Turkey 01 January 1920
BATTLESHIPS
| BB | Torgud Reis | 1 | 1 | Torgud Reis | 1894 | |
10670t, 115.7x19.5x7.6m, 12b,2vte, 10200hp, 16.5kts, 600p; Harvey- 400belt, 60deck, 300barbettes, 300CT; 2x2-283/37, 1x2-283/32, 6x1-105/32, 6x1-88/27, 3-450TT |
| CB | Yavuz Sultan Selim | 1 | 1 | Yavuz Sultan Selim | 1912 | |
25400t, 186.6x29.5x8.7m, 24b,4st, 52000hp, 25.5kts, 1053p; 270belt, 75decks, 230turrets, 350CT; 5x2-283/47, 10x1-149/42, 8x1-88/45, 8x1-88/42, 4-500TT |
CRUISERS
| CL | Mecidiye | 1 | 1 | Mecidiye | 1903 |  |
3967t, 102.4x12.8x4.8m, 16b,2vte, 12500hp, 22kts, 312p; 102slopes, 38deck; 10x1-130/53 |
| Hamidiye | 1 | 2 | Hamidiye | 1904 |  |
3904t, 112.0x14.5x4.9m, 6b,2vte, 12000hp, 22kts, 302p; 102slopes, 38deck; 2x1-152/45, 6x1-120/45, 2x1-47/50, 2x1-37/30, 2x1-450TT |
TORPEDO SHIPS
| PGT | Peyk-i Şevket | 2 | 1 | Peyk-i Şevket | 1907 |  |
775t, 80.1ppx8.4x4.6m, 4b,2vte, 5100hp, 21kts, 105p; 2x1-105/37, 6x1-57/42, 2x1-37/42, (1+2x1)-450TT |
| 2 | Berk-i Satvet | 1907 | |||||
| DD | Samsun | 3 | 1 | Samsun | 1907 |  |
284t, 58.2x6.3x2.8m, 2b,2vte, 5950hp, 28kts, 23p; 1x1-65/50, 6x1-47/50, 2x1-450TT |
| 2 | Taşoz | 1907 | |||||
| 3 | Basra | 1907 | |||||
| TB | Berk Efşan | 1 | 1 | Berk Efşan | 1894 | No picture | 230t, 59.9x6.6x2.4m, 2b,2vte, 3500hp, 21kts, 50p; 6x5-37/27, 2-428TT |
| Hamidiye | 1 | 2 | Yunus | 1902 |  |
145t, 50.6x5.6x1.2m, 3b,2vte, 2400hp, 26kts, 30p; 1x1-47/42 | |
| Akhisar | 1 | 3 | Akhisar | 1904 |  |
165t, 51.0x5.7x1.4m, 2b,2vte, 2400hp, 24kts, 30p; 1x1-47/42, 2x1-37/20, 1x1-450TT | |
| Antalya | 2 | 4 | Draç | 1907 |  |
165t, 51.0x5.7x1.4m, 2b,2vte, 2700hp, 26kts, 30p; 1x1-47/42(5), 2x1-37/20, 2x1-450TT(5) | |
| 5 | Musul | 1907 | |||||
| Demirhisar | 2 | 6 | Sultanhisar | 1907 |  |
101t, 40.2x4.4x1.9m, 2b,1vte, 2200hp, 26kts, 23p; 2x1-37/20, (1+1x2)-450TT | |
| 7 | Sivrihisar | 1907 |
OTHER FIGHTING SHIPS
| PG | Aydin Reis | 4 | 1 | Aydin Reis | 1914 |  |
503t, 54.5x8.2x2.4m, 3b,2vte, 1025hp, 14kts, 75p; 2x1-75/37(1,2) |
| 2 | Preveze | 1914 | |||||
| 3 | Sakiz | 1914 | |||||
| 4 | Bürak Reis | 1914 | |||||
| İsa Reis | 2 | 5 | İsa Reis | 1914 |  |
413t, 47.0x7.9x1.3m, 3b,2vte, 850hp, 14kts, 60p; 3x1-75/48, 2x1-47/50 | |
| 6 | Kemal Reis | 1914 | |||||
| ADV | - | 1 | 1 | Galata | 1896 | 120t | |
| AGS | - | 2 | 1 | İskenderun | 1895 | 142t | |
| 2 | Rüsumet No4 | 1891 | 310t |
COASTAL FORCES
| YP | No1 | 10 | 1-10 | No11, 13-15, 17, 18, 20-23 | 1911-1914 |  |
20t, 18.3ppx3.3x1.6m, 1pe, 70hp, 11.9kts, 6p; 2x1-37/27 |
MINE WARFARE SHIPS
| ML | Nusret | 1 | 1 | Nusret | 1913 |  |
365t, 40.2ppx7.6x3.4m, 2b,2vte, 1200hp, 15kts; 2x1-47/42, 40mines |
| AML | - | 1 | 1 | Selanik | 270t; 25mines |
