World navies yesterday

1915



France 01 January 1915

BATTLESHIPS

BB Terrible 1 1 Requin 1888 7530t, 85.3x18.0x8.0m, 12b,2vte, 11200hp, 15kts, 373p; compound- 500belt, 105deck, 450barbettes, 30CT; 2x1-274/40, 6x1-100/45, 14x1-47/40
Brennus 1 2 Brennus 1896 11190t, 114.0x20.4x8.3m, 32b,2vte, 13900hp, 18kts, 673p; steel/compound- 450belt, 80deck, 450turrets, 150CT; (1x2+1x1)-340/42, 10x1-165/45, 4x1-65/50, 14x1-47/40, 8x1-37/20
Charles Martel 1 3 Charles Martel 1897 11693t, 119.0x21.6x8.4m, 24b,2vte, 14900hp, 18kts, 644p; nickel steel- 450belt, 70deck, 380turrets, 230CT; 2x1-305/45, 2x1-274/45, 8x1-139/45, 4x1-65/50, 16x1-47/40, 8x5-37/20, 2-450TT
Carnot 1 4 Carnot 1897 11954t, 119.0x21.4x8.4m, 24b,2vte, 16300hp, 17.8kts, 647p; nickel steel- 450belt, 70deck, 380turrets, 230CT; 2x1-305/45, 2x1-274/45, 8x1-139/45, 4x1-65/50, 16x1-47/40, 8x5-37/20, 2-450TT
Jauréguiberry 1 5 Jauréguiberry 1897 11637t, 111.9x22.2x8.4m, 24b,2vte, 14400hp, 17.7kts, 631p; nickel steel- 450belt, 70deck, 380turrets, 230CT; 2x1-305/45, 2x1-274/45, 4x2-139/45, 4x1-65/50, 18x1-47/40, 8x5-37/20, 2-450TT
Charlemagne 3 6 Charlemagne 1897 11300t, 117.7x20.2x8.4m, 20b,3vte, 15000hp, 18kts, 694p; Harvey- 400belt, 90deck, 380turrets, 330CT; 2x2-305/40, 10x1-139/45, 8x1-100/45, 20x1-47/40, 4x1-37/20, 2-450TT
7 Gaulois 1899
8 Saint-Louis 1900
Masséna 1 9 Masséna 1898 11735t, 115.5x20.3x8.8m, 24b,3vte, 14200hp, 17kts, 667p; nickel steel- 450belt, 110decks, 400turrets, 350CT; 2x1-305/40, 2x1-274/45, 8x1-139/45, 8x1-100/45, 12x1-47/40, (3x5+5x1)-37/20, 2-450TT
Bouvet 1 10 Bouvet 1898 12007t, 122.6x21.4x8.4m, 32b,3vte, 15000hp, 18kts, 666p; Harvey- 400belt, 70decks, 380turrets, 300CT; 2x1-305/40, 2x1-274/45, 8x1-139/45, 8x1-100/45, 12x1-47/40, (2x5+5x1)-37/20, 2-450TT
Henry IV 1 11 Henry IV 1903 8948t, 108.0x22.2x7.0m, 12b,3vte, 11000hp, 17kts, 464p; Harvey- 280belt, 80deck, 300turrets, 240CT; 2x1-274/40, 7x1-139/45, 12x1-47/40, 2x1-37/20, 2-450TT
Suffren 1 12 Suffren 1903 12892t, 125.9x21.4x8.4m, 24b,3vte, 16700hp, 17kts, 714p; Harvey- 300belt, 110deck, 325turrets, 300CT; 2x2-305/40, 10x1-165/45, 8x1-100/45, 22x1-47/40, 2x1-37/20, 2-450TT
République 2 13 République 1906 14605(13)-14900(14)t, 134.8x24.3x8.4m, 24b,3vte, 18000hp, 19kts, 825p; 280belt, 55deck, 360turrets, 300CT; 2x2-305/40, (6x2+6x1)-165/45, 25x1-47/50, 2-450TT
14 Patrie 1906
Démocratie 3 15 Démocratie 1908 14489-14860t, 134.8x24.3x8.4m, 22b,3vte(15,17)-24b,3vte(16), 18500hp, 19kts, 769p; 280belt, 55deck, 360turrets, 300CT; 2x2-305/40, 10x1-194/50, 13x1-65/50, 10x1-47/50, 2-450TT
16 Justice 1908
17 Verité 1908
Danton 6 18 Condorcet 1911 19763t, 146.6x25.8x9.2m, 26b,4st, 22500hp, 19.2-19.4kts, 681p; 270belt, 93deck, 300turrets, 300CT; 2x2-305/45, 6x2-240/50, 16x1-75/63, 10x1-47/50, 2-450TT
19 Danton 1911
20 Diderot 1911
21 Mirabeau 1911
22 Vergniaud 1911
23 Voltaire 1911
Courbet 4 24 Courbet 1913 25000-26000hp, 168.0x27.9x9.0m, 26b,4st, 28000hp, 20kts, 1085-1108p; 270belt, 70deck, 320turrets, 300CT; 6x2-305/45, 22x1-139/55, 4x1-47/50, 4-450TT
25 France 1914
26 Jean Bart 1913
27 Paris 1914
BC Amiral Tréhouart 2 1 Amiral Tréhouart 1896 6681t, 89.7x17.8x7.1m, 16b,2vte, 8500hp, 16.5-17kts, 343-362p; NS- 450belt, 110deck, 450turrets, 100CT; 2x1-305/45, 8x1-100/45, 4x1-47/40, 10x5-37/20(1), (8x5+4x1)-37/20(2), 2-450TT
2 Bouvines 1894

