World navies yesterday

1930

JAPAN 01 January 1930

CAPITAL SHIPS

BB	Fuso	2	1	Fuso	1915		35900(1)-39154(2)t, 205.1x28.7x8.7m, 24b, 4t, 40000hp, 22.5kts, 1193p; 305belt, 76deck, 305turrets, 350CT; 6x2-356/45, 16x1-152/50, 6x1-76/40, 6-533TT
			2	Yamashiro	1917
	Ise	2	3	Ise	1917		36500t, 208.2x28.7x8.8m, 24b, 4t, 45000hp, 23kts, 1360p; 305belt, 51deck, 305turrets, 305CT; 6x2-356/45, 20x1-140/50, 4x1-76/40, 6-533TT
			4	Hyuga	1918
	Nagato	2	5	Nagato	1920		38500t, 215.8x29.0x9.1m, 21b, 4gt, 80000hp, 26.5kts, 1333p; 305b, 121deck, 356turrets, 356CT; 4x2-410/45, 20x1-140/50, 7x1-76/40(5), 4x1-76/40(6), 8-533TT
			6	Mutsu	1921
BC	Kongo	4	1	Kongo	1913		32200(1-3)-31475(4)t, 214.5(1-3)-215.2(4)x28.0(1-3)-29.3(4)x8.4(1-3)-8.6(4)m, 36b(1-3)-16b(4), 4t, 64000hp, 27.5(1-3)-25.9(4)kts, 1201-1221(1-3)-1118(4)p; 203belt, 57(1-3)-120(4)deck, 229turrets, 254CT; 4x2-356/45, 16x1-152/50, 7x1-76/40, 8-533TT(1-3), 4-533TT(4)
			2	Hiei	1914
			3	Kirishima	1915
			4	Haruna	1915

AIRCRAFT CARRYING SHIPS

CV	Akagi	1	1	Akagi	1927		34364t, 260.7x29.0x8.1m, 19b, 4gt, 131200hp, 31kts, 1650p; 152belt, 51deck, 25turrets; (2x2+6x1)-200/50, 6x2-120/45, 60aircraft (16 A1N, 28 B1M, 16 C1M)
	Kaga	1	2	Kaga	1928		33693t, 238.5x29.6x7.9m, 12b, 4gt, 91000hp, 27.5kts, 1340p; 152belt, 55deck, 25turrets; (2x2+6x1)-200/50, 6x2-120/45, 60aircraft (15 A1N, 24 B1M, 8 C1M)
CVL	Hosho	1	1	Hosho	1922		9630t, 168.1x22.7x6.2m, 8b, 2t, 30000hp, 25kts, 550p; 4x1-140/50, 4x1-76/40, 26aircraft (9 A1N, 3 B1M, 3 C1M)
AV	Wakamiya	1	1	Wakamiya	1901		7720t, 111.3x14.7x5.8m, 3b, 1vte, 1590hp, 10kts, 234p; 2x1-76/40, 2x1-47/40, 4seaplanes (really none)
	Notoro	2	2	Notoro	1920		14050t, 138.9x17.7x8.1m, 4b, 2vte, 5850hp, 12kts, 155p; 2x1-120/45, 2x1-76/40, 10seaplanes (E1Y, E2N and E3A)
			3	Tsurumi	1922

