Dominican Republic 01 January 1950
PRINCIPAL SURFACE COMBATANTS
| DD | H | 1 | D101 | Trujillo | 1936 | |
2095t, 98.5x10.1x4.1m, 3b,2gst, 34000hp, 36kts, 145p; 3x1-120/45, (2x2+2x1)-20/70, 1x4-533TT, 4dct, 1dcr, minesweeping gear; radars, type 124 sonar |
| F | 1 | D102 | Generalissimo | 1935 | |
2095t, 100.3x10.1x4.0m, 3b,2gst, 36000hp, 36kts, 145p; 4x1-120/45, (2x2+2x1)-20/70, 4dct, 1dcr, minesweeping gear; radars, type 121 sonar | |
| FF | River | 1 | F101 | Presidente Trujillo | 1944 | |
2125t, 91.8x11.2x3.9m, 2b,2vte, 5500hp, 20kts, 195p; 1x1-102/41, 2x1-47/40, 1x1-40/60, 4x1-20/70; radar |
| Ashville | 1 | F102 | Juan Pablo Duarte | 1942 | |
2150t, 91.9x11.1x4.0m, 2b,2vte, 5500hp, 20kts, 190p; 3x1-76/50, 2x2-40/60, 4x1-20/70, 1x24-178 Hedgehog ASWRL, 8dct, 2dcr; SA, SF, Mk26 radars, sonar | |
| Tacoma | 2 | F103 | Presidente Troncoso | 1944 | |
2238t, 92.6x11.4x3.9m, 3b,2vte, 5500hp, 20kts, 190p; 3x1-76/50, 2x2-40/60, 6x1-20/70, 2x2-12.7; SA, SF, Mk26 radars | |
| F104 | Presidente Peynado | 1944 | |||||
| FS | mod. Flower | 5 | C101 | Cristobal Colón | 1944 | |
1350t, 63.5x10.1x4.4m, 2b,1vte, 2750hp, 16.5kts, 109p; 1x1-102/40, 1x1-40/60, 2x1-20/70, 1x24-178 Hedgehog ASWRL, 4dct, 2dcr; type 268, 276 radars, sonar |
| C102 | Juan Alejandro Acosta | 1943 | |||||
| C103 | Juan Bautista Cambiaso | 1944 | |||||
| C104 | Gerardo Jansen | 1944 | |||||
| C105 | Juan Bautista Maggiolo | 1943 |
PATROL AND COASTAL COMBATANTS
| PC | PC173 | 3 | P101 | 27 de Febrero | 1943 |  |
463t, 52.9x7.1x3.3m, 2d, 2880(101,102)-1800(103)hp, 19(101,102)-17(103)kts, 65p; 1x1-76/50, 1x1-40/60, 1x1-20/70; SO radar |
| P102 | Capitán Wenceslao Arvelo | 1943 | |||||
| P103 | Cibas | 1942 | |||||
| Argo | 3 | P104 | Restauración | 1933 |  |
370t, 50.3x7.2x2.3m, 2d, 1340hp, 16kts, 50p; 1x1-76/50, 1x1-40/60, 1x1-20/70; radar | |
| P105 | Independencia | 1932 | |||||
| P106 | Rafael Atoa | 1931 | |||||
| PB | GC75ft | 6 | GC1, 3-7 | 1924-1926 | No picture | 37t, 22.9x4.2x1.2m, 1pe, 400hp, 13.5kts, 12p; 2x1-20/70, 2dcr | |
| GC2 | 1 | GC2 | 1918 | No picture | 18t, 13.7x3.4x1.1m, 2pe, 200hp, 9.5kts | ||
| GC8 | 1 | GC8 | 1941 | No picture | 28t, 19.0x3.7x1.2m, 1pe, 200hp, 10kts, 10p | ||
| GC9 | 3 | GC9 | Luperón | 1943 | No picture | 45t, 25.3x4.9x1.4m, 2pe, 1200hp, 20.5kts,14p; 2x1-20/70, 2dcr | |
| GC10 | 22 de Julio | 1943 | |||||
| GC11 | 16 de Agosto | 1943 | |||||
| AVR | 3 | LR101 | 1945 | No picture | 100t, 31.9x5.9x1.7m, 2pe, 1000hp, 17kts, 20p; 2x1-20/70 | ||
| LR102 | 1945 | ||||||
| LR103 | 1945 | ||||||
| SC110 | 2 | GC101 | Sanchez | 1943 |  |
136t, 33.8x5.5x2.0m, 2d, 1000hp, 16kts, 27p; 1x1-40/60, 3x1-20/70, 2x4-178 Mousetrap ASWRL, 2dct, 2dcr; SO radar, QC sonar | |
| GC102 | Mella | 1943 |
AMPHIBIOUS
| LSM | LSM1 | 1 | BA103 | San Rafael | 1944 |  |
1095t, 62.0x10.5x2.1m, 2d, 2800hp, 13.2kts, 60p; 1x2-40/60, 4x1-20/70; 5tanks, 54troops; radar |
| LCU | LCI(L)1 | 2 | BDI101 | Beller | 1942 |  |
387t, 48.5x7.2x1.5m, 8d(2), 2320hp, 15.5kts, 24p; 4x1-20/70; SO radar; 180troops |
| BDI102 | Palo Incaldo | 1943 | |||||
| LCT(5) | 1 | LA2 | Samaná | 1943 |  |
286t, 34.8x10.0x1.3m, 3d, 675hp, 8kts, 11p; 1x1-12.7; 4tanks | |
| LCT(6) | 2 | LA3 | 17 de Julio | 1944 |  |
320t, 36.3x10.0x1.2m, 3d, 675hp, 8kts, 13p; 1x1-12.7; 4tanks | |
| LA4 | María Josefina | 1944 |