AIRCRAFT CARRYING SHIPS

AV Foudre 1 1 Foudre 1897 6089t, 118.7x17.2x7.1m, 24b,2vte, 11500hp, 19kts, 410p; Harvey- 120slopes, 60deck, 55shields, 120CT; 8x1-100/45, 4x1-65/50, 8seaplanes

CRUISERS

CA Amiral Charner 3 1 Amiral Charner 1894 4681-4736t, 110.0x14.0x6.0m, 16b,3hte, 8000hp, 18.2kts, 393p; steel- 90belt, 40deck, 110turrets, 110CT; 2x1-194/45, 6x1-139/45, 4x1-65/50, 4x1-47/40, 4-450TT
2 Bruix 1896
3 Latouche-Tréville 1895
Dupuy de Lôme 1 4 Dupuy de Lôme 1895 6676t, 114.0x15.7x7.5m, 20b,2hte+1vte, 13000hp, 19.7kts, 526p; steel- 100belt, 20deck, 200turrets, 130CT; 2x1-194/45, 6x1-165/45, 4x1-65/50, 8x1-47/40, 8x5-37/20, 2-450TT
Pothuau 1 5 Pothuau 1897 5374t, 113.0x15.3x6.5m, 18b,2vte, 10000hp, 19kts, 459p; NS- 60belt, 35deck, 170turrets, 230CT; 2x1-194/40, 10x1-139/45, 10x1-47/40, 8x1-37/20, 4-450TT
Jeanne d'Arc 1 6 Jeanne d'Arc 1902 11270t, 145.4x19.4x8.1m, 36b,3vte, 28000hp, 21kts, 651p; Harvey- 150belt, 65deck, 160turrets, 150CT; 2x1-194/40, 14x1-139/45, 16x1-47/40, 2-450TT
Gueydon 3 7 Montcalm 1902 9177(7)-9548(8)-9367(9)t, 138.0x19.4x7.7m, 20b,3vte(7)-28b,3vte(8,9), 19600(7,8)-22000(9)hp, 21(7,8)-22(9)kts, 566p; Harvey- 150belt, 55deck, 200turrets, 160CT; 2x1-194/40, 8x1-165/45, 4x1-100/45, 16x1-47/40, 4x1-37/20, 2-450TT
8 Gueydon 1903
9 Dupetit-Thouars 1905
Dupleix 3 10 Dupleix 1903 7432(10)-7547(11)-7602(12)t, 130.0x17.8x7.4m, 24b,3vte(10,11)-20b,3vte(12), 17500hp, 21kts, 531p; Harvey- 100belt, 70deck, 160turrets, 80CT; 4x2-165/45, 4x1-100/45, 10x1-47/40, 4x1-37/20, 2-450TT
11 Desaix 1904
12 Kléber 1904
Gloire 4 13 Amiral Aube 1904 9534(13)-10233(14)-10212(15)-9458(16)t, 139.8x20.2x7.5-7.7m, 24b,3vte(13,16)-28b,3vte(14,15), 21800hp, 21.5kts, 615p; Harvey- 150belt, 80deck, 170turrets, 150CT; 2x1-194/40, 8x1-165/45, 6x1-100/45, 18x1-47/40, 2-450TT
14 Condé 1904
15 Gloire 1904
16 Marseillaise 1903
Léon Gambetta 3 17 Léon Gambetta 1905 11959(17)-12379(18)-13108(19)t, 146.5x21.4x8.1-8.4m, 28b,3vte(17,19)-20b,3vte(18), 28500hp, 22.5kts, 728p; 150belt, 35deck, 200turrets, 200CT; 2x2-194/40, (6x2+4x1)-165/45, 24x1-47/40, 2x1-37/20, 2-450TT
18 Jules Ferry 1905
19 Victor Hugo 1907
Jules Michelet 1 20 Jules Michelet 1908 13105t, 146.5x21.4x8.4m, 28b,3vte, 30000hp, 22.5kts, 770p; 150belt, 35deck, 200turrets, 200CT; 2x2-194/50, 12x1-165/45, 24x1-47/50, 2-450TT
Ernest Renan 1 21 Ernest Renan 1909 13504t, 159.0x21.3x8.4m, 42b,3vte, 36000hp, 23kts, 824p; 150belt, 35deck, 200turrets, 200CT; 2x2-194/50, 12x1-165/45, 16x1-65/50, 8x1-47/50, 2x1-37/20, 2-450TT
Edgar Quinet 2 22 Edgar Quinet 1911 13847(22)-13995(23)t, 158.9x21.5x8.4m, 40b,3vte(22)-42b,3vte(23), 36000hp, 23kts, 859-892p; 150belt, 35deck, 200turrets, 200CT; (2x2+10x1)-194/50, 20x1-65/50, 2-450TT
23 Waldeck-Rousseau 1911
CL Forbin 1 1 Surcouf 1890 2012t, 95.0x9.0x5.2m, 6b,2hc, 5800hp, 20-20.5kts, 199p; steel- 40deck, 20CT; 4x1-139/30, 8x1-47/40, 4x5-37/20, 150mines
