World navies yesterday

1925

China 01 January 1925

CRUISERS

CL Tung Chi 1 1 Tung Chi 1896 1900t, 77.0ppx10.4x4.9m, 4b,1vc, 1600hp, 11.6kts, 335p; 2x1-152/50, 5x1-120/45, 3x1-57/40, 8x1-37/23
Hai Yung 3 2 Hai Yung 1898 2950t, 100.0x12.4x5.8m, 8b,2vte, 7500hp, 19.5kts, 244p; 32deck, 70slopes,  51shields, 37CT; 3x1-150/40, 8x1-105/40, 6x1-47/40, 3-356TT
3 Hai Chou 1898
4 Hai Chen 1898
Hai Chi 1 5 Hai Chi 1899 4515t, 129.2x14.2x5.5m, 12b,4vte(2), 17000hp, 24kts, 350p; 37deck, 127slopes, 114gunhouses, 152CT; 2x1-203/45, 10x1-120/45, 12x1-47/40, 4x1-37/32, 5-450TT
Ying Swei 1 6 Ying Swei 1911 2500t, 105.0x11.9x4.0m, 6b,3t, 6000hp, 20kts, 270p; 25deck, 37slopes, 76CT; 2x1-152/50, 4x1-102/50, 4x1-76/50, 6x1-47/40, 2x1-37/32, 2x1-450TT
Chao Ho 1 7 Chao Ho 1912 2750t, 105.5x12.8x4.5m, 8b,3t, 6000hp, 20kts, 283p; 25deck, 51slopes, 76CT; 2x1-152/50, 4x1-102/50, 4x1-76/50, 6x1-47/40, 2x1-37/32, 2x1-450TT

TORPEDO SHIPS

PGT Fei Ying 1 1 Fei Ying 1896 850t, 75.0x8.6x4.0m, 8b,2vte, 5430hp, 22kts, 90p; 25deck, 50shields; 2x1-105/40, 6x1-57/40, 4x1-37/23, (1+2x1)-356TT
Chien Wei 2 2 Chien Wei 1903 900t, 79.2x8.1x3.5m, 4b,2vte, 6500hp, 20.5kts, 140p; 25belt, 25deck; 1x1-100/45, 3x1-65/60, 6x1-37/32, 2x1-356TT
  3 Chien An 1903
DD Fu Po 3 1 Yu Chang 1911 390t, 60.4x6.5x1.8m, 4b,2vte, 6500hp, 32kts, 69p; 2x1-76/50, 2x1-47/40, 2x1-450TT
2 Chien Kang 1912
3 Tung An 1912
TB Lei Fu 2 1, 2 Lei Fu, Lei Lung 1884 No picture 64t, 35.0x4.0x1.7m, 2b,1vte, 700hp, 19.8kts, 20p; 2x5-37/20, 2-356TT
Lei Chen 9 3 - 11 Lei Chen, Lei Chung, Lei Kong, Lei Kwong, Lei Kung, Lei Li, Lei Sun, Lei Tsen, Lei Tui 1885 No picture 27t, 26.0x3.6xm, 1b,1vc, 420hp, 19.5kts; 1-356TT
Chang Tze 2 12, 13 No1 Chang Tze, No3 Lieh Tze 1895 No picture 89t, 39.0x4.8x1.5m, 1b,1vc, 600hp, 18kts, 31p; 2x5-37/20, (2+1x1)-356TT
Chen Tse 2 14 No2 Chen Tse 1896 126t, 43.9x5.2x2.4m, 2b,1vte, 1000hp, 18kts, 31p; 2x5-37/20, (2+1x1)-450TT
15 No4 Su Tse 1896
Hu Peng 4 16 No7 Hu Peng 1906 120t, 41.1x4.9x2.1m, 2b,1vte, 1200hp, 23kts, 34p; 2x1-47/40, (1+2x1)-450TT
17 No8 Hu Oah 1906
18 No9 Hu Ying 1907
19 No10 Hu Chen 1907

ESCORTS

PC Yi Sheng 1 1 Yi Sheng 1911 350t, 36.7x6.3x3.4m, 1b,1vte, 500hp, 10kts, 37p; 1x1-65/60, 1x1-57/40
Hai Yen 1 2 Hai Yen 1917 No picture 60t, 19.8x3.7x0.7m, 1b,2vte, 60hp, 10kts; 1x1-37/32
Hai Ku 2 3 Hai Ku 1917 200t, 34.1x5.5x2.6m, 1b,2vte, 300hp, 10.5kts, 22p; 2x1-37/32
4 Hai Hung 1917
Hai Fu 2 5 Hai Fu 1917 166t, 33.2x5.2x2.4m, 1b,1vte, 220hp, 10.5kts, 22p; 1x1-37/32
6 Hai Ou 1917
Hai Hao 2 7 Hai Hao 1917 230t, 32.3x5.5x2.0m, 1b,1vte, 200hp, 12kts, 22p; 4x1-37/32
8 Hai Peng 1920

