5	Mul5	1904	No picture	120t, 7.5kts; mines
			Mul6	Mul6	1904
			Mul7	Mul7	1904
			Mul8	Mul8	1905
	Mul9	1	Mul9	Mul9	1912	No picture	120t, 9.1kts; mines
	Mul10	1	Mul10	Mul10	1939	No picture	166t, 27.4x5.6x2.3m, 9.5kts; mines
	Älvsnabben	1	M01	Älvsnabben	1943		4250t, 102.0x13.6x4.9m, 1d, 3000hp, 14kts, 255p; 4x1-152/44, 4x2-40/60, 6x1-20/66, 4dcr, 380mines
	Mul11	1	Mul11	Mul11	1946	No picture	200t, 30.1x7.2x3.6m, 2d(1), 300hp, 10kts, 9p; 2x1-20/66, mines
MSC	Arholma	14	53	Arholma	1939		442t, 56.7x7.6x2.1m, 2b,2gst, 3200hp, 17kts, 37p; 2x1-105/41, 2x1-40/60, 2dct, mines, sweeps
			54	Landsort	1939
			55	Bremön	1940
			56	Holmön	1940
			57	Sandön	1941
			58	Ulvön	1941
			59	Bredskär	1941
			60	Grönskär	1941
			61	Ramskär	1941
			62	Örskär	1941
			63	Koster	1940
			64	Kullen	1941
			65	Vinga	1940
			66	Ven	1941
MSI	M1	2	M1, 2		1938	No picture	62t, 30.0x4.3x1.0m, 3hbe(1)-3d(2), 600(1)-630(2)hp, 16.5(1)-18(2)kts, 11p; 1x1-13.2, dc, sweeps
	M3	12	M3-14		1940-1941	No picture	50t, 25.0x5.1x1.4m, 2d, 400hp, 13kts; 1x1-20/66, sweeps
	M15	12	M15-26		1941-1942		70t, 27.7x5.0x1.5m, 2d, 410hp, 13kts; 1x1-20/66, sweeps
	Orust	2	M41	Orust	1948	No picture	110t, 19.0x6.0x1.5m, 1d, 210hp, 9kts, 10p; 2x1-25/58, sweeps
			M42	Tjörn	1949