Amiral Cécille 1 2 Amiral Cécille 1890 5839t, 115.5x15.0x6.8m, 12b,4vc/2, 10200hp, 19.4kts, 517p; steel- 100slopes, 55deck, 90CT; 8x1-165/30, 10x1-139/30, 6x1-47/40, 14x5-37/20, 3-380TT
Troude 1 3 Cosmao 1891 1923t, 95.0x9.0x5.2m, 5b,2hc, 5800hp, 20.5kts, 201p; steel- 40deck; 4x1-139/30, 10x1-47/40, 4x1-37/20, 150mines
Linois 1 4 Lavoisier 1898 2318t, 100.6x10.6x5.4m, 16b,2vte, 6800hp, 20.5kts, 201p; steel- 40deck, 75shields, 125CT; 4x1-139/45, 2x1-100/45, 10x1-47/40, 2-450TT
Friant 1 5 Friant 1895 3982t, 97.0x13.0x6.3m, 20b,2vte, 9500hp, 18.7kts, 339p; steel- 80slopes, 30deck, 50shields, 75CT; 6x1-165/45, 4x1-100/45, 4x1-47/40, 11x1-37/20, 2-350TT
Descartes 1 6 Descartes 1896 3960t, 99.0x13.0x6.5m, 16b,2vte, 8500hp, 19.5kts, 383p; steel- 60slopes, 45deck, 50shields, 70CT; 4x1-165/45, 10x1-100/45, 8x1-47/40, 4x1-37/20, 2-450TT
D'Assas 2 7 Cassard 1898 3890t, 99.0x13.7x6.3m, 20b,2vte, 10000hp, 20kts, 370-392p; 100slopes, 70deck, 50shields, 100CT; 6x1-165/45, 4x1-100/45, 10x1-47/40, 9x1-37/20, 2-450TT
8 Du Chayla 1898
D'Entrecasteaux 1 9 D'Entrecasteaux 1899 8142t, 120.0x17.8x7.5m, 5b,2vte, 14500hp, 19.2kts, 559p; Harvey- 100slopes, 55deck, 250turrets, 250CT; 2x1-240/40, 12x1-139/30, 12x1-47/40, 6x1-37/20, 6-450TT
Guichen 1 10 Guichen 1899 8151t, 139.0x17.0x7.5m, 36b,3vte, 25000hp, 23.5kts, 604p; Harvey- 100slopes, 55deck, 60casemates, 160CT; 2x1-165/45, 6x1-139/45, 10x1-47/40, 5x1-37/20, 2-450TT
D'Estrées 1 11 D'Estrées 1899 2428t, 95.0x12.0x5.4m, 8b,2vte, 8500hp, 20.5kts, 235p; steel- 43deck; 2x1-139/45, 4x1-100/45, 8x1-47/40, 2x1-37/20
Châteaurenault 1 12 Châteaurenault 1902 7898t, 135.0x17.0x7.4m, 14b,3vte, 23000hp, 24kts, 604p; Harvey- 100slopes, 55deck, 60casemates, 160CT; 2x1-165/45, 6x1-139/45, 10x1-47/40, 5x1-37/20
Jurien de la Gravière 1 13 Jurien de la Gravière 1903 5595t, 137.0x15.0x6.3m, 24b,3vte, 17400hp, 22.9kts, 463p; 65slopes, 80deck, 70shields, 100CT; 8x1-165/45, 10x1-47/40, 6x1-37/20, 2-450TT
CLL Kersaint 1 1 Kersaint 1898 1276t, 68.6x10.5x4.6m, 4b,1vte, 2400hp, 16kts, 146p; 1x1-139/45, 5x1-100/45, 7x1-37/20
AMC - 17 1 Amazone II 1896   6357brt, 135.0x15.5m, 2st, 18kts
2 Burdigala 1897   12480brt, 177.3x19.4m, 2vqe, 19kts
3 Caledonien 1882   4233brt, 126.2x12.6m, 1vc, 15kts
4 Carthage 1910   5601brt, 122.8x15.6m, 2st, 19kts
5 Europe 1906   4756brt, 112.5x14.0m, 2st, 14kts
6 Flandre 1913   8503brt, 141.5x17.4m, 4vteet, 17kts
7 Gallia 1913   14966brt, 175.0x19.1m, 3vteet, 20kts
8 Golo II 1905   1380brt, 80.2x10.5m, 1vte, 17kts; 2x1-65/50, 2x1-47/40
9 Lorraine II 1899   11146brt, 171.6x18.3m, 2vte, 20kts
10 Lutetia 1913   14581brt, 176.5x19.5m, 4vte/st, 20kts
11 Newhaven 1910   1656brt, 89.0x10.5m, 3st, 23.5kts
12 Niagara 1908   8481brt, 147.9x17.1m, 2vte, 15kts
13 Provence II 1905   13753brt, 183.6x19.8m, 2vte, 22kts; 5x1-139/45, 4x1-47/40
14 La Savoie 1900   11168brt, 171.6x18.3m, 2vte, 20kts
15 Sant'anna 1910   9350brt, 143.3x17.2m, 2vte, 16kts
16 Timgad 1911   5232brt, 122.6x15.7m, 2vte, 18.5kts
17 La Touraine 1890   8893brt, 158.5x17.1m, 2vte, 19kts