CRUISERS

CA	Asama	1	1	Asama	1899		10500t, 134.7x20.5x7.4m, 16b, 2vte, 18000hp, 21.5kts, 726p; HN 178belt, 76deck, 152turrets, 356CT; 2x2-203/45, 14x1-152/40, 9x1-76/40, 3x1-47/30, 2-450TT
	Yakumo	1	2	Yakumo	1900		10300t, 132.3x19.6x7.2m, 6b, 2vte, 7000hp, 16kts, 700p; 178belt, 63deck, 152turrets, 356CT; 2x2-203/45, 8x1-152/40, 1x1-76/40
	Azuma	1	3	Azuma (TS)	1900		9953t, 137.9x20.9x7.2m, 24b,2vte, 17000hp, 20kts, 650p; 178belt, 63deck, 152turrets, 356CT; 2x2-203/45, 12x1-152/40, 9x1-76/40, 8x1-47/40, 2-450TT
	Izumo	2	4	Izumo	1900		10300t, 132.3x20.9x7.4m, 24b, 2vte, 14500hp, 20.8kts, 672p; 178belt, 63deck, 152turrets, 356CT; 2x2-203/45, 14x1-152/40, 9x1-76/40, 4x1-47/30, 2-450TT
			5	Iwate	1901
	Kasuga	2	6	Kasuga	1904		8500t, 111.7x18.9x7.3m, 12b, 2vte, 13500hp, 20kts, 600p; 150belt, 38deck, 150turrets, 150CT; 1x1-254/40(5), 1x2-203/45(5), 2x2-203/45(6), 4x1-152/40, 5x1-76/40, 4-450TT
			7	Nisshin	1904
	Furutaka	2	8	Furutaka	1926		9544t, 185.2x15.8x5.6m, 12b, 4gt, 102000hp, 34.5kts, 625p; 76belt, 35deck, 25turrets; 6x1-200/50, 4x1-76/40, 12-610TT, 1seaplane (HD.25)
			9	Kako	1926
	Aoba	2	10	Aoba	1927		9820t, 185.2x15.8x5.7m, 12b, 4gt, 102000hp, 34.5kts, 625p; 76belt, 35deck, 25turrets; 3x2-200/50, 4x1-120/45, 12-610TT, 1seaplane (E2N)
			11	Kinugasa	1927
	Nachi	4	12	Nachi	1928		13280t, 203.8x17.3x5.9m, 12b, 4gt, 130000hp, 35.5kts, 773p; 102belt, 90deck, 25turrets; 5x2-200/50, 6x1-120/45, 12-610TT, 2seaplanes (E2N)
			13	Myoko	1929
			14	Haguro	1929
			15	Ashigara	1929
CL	Tsushima	1	1	Tsushima	1904		3716t, 104.1x13.4x4.9m, 16b, 2vte, 9500hp, 20kts, 320p; HN 64slopes, 25shields, 102CT; 6x1-152/40, 9x1-76/40
	Tone	1	2	Tone	1910		4900t, 113.8x14.4x5.1m, 16b, 2vte, 15000hp, 23kts, 370p; 76deck, 25shields, 102CT; 2x1-152/45, 8x1-120/40, 6x1-76/40, 3-450TT
	Chikuma	3	3	Chikuma	1912		5040t, 144.8x14.2x5.1m, 6b, 2t, 22500hp, 26kts, 414p; 89belt, 57deck, 25shields, 102CT; 8x1-152/45, 6x1-76/40, 2x2-533TT
			4	Hirado	1912
			5	Yahagi	1912
	Tenryu	2	6	Tenryu	1919		4350t, 142.9x12.3x4.0m, 10b, 3gt, 51000hp, 33kts, 327p; 63belt, 25deck, 20shields, 51CT; 4x1-140/50, 1x1-76/40, 2x3-533TT, 48mines
			7	Tatsuta	1919
	Kuma	5	8	Kuma	1920		5832t, 162.2x14.2x4.8m, 12b, 4gt, 90000hp, 36kts, 450p; 63belt, 45deck, 20shields, 51CT; 7x1-140/50, 2x1-76/40, 4x2-533TT, 48mines
			9	Tama	1921
			10	Kitakami	1921
			11	Oi	1921
			12	Kiso	1921
	Nagara	6	13	Nagara	1922		7050t, 162.2x14.2x4.8m, 12b, 4gt, 90000hp, 36kts, 450p; 63belt, 20shields, 29deck, 51CT; 7x1-140/50, 2x1-76/40, 4x2-610TT, 48mines, 1seaplane (E2N)
			14	Natori	1922
			15	Kinu	1922
			16	Isuzu	1923
			17	Yura	1923
			18	Abukuma	1925
	Yubari	1	19	Yubari	1923		4400t, 138.9x12.0x3.6m, 8b, 3gt, 57750hp, 35.5kts, 328p; 57belt, 25deck, 25turrets; (2x2+2x1)-140/50, 1x1-76/40, 2x2-610TT, 48mines
	Sendai	3	20	Sendai	1924		7100t, 163.0x14.2x4.9m, 12b, 4gt, 90000hp, 35.2kts, 450p; 64belt, 29deck; 7x1-140/50, 2x1-76/40, 4x2-610TT, 48mines, 1seaplane (E2N)
			21	Naka	1925
			22	Jintsu	1925

