AUSTRALIA 01 January 1925
CRUISERS
| CL | Chatham | 3 | 1 | Melbourne | 1913 |
|
6000t, 139.6x14.9x4.9m, 12b,4t, 25000hp, 25.5kts, 475p; 51belt, 38deck, 102shields, 102CT(3); 8x1-152/45, 1x1-76/45, 4x1-47/40, 2-533TT |
| 2 | Sydney | 1913 | |||||
| 3 | Brisbane | 1916 | |||||
| Birmingham | 1 | 4 | Adelaide | 1922 | |
6160t, 141.0x15.2x4.9m, 12b,2gt, 25500hp, 25.5kts, 480p; 51belt, 38deck, 102shields, 102CT; 9x1-152/45, 1x1-76/50, 1x1-76/45, 4x1-47/40, 2-533TT |
TORPEDO SHIPS
| DL | Parker | 1 | 1 | Anzac | 1917 |  |
1912t, 99.0x9.7x3.7m, 4b,3t, 36000hp, 34kts, 116p; 4x1-102/40, 2x1-40/39, 2x2-533TT |
| DD | I-Australian | 6 | 1 | Parramatta | 1910 |  |
990t, 75.0x7.8x2.7m, 3b,3t, 13500hp, 27kts, 70p; 1x1-102/40, 3x1-76/40, 3x1-450TT |
| 2 | Yarra | 1910 | |||||
| 3 | Warrego | 1912 | |||||
| 4 | Huon | 1915 | |||||
| 5 | Torrens | 1916 | |||||
| 6 | Swan | 1916 | |||||
| S-Admiralty | 5 | 7 | Stalwart | 1918 |  |
1225t, 84.1x8.1x2.7m, 3b,2gt, 27000hp, 36kts, 90p; 3x1-102/40, 1x1-40/39, 2x2-533TT, 2DCT, 1DCR | |
| 8 | Success | 1919 | |||||
| 9 | Swordsman | 1919 | |||||
| 10 | Tasmania | 1919 | |||||
| 11 | Tattoo | 1919 |
SUBMARINES
| SS | J | 2 | 1 | J4 | 1916 |  |
1204(1)-1212(2)/1820t, 84.0(1)-83.7(2)x7.0x4.3m, 3d/em, 3600/1350hp, 19.5/9.5kts, 44p, 50m; 1x1-102/40, 1x1-40/39, 6-450TT |
| 2 | J7 | 1917 |
ESCORTS
| SL | Acacia | 1 | 1 | Mallow | 1915 |  |
1275t, 80.0x10.1x3.4m, 2b,1vte, 1800hp, 16.5kts, 90p; 2x1-102/40, 2x1-40/39, 2DCT, 1DCR, MS |
| Arabis | 2 | 2 | Geranium | 1916 |  |
1350t, 81.7x10.2x3.4m, 2b,1vte, 2000hp, 16kts, 104p; 2x1-102/40, 2x1-47/50, 2DCT, 1DCR, MS | |
| 3 | Marguerite | 1916 | |||||
| 24 | 1 | 4 | Silvio | 1918 |  |
1493t, 81.5x10.7x3.2m, 2b,1vte, 2500hp, 17kts, 82p; 2x1-102/40, 2DCT, 2DCR, MS |
