World navies yesterday - Spain 01.01.1950

1950

Spain 01 January 1950

SUBMARINES

SS	B1	1	1	B2	1922	556/740t, 64.2x5.6x3.4m, 2d/em, 1400/420hp, 16.2/10.5kts, 28p, 60m; 1x1-76/45, 4-450TT
	C1	2	1	C1 Isaac Peral	1928	915/1143t, 75.3x6.3x4.1m, 2d/em, 2000/750hp, 16.5/8.5kts, 40p, 90m; 1x1-76/45, 6-533TT
	C1	2	2	C2	1928
	Archimede	2	1	General Mola	1934	970/1239t, 70.5x6.9x4.1m, 2d/em, 3000/1100hp, 17/8kts, 55p, 90m; 2x1-100/43, 2x1-13.2, 8-533TT
	Archimede	2	2	General Sanjurjo	1934
	D1	1	1	D1	1947	1065/1399t, 84.3x6.7x4.3m, 2d/em, 5000/1350hp, 20.5/9.5kts, 56p, 60m; 1x1-88/45, 1x1-20/65, 6-533TT
	G1	1	1	G7	1941	769/1070t, 67.1x6.2x4.7m, 2d/em, 2800/750hp, 17/7.6kts, 54p, 100m; 1x1-88/45, 1x1-20/65, 5-533TT

PRINCIPAL SURFACE COMBATANTS

CA	Canarias	1	1	Canarias	1936	13750t, 193.6x19.5x5.3m, 8b,4gst, 90000hp, 33kts, 1200p; 51belt, 37deck, 25turrets, 25CT; 4x2-203/50, 8x1-120/45, 4x1-40/70, 4x2-37/83, 4x1-20/70, 2dct, 1dcr; SG-6B, MLA-1B, Marconi, Decca 12 radars
CL	Reina Victoria Eugenia	1	1	Navarra	1923	6450t, 140.8x15.2x4.8m, 8b,2st, 25500hp, 25kts, 404p; 50belt, 38deck, 152shields, 152CT; 6x1-152/50, 4x1-88/45, 4x4-20/65
	Méndez Núñes	1	1	Méndez Núñes	1924	6045t, 142.9x14.1x4.4m, 12b,4gst, 45000hp, 29kts, 343p; 76belt, 25deck, 150CT; 8x1-120/45, 5x2-37/83, 2x4-20/65, 2x3-533TT
	Príncipe Alfonso	3	1	Galicia	1925	9748(1,3)-9660(2)t, 176.6x16.5x5.0m, 8b,4gst, 80000hp, 31.5(1,3)-33(2)kts, 781(1,3)-564(2)p; 76belt, 50deck, 13shields, 150CT; 4x2-152/50(1,3), (3x2+2x1)-152/50(2), 4x1-105/45(2), 8x2-37/83(1,3), 4x2-37/83(2), 5x4-20/65(1,3), 4x1-20/65(2), 2x3-533TT(1,3), 4x3-533TT(2), 4dct(1,3), 1seaplane(He114)(3)
			2	Almirante Cervera	1927
			3	Miguel de Cervantes	1930
DD	Alsedo	3	1	Alsedo	1924	1337t, 86.8x8.2x4.5m, 4b,2gst, 33000hp, 34kts, 86p; 3x1-102/50, 3x1-20/65, 2x2-450TT, 2dct, 1dcr, 60mines
			2	Velasco	1924
			3	Lazaga	1925
	Churucca	6	1	Sánchez Barcáiztegui	1928	2087t, 102.0x9.7x3.2m, 4b,2gst, 42000hp, 36kts, 190p; 4x1-120/45, 2x2-37/83, 4x1-20/65, 2x3-533TT, 2dcr
			2	José Luis Díez	1929
			3	Lepanto	1930
			4	Churucca	1931
			5	Alcalá Galiano	1931
			6	Almirante Valdés	1933
	Almirante Antequera	7	1	Almirante Antequera	1935	2175t, 101.2x9.7x3.2m, 4b,2gst, 42000hp, 36kts, 190p; 4x1-120/45, 2x2-37/83, 4x1-20/65, 2x3-533TT, 2dct, 2dcr
			2	Almirante Miranda	1936
			3	Gravina	1936
			4	Escaño	1936
			5	Císcar	1936
			6	Jorge Juan	1937
			7	Ulloa	1937
	Falco	1	1	Melilla	1917	1820t, 94.7x9.5x3.4m, 5b,2st, 40000hp, 34kts, 160p; 2x2-120/45, 2x1-76/40, 4x1-20/65, 2x2-450TT, 1dcr, 50mines
	Alessandro Poerio	1	1	Huesca	1915	1216t, 85.0x8.0x2.8m, 3b,2st, 20000hp, 31.5kts, 137p; 5x1-102/45, 1x1-40/39, 2x1-20/65, 2x1-13.2, 2x2-450TT, 42mines
FF	Pizarro	6	1	Pizarro	1946	2246t, 95.2x12.2x3.4m, 2b,2gst, 6000hp, 18.5kts, 251p; 3x1-120/45(5,6), 3x1-105/45(1-3), 2x1-105/45(4), 4x2-37/83, 6x1-20/65, 4dct, 1dcr, 30mines
			2	Hernán Cortés	1947
			3	Vasco Núñez de Balboa	1947
			4	Martín Alonso Pinzón	1948
			5	Magallanes	1948
			6	Vicente Yáñez Pinzón	1949
	Antonio Cánovas del Castillo	3	1	Cánovas del Castillo	1923	1335t, 77.3x10.2x3.4m, 2b,2vte, 1700hp, 15kts, 132p; 4x1-102/45, 2x1-47/50, 3x1-20/65
			2	Canalejas	1924
			3	Dato	1925
	Calvo Sotelo	1	1	Calvo Sotelo	1938	2000t, 92.4x12.2x3.5m, 2b,2gst, 6500hp, 18.5kts, 160p; 2x1-102/45, 2x1-57/42, 3x1-20/65, 2dcr
	Júpiter	4	1	Marte	1938	2600t, 96.0x12.7x3.5m, 4b,2gst, 10000hp, 18.5kts, 180p; 4x1-120/45, 2x1-76/40, 3x1-20/65, 264mines, 2dcr
			2	Neptuno	1939
			3	Júpiter	1937
			4	Vulcano	1937
	Eolo	2	1	Eolo	1941	1925t, 88.9x11.8x3.7m, 2b,2gst, 5000hp, 19.5kts, 220p; 4x1-105/44, 2x2-37/83, 4x1-20/65, 2dct, 70mines
	Eolo	2	2	Tritón	1943