TORPEDO SHIPS

DD	Umikaze	2	1	Umikaze	1911		1150t, 98.5x8.5x2.7m, 8b, 3t, 20500hp, 33kts, 140p; 2x1-120/40, 5x1-76/40, 2x2-450TT(1), 3x1-450TT(2)
			2	Yamakaze	1911
	Sakura	2	3	Sakura	1912		830t, 83.6x7.3x2.2m, 5b, 3vte, 9500hp, 30kts, 92p; 1x1-120/40, 4x1-76/40, 2x2-450TT
			4	Tachibana	1912
	Urakaze	1	5	Urakaze	1915		1085t, 87.2x8.4x2.4m, 3b, 2t, 22000hp, 30kts, 120p; 1x1-120/40, 4x1-76/40, 2x2-533TT
	Kaba	10	6	Kaba	1915		850t, 83.6x7.3x2.3m, 4b, 3vte, 9500hp, 30kts, 92p; 1x1-120/40, 4x1-76/40, 2x2-450TT
			7	Matsu	1915
			8	Kashiwa	1915
			9	Katsura	1915
			10	Kaede	1915
			11	Kiri	1915
			12	Kusunoki	1915
			13	Ume	1915
			14	Sakaki	1915
			15	Sugi	1915
	Momo	4	16	Momo	1916		1080t, 85.6x7.7x2.3m, 4b, 2gt, 16000hp, 31.5kts, 110p; 3x1-120/40, 2x3-450TT
			17	Kashi	1917
			18	Hinoki	1917
			19	Yanagi	1917
	Amatsukaze	4	20	Amatsukaze	1917		1570t, 96.9x8.5x2.8m, 5b, 3t, 27000hp, 34kts, 128p; 4x1-120/40, 3x2-450TT
			21	Isokaze	1917
			22	Tokitsukaze	1917
			23	Hamakaze	1917
	Kawakaze	2	24	Kawakaze	1918		1580t, 103.6x8.8x2.8m, 4b, 2gt(24)-2t(25), 34000hp, 37.5kts, 128p; 3x1-120/45, 2x3-533TT
			25	Tanikaze	1919
	Enoki	6	26	Enoki	1918		1100t, 85.8x7.7x2.3m, 4b, 2gt, 17500hp, 31.5kts, 110p; 3x1-120/40, 2x3-450TT
			27	Nara	1918
			28	Tsubaki	1918
			29	Kuwa	1918
			30	Keyaki	1918
			31	Maki	1918
	Momi	20	32	Momi	1919		1020t, 85.3x7.9x2.4m, 3b, 2gt, 21500hp, 36kts, 110p; 3x1-120/45, 2x2-533TT, 20mines, MS
			33	Nashi	1919
			34	Take	1919
			35	Kaya	1920
			36	Nire	1920
			37	Kaki	1920
			38	Kuri	1920
			39	Tsuga	1920
			40	Kiku	1920
			41	Aoi	1920
			42	Fuji	1921
			43	Hagi	1921
			44	Susuki	1921
			45	Ashi	1921