TORPEDO SHIPS

PGT Condor 1 1 Faucon 1887 1311t, 68.0ppx9.0x4.7m, 4b,2ic, 3000hp, 17kts, 137p; steel- 40deck; 5x1-100/26, 4x1-47/40, 6x5-37/20
D'Iberville 3 2 D'Iberville 1894 952(2)-970(3,4)t, 81.9x8.1(2)-8.2(3,4)x3.5m, 8b,2vqe(2,3)-8b,2vte(4), 5000hp, 21.5-22kts, 143(2)-140(3,4)p; steel- 20belt(3,4), 40slopes(2), 20deck(3,4), 40CT(2); 1x1-100/45, 3x1-65/50, 6x1-47/40(2), 97mines(3,4)
3 Cassini 1895
4 Casabianca 1896
Dunois 2 5 Dunois 1898 889t, 78.0x8.4x3.9m, 8b,2vte, 7500hp, 21.7-22kts, 137p; steel- 25belt, 10deck, 50CT; 6x1-65/50, 6x1-47/40
6 La Hire 1899
DD Durandal 3 1 Durandal 1899 296(1,2)-306(3)t, 57.6x6.3x3.2m, 2b,2vte, 4800hp, 26kts, 52p; 1x1-65/50, 6x1-47/40, 2x1-380TT
2 Hallebarde 1899
3 Fauconneau 1900
Framée 3 4 Yatagan 1900 314t, 58.1x6.3x3.0m, 4b,2vte, 4800-5200hp, 26kts, 48p; 1x1-65/50, 6x1-47/40, 2x1-380TT
5 Pique 1901
6 Epée 1901
Pertuisane 4 7 Pertuisane 1902 344t, 57.6x6.3x3.2m, 2b,2vte, 4800hp, 26kts, 52p; 1x1-65/50, 6x1-47/40, 2x1-380TT
8 Escopette 1903
9 Flamberge 1903
10 Rapière 1903
Arquebuse 19 11 Carabine 1903 298t, 58.2x6.4x3.2m, 2b,2vte, 6300hp, 28kts, 60p; 1x1-65/50, 6x1-47/40, 2x1-380TT
12 Sarbacane 1903
13 Arquebuse 1903
14 Arbalète 1903
15 Javeline 1903
16 Sagaie 1903
17 Epieu 1903
18 Harpon 1903
19 Fronde 1903
20 Francisque 1904
21 Sabre 1904
22 Dard 1904
23 Baliste 1904
24 Mousqueton 1904
25 Arc 1904
26 Pistolet 1903
27 Bélier 1904
28 Catapulte 1903
29 Bombarde 1903
Claymore 13 30 Stylet 1907 350t, 58.5x6.5x3.0m, 2b,2vte, 6800hp, 28kts, 60p; 1x1-65/50, 6x1-47/50, 2x1-450TT
31 Tromblon 1907
32 Pierrier 1908
33 Obusier 1907
34 Mortier 1908
35 Claymore 1906
36 Carquois 1908
37 Trident 1909
38 Fleuret 1908
39 Coutelas 1908