PATROL AND COASTAL COMBATANTS

PC	Castle	2	1	Uad Martin	1917		547t, 40.8x7.2x2.8m, 1b,1vte, 480hp, 10.5kts, 39p; 1x1-76/50
	Castle	2	2	Alhucemas	1918
	Mersey	3	1	Uad Kert	1917		665t, 45.1x7.2x2.8m, 1b,1vte, 600hp, 11kts, 45p; 1x1-76/50(1,3), 2x1-76/50(2), 1x1-47/50(3)
			2	Arcíla	1918
			3	Xauen	1918
	Briscard	2	1	Alcázar	1918		440t, 41.0x7.3x3.2m, 1b,1vte, 425hp, 11kts, 41p; 1x1-76/50, 1x1-57/42(2), 2x1-47/50(1)
	Briscard	2	2	Tetuán	1918
	Lanzón	2	1	V17	1935	No picture	111t, 26.5x5.4x3.1m, 1pe, 285hp, 12kts
	Lanzón	2	2	V18	1935	No picture	111t, 26.5x5.4x3.1m, 1pe, 285hp, 12kts
	Hunt	1	1	Virgen de la Caridad	1919		1094t, 70.4x8.8x2.9m, 2b,2vte, 1600hp, 13.2kts, 97p; 3x1-102/45, 2x1-20/65
APC	-	1	1	Finisterre	1894		365t
PR	Cabo Fradera	1	1	Cabo Fradera	1928		45t, 22.8x4.4x1.2m, 2pe, 121hp, 10.7kts, 16p; 1x1-42/42
PT	LT21	6	1	LT21	1943		115t, 34.9x5.3x1.7m, 3d, 7500(21,22,25,26)-6000(23,24)hp, 41(21,22,25,26)-39(23,24)kts, 24p; 2x1-20/65, 2-533TT, 2dcr, 6mines
			2	LT22	1943
			3	LT23	1942
			4	LT24	1942
			5	LT25	1943
			6	LT26	1943
PB	V20	2	1, 2	V20, 21	1942 - 1944		60t, 26.2x4.7x1.4m, 2d, 700hp, 18kts, 14p; 2x1-20/65
	C.I	18	1-18	C1, 3, 4, 6-16, 18-21	1922 - 1925	No picture	36t, 22.8x4.0x1.4m, 2d, 180hp, 12kts, 6p
	I1	5	1	MNF525	1923	No picture	128t, 33.5x2.6x1.8m, 2d, 600hp, 13kts; 1x1-57/42
			2	I2	1923
			3	I3	1923
			4	I4	1923
			5	I6	1923

AMPHIBIOUS

LCU	LCT(4)	2	1	Foca	1944		640t, 57.1x11.8x1.4m, 2d, 920hp, 10kts, 12p; 2x1-20/70, 9tanks or 200troops
			2	Morsa	1945

MINE WARFARE

MSO	Bidasoa	7	1	Bidasoa	1946	748t, 61.9x8.5x2.6m, 2b,2vte, 2400hp, 16.5kts, 90p; 1x1-88/45 or 1x1-102/45, 1x1-37/83, 2x1-20/65, 2dcr, sweeps
			2	Nervión	1946
			3	Lérez	1947
			4	Tambre	1946
			5	Guadalete	1946
			6	Segura	1949
			7	Ter	1948