			46	Tsuta	1921
			47	Hasu	1922
			48	Hishi	1922
			49	Yomogi	1922
			50	Tade	1922
			51	Sumire	1923
	Minekaze	15	52	Minekaze	1920		1650t, 102.6x9.0x2.9m, 4b, 2gt, 38500hp, 39kts, 148p; 4x1-120/45, 3x2-533TT, 20mines
			53	Sawakaze	1920
			54	Okikaze	1920
			55	Hakaze	1920
			56	Yakaze	1920
			57	Shimakaze	1920
			58	Nadakaze	1921
			59	Akikaze	1921
			60	Shiokaze	1921
			61	Yukaze	1921
			62	Hokaze	1921
			63	Tachikaze	1921
			64	Nokaze	1922
65			Namikaze	1922
66			Numakaze	1922
Kamikaze	9	67	Kamikaze	1922		1720t, 102.6x9.1x2.9m, 4b, 2gt, 38500hp, 37.2kts, 148p; 4x1-120/45, 3x2-533TT, 20mines, sweeps
		68	Asakaze	1923
		69	Harukaze	1923
		70	Matsukaze	1924
		71	Hatakaze	1924
		72	Oite	1925
		73	Hayate	1925
		74	Asanagi	1925
		75	Yunagi	1925
Wakatake	8	76	Wakatake	1922		1100t, 85.3x7.9x2.5m, 3b, 2gt, 21500hp, 35.5kts, 110p; 3x1-120/45, 2x2-533TT, 20mines, MS
		77	Kuretake	1922
		78	Sanae	1923
		79	Asagao	1923
		80	Fuyo	1923
		81	Karukaya	1923
		82	Sawarabi	1924
		83	Yugao	1924
Mutsuki	12	84	Kisaragi	1925		1772t, 102.7x9.2x3.0m, 4b, 2gt, 38500hp, 37.2kts, 150p; 4x1-120/45, 2x3-610TT, 2DCT, 16mines, MS
		85	Satsuki	1925
		86	Mutsuki	1926
		87	Yayoi	1926
		88	Uzuki	1926
		89	Fumizuki	1926
		90	Kikuzuki	1926
		91	Minazuki	1927
		92	Nagatsuki	1927
		93	Mikazuki	1927
		94	Mochizuki	1927
		95	Yuzuki	1927
Fubuki	11	96	Fubuki	1928		2097t, 118.4x10.4x3.2m, 4b, 2gt, 50000hp, 38kts, 197p; 3x2-127/50, 3x3-610TT, 2DCT, 18mines
		97	Shinonome	1928
		98	Usugumo	1928
		99	Shirakumo	1928
		100	Isonami	1928
		101	Shirayuki	1928
		102	Murakumo	1928
		103	Hatsuyuki	1929
		104	Miyuki	1929
		105	Uranami	1929
		106	Shikinami	1929