OTHER FIGHTING SHIPS

PG Kwang Tung 2 1 An Lan 1868 No picture 440t, 42.7x7.2x2.7m, 3b,1hr, 255hp, 9.3kts, 60p; 1x1-178/12, 2x1-120/22
2 Chen T`ao 1868
Fei Ting 2 3 Fei Ting 1876 420t, 36.6x9.1x2.4m, 1b,2hcr, 270kts, 9.5kts, 30p; 13shield, 13CT; 1x1-318/16, 2x1-70/25, 1x4-25/40
4 Tse Tien 1876
Hai Ch`ang Ch`ing 1 5 Hai Ch`ang Ch`ing 1877 430t, 38.1x9.1x2.4m, 1b,2hrc, 70kts, 7.5kts; 1x1-254/14, 2x1-70/25
Kuang Yuan 4 6 Kuang Yuan 1886 No picture 300t, 33.8x5.5x2.3m, 2hr, 78hp, 10kts; 1x1-150/35, 1x1-88/35, 3x1-37/40
7 Kuang Heng 1886
8 Kuang Li 1886
9 Kuang Chien 1886
Kuang Keng 4 10 Kuang Keng 1887 No picture 560t, 43.0x7.3x3.7m, 1vr, 400hp, 11kts; 2x1-120/22, 1x1-100/22, 2x1-47/40
11 Kuang Hsing 1887
12 Kuang Jen 1887
13 Kuang Kuei 1887
Kiang Yuan 4 14 Kiang Yuan 1905 565t, 54.1x8.5x2.1m, 2b,2vte, 950hp, 13kts, 85p; 1x1-120/40, 1x1-76/40, 4x1-47/40
15 Kiang Heng 1907
16 Kiang Li 1907
17 Kiang Chen 1907
Chu Tung 6 18 Chu Tung 1906 752t, 61.0x9.0x2.4m, 2b,2vte, 1350hp, 13kts, 117p; 2x1-120/40, 2x1-76/40
19 Chu Chien 1906
20 Chu Tai 1906
21 Chu Yu 1907
22 Chu Yiu 1907
23 Chu Kuan 1907
Kuan Chuan 1 24 Kuan Chuan 1908 No picture 305t, 36.3x6.1x2.3m, 1b,1vc, 300hp, 7.9kts, 26p; 2x1-37/32
An Feng 1 25 An Feng 1908 No picture 169t, 37.2x5.6x1.7m, 1b,1vc, 350hp, 12.1kts
Lien Ching 1 26 Lien Ching 1911 No picture 500t, 53.3x7.6x2.9m, 2b,2vte, 925hp, 13.5kts, 60p; 4x1-47/40
Wu Feng 1 27 Wu feng 1912 No picture 200t, 37.8x6.1x2.1m, 1b,1vte, 300hp, 10kts, 46p; 2x1-65/60
Yung Feng 2 28 Yung Feng 1913 1020t, 65.8x9.0x2.4m, 2b,2vte, 1350hp, 13kts, 108p; 25deck; 1x1-105/40, 1x1-76/50, 4x1-47/40, 2x1-37/32
29 Yung Hsiang 1913
Yung Chien 2 30 Yung Chien 1915 1039t, 65.7x9.0x3.5m, 2b,2vte, 1350hp, 13kts, 105p; 25deck; 1x1-102/40, 1x1-76/40, 4x1-47/40, 2x1-37/32
31 Yung Chi 1916
PR Chiang Kung 4 1 Chiang Kung 1909 200t, 44.0x6.0x1.6m, 1b,2vte, 500hp, 14kts, 62p; 1x1-76/40
2 Chiang Chi 1909
3 Chiang Ku 1909
4 Chiang Tai 1909
Chiang Hsi 2 5 Chiang Hsi 1912 140t, 43.9(5)-44.5(6)x7.5(5)-7.3(6)x0.6m, 2b,2vte, 450(5)-500(6)hp, 12kts, 49p; 1x1-88/22
6 Chiang Kun 1912
Chien Chung 3 7 - 9 Chien Chung, Yung An, Kung Chen 1915 - 1916 No picture 90t, 35.5x5.6x0.6m, 1b,2vte, 450hp, 11kts, 42p; 1x1-88/22
Li Sui 1 10 Li Sui 1904 280t, 50.1x8.0x0.9m, 2b,2vte, 1300hp, 13kts, 58p; 1x1-88/30, 1x1-50/40
Li Chieh 1 11 Li Chieh 1910 314t, 54.1x8.7x0.8m, 2b,2vte, 1300hp, 13kts, 58p; 2x1-52/55

COASTAL FORCES

PT Kuai 1 2 1, 2 Kuai 1, 2 1918 13t, 16.4x2.9x1.4m, 2pe, 500hp, 26kts, 8p; 2-450TT, 1DCR