SUBMARINES

SS	K1	2	1	RO11	1919		735/1030t, 69.2x6.4x3.4m, 2d/em, 2600/1200hp, 18/9kts, 44p, 30m; 1x1-76/23, 6-450TT
			2	RO12	1919
	F1	2	3	RO1	1920		689/1047t, 65.6x6.1x4.2m, 2d/em, 2800/1200hp, 13/8kts, 43p, 40m; 1x1-76/23, 5-450TT
			4	RO2	1920
	F2	3	5	RO3	1922		689/1047t, 65.6x6.1x4.1m, 2d/em, 2600/1200hp, 14/8kts, 43p, 40m; 1x1-76/23, 5-450TT
			6	RO4	1922
			7	RO5	1922
	K2	3	8	RO13	1920		755/1050t, 70.1x6.1x3.7m, 2d/em, 2600/1200hp, 17/9kts, 45p, 45m; 1x1-76/23, 6-450TT
			9	RO14	1921
			10	RO15	1921
	L1	2	11	RO51	1920		893/1195t, 70.6x7.2x3.9m, 2d/em, 2400/1600hp, 17/8kts, 48p, 60m; 1x1-76/23, 6-450TT
			12	RO52	1920
	K3	10	13	RO16	1922		755/1050t, 70.1x6.1x3.7m, 2d/em, 2600/1200hp, 17/9kts, 45p, 45m; 1x1-76/23, 6-450TT
			14	RO17	1921
			15	RO18	1921
			16	RO19	1922
			17	RO20	1922
			18	RO21	1922
			19	RO22	1922
			20	RO23	1923
			21	RO24	1920
			22	RO25	1921
	L2	4	23	RO53	1921		893/1195t, 70.6x7.1x3.9m, 2d/em, 2400/1600hp, 17/8kts, 48p, 60m; 1x1-76/23, 4-450TT
			24	RO54	1921
			25	RO55	1921
			26	RO56	1922
	L3	3	27	RO57	1922		897/1195t, 76.2x7.2x4.0m, 2d/em, 2400/1600hp, 17/8kts, 48p, 60m; 1x1-76/23, 4-533TT
			28	RO58	1922
			29	RO59	1923
	K4	3	30	RO26	1923		770/1080t, 74.2x6.1x3.7m, 2d/em, 2600/1200hp, 17/9kts, 45p, 45m; 1x1-76/23, 4-533TT
			31	RO27	1924
			32	RO28	1923
	KT	4	33	RO29	1923		665/1030t, 74.2x6.1x3.7m, 2d/em, 1200/1200hp, 13/8kts, 43p, 75m; 1x1-120/45, 4-533TT
			34	RO30	1924
			35	RO31	1927
			36	RO32	1924
	L4	9	37	RO60	1923		996/1322t, 76.2x7.4x3.8m, 2d/em, 2400/1600hp, 16.5/9kts, 47p, 60m; 1x1-76/40, 6-533TT
			38	RO61	1924
			39	RO62	1924
			40	RO63	1924
			41	RO64	1925
			42	RO65	1926
			43	RO66	1927
			44	RO67	1926
			45	RO68	1925
	KD1	1	46	I51	1924		1500/2430t, 91.4x8.8x4.6m, 4d/em, 5200/2000hp, 20/10kts, 60p, 60m; 1x1-120/45, 1x1-76/40, 8-533TT
	KD2	1	47	I52	1925		1500/2500t, 100.9x7.6x5.1m, 2d/em, 6800/2000hp, 22/10kts, 60p, 60m; 1x1-120/45, 1x1-76/40, 8-533TT
	J1	4	48	I1	1926		2135/2791t, 97.5x9.2x5.0m, 2d/em, 6000/2600hp, 18/8kts, 92p, 80m; 2x1-140/40, 6-533TT
			49	I2	1926
			50	I3	1926
			51	I4	1929
	KD3a	4	52	I53	1927		1800/2300t, 100.6x8.0x4.8m, 2d/em, 6800/1800hp, 20/8kts, 64p, 60m; 1x1-120/45, 8-533TT
			53	I54	1927
			54	I55	1927
			55	I58	1928
	KRS	4	56	I21	1927		1383/1768t, 85.2x7.5x4.4m, 2d/em, 2400/1100hp, 14.5/7kts, 51p, 75m; 1x1-140/40, 4-533TT, 42mines
			57	I22	1927
			58	I23	1928
			59	I24	1928
	KD3b	4	60	I56	1929		1800/2300t, 101.0x7.9x4.9m, 2d/em, 6800/1800hp, 20/8kts, 79p, 60m; 1x1-120/45, 8-533TT
			61	I57	1929
			62	I60	1929
			63	I63	1928
	KD4	1	64	I61	1929		1720/2300t, 97.7x7.8x4.8m, 2d/em, 6000/1800hp, 20/8.5kts, 58p, 60m; 1x1-120/45, 6-533TT

OTHER FIGHTING SHIPS

PG	Chihaya	1	1	Chihaya (TS)	1901		1464t, 87.7x9.6x2.8m, 4b,2vte, 6000hp, 21kts, 125p; 2x1-120/40, 4x1-76/40, 2x1-450TT
	Uji	1	2	Uji	1903		620t, 57.8x8.4x2.1m, 2b, 2vte, 1000hp, 13kts, 88p; 4x1-76/40
	Saga	1	3	Saga	1912		885t, 69.0x9.0x2.2m, 2b, 2vte, 1600hp, 15kts, 98p; 1x1-120/45, 3x1-76/40
	Ataka	1	4	Ataka	1923		1133t, 71.7x9.0x2.3m, 2b, 2vte, 1700hp, 16kts, 118p; 2x1-120/45, 2x1-76/40
PR	Sumida	1	1	Sumida	1906		126t, 44.2x7.2x0.6m, 2b, 3vte, 550hp, 13kts, 40p; 2x1-47/40
	Fushimi	1	2	Fushimi	1906		180t, 48.7x7.4x0.7m, 2b, 3vte, 900hp, 14kts, 45p; 2x1-57/40
	Toba	1	3	Toba	1911		291t, 55.9x8.2x0.8m, 2b, 3vte, 1400hp, 15kts, 59p; 2x1-76/23
	Seta	4	4	Seta	1923		400t, 56.1x8.2x1.0m, 2b, 2vce, 2100hp, 16kts, 62p; 2x1-76/40
			5	Kataka	1923
			6	Hira	1923
			7	Hozu	1923
	Atami	1	8	Atami	1929		249t, 46.3x6.3x0.9m, 2b, 2vce, 1300hp, 16.7kts, 77p; 1x1-76/23, 1x1-13.2/76

COASTAL FORCES

PT

CMB-55

4

1 - 4

No615, 1149 and 2 others

1920

14t, 16.8x3.4x1.0m, 2pe, 1000hp, 40kts, 5p; 2-450TT, 1DCR

MINE WARFARE

ML	Tokiwa	1	1	Tokiwa	1899		10500t, 134.7x20.5x7.4m, 16b, 2vte, 18000hp, 21.5kts, 726p; HN 178belt, 76deck, 152turrets, 356CT; 1x2-203/45, 8x1-152/40, 3x1-76/40, 300mines
	Aso	1	2	Aso	1903		7800t, 137.0x17.5x6.5m, 26b, 2vte, 16500hp, 21kts, 593p; H 200belt, 50decl, 60casemates, 160CT; 2x1-152/50, 8x1-152/45, 16x1-76/40, 420mines
	Natsushima	13	3	Natsushima	1912		435t, 45.7x7.6x2.3m, 1b, 1vte, 600hp, 12.8kts, 40p; 2x1-76/40, 60mines, MS
			4	Sokuten	1913
			5	Toshima	1915
			6	Kuroshima	1915
			7	Ashizaki	1916
			8	Katoku	1916
			9	Kurokami	1917
			10	Katashima	1917
			11	Ento	1917
			12	Enoshima	1919
			13	Kurosaki	1921
			14	Ninoshima	1920
			15	Washizaki	1921
	Katsuriki	1	16	Katsuriki	1917		2000t, 73.1x11.9x4.3m, 2b, 2vte, 1800hp, 13kts, 3x1-76/40, 150mines
	Shirataka	1	17	Shirataka	1929		1692t, 84.0x11.6x3.0m, 2b, 2vte, 2000hp, 16kts, 3x1-120/45, 100mines
	Itsukushima	1	18	Itsukushima	1929		2408t, 107.5x11.8x3.2m, 3d, 3000hp, 17kts, 235p; 3x1-140/50, 2x1-76/40, 300mines, 2DCT
	Kamome	2	19	Kamome	1929		557t, 68.8x7.2x2.1m, 2b, 2vte, 2500hp, 19kts, 56p; 1x1-76/40, 1x1-13.2/76, 120mines
			20	Tsubame	1929
MS	W1	4	1	W1	1923		702t, 76.3x8.0x2.3m, 3b, 2vte, 4000hp, 20kts, 92p; 2x1-120/45, 1x1-76/40, MS
			2	W2	1923
			3	W3	1923
			4	W4	1925
	W5	2	5	W5	1929		717t, 77.0x8.2x2.2m, 3b, 2vte, 4000hp, 21kts, 87p; 2x1-120/45, 1x1-76/40, 1x1-13.2/76, MS
			6	W6	1929
	Asakaze	6	7	W7	1909		450t, 72.0x6.6x1.8m, 4b, 2vte, 6000hp, 29kts, 70p; 2x1-120/40, 2x1-76/40, MS
			8	W8	1908
			9	W9	1909
			10	W10	1907
			11	W11	1907
			12	W12	1907

NAVAL AVIATION (approximately, maximal number of delivered planes signed)