40 Cognée 1908
41 Hache 1909
42 Massue 1909
Branlebas 10 43 Sabretache 1908 339t, 57.9x6.6x2.4m, 2b,2vte, 6800hp, 27.5kts, 60p; 1x1-65/50, 6x1-47/50, 2x1-450TT
44 Oriflamme 1908
45 Étendard 1909
46 Fanion 1909
47 Sape 1908
48 Gabion 1908
49 Branlebas 1908
50 Fanfare 1908
51 Glaive 1910
52 Poignard 1910
Spahi 7 53 Carabinier 1909 550t, 67.0x6.6x2.3-2.4m, 4b,2vte, 7500(53,55-59)-9000(54)hp, 28kts, 77-79p; 6x1-65/50, (1+2x1)-450TT
54 Spahi 1910
55 Hussard 1911
56 Lansquenet 1910
57 Mameluk 1911
58 Enseigne Henry 1912
59 Aspirant Herber 1912
Chasseur 4 60 Chasseur 1909 520t, 67.0x6.5-6.7x3.1m, 4b,3st(60,62,63)-3b,3st(61), 7200hp, 28kts, 77-79p; 6x1-65/50, (1+2x1)-450TT(60-62), 2x1-450TT(63)
61 Janissaire 1911
62 Fantassin 1911
63 Cavalier 1911
Voltigeur 2 64 Voltigeur 1910 590t, 65.5pp(64)-63.0pp(65)x6.8(64)-6.4(65)x3.1(64)-2.9(65)m, 4b,1vte+2st, 7500hp, 28kts, 76-77p; 6x1-65/50, (1+2x1)-450TT
65 Tirailleur 1910
Bouclier 12 66 Bouclier 1911 760-820t, 72.3-78.3x7.6-8.0x2.9-3.3m, 4b,3st(66,68)-4b,2st(67,69-77), 13000hp, 30kts, 80-83p; 2x1-100/45, 4x1-65/50, 2x2-450TT
67 Boutefeu 1911
68 Casque 1911
69 Cimeterre 1912
70 Dague 1912
71 Faulx 1912
72 Fourche 1912
73 Capitaine Mehl 1912
74 Commandant Bory 1913
75 Commandant Rivière 1913
76 Dehorter 1913
77 Francis Garnier 1913
Bisson 6 78 Bisson 1913 855t, 78.1ppx8.6x3.1m, 4b,2st, 15000hp, 30kts, 80-83p; 2x1-100/45, 4x1-65/50, 2x2-450TT
79 Renaudin 1913
80 Commandant Lucas 1914
81 Protet 1914
82 Mangini 1914
83 Magon 1914
Aventurier 4 84 Opiniâtre 1914 1250t, 88.5x8.8x3.1m, 5b,2st, 18000hp, 32kts, 140p; 4x1-100/45, 1x1-47/50, 4x1-450TT
85 Aventurier 1914
86 Téméraire 1914
87 Intrépide 1914
TB Coureur 1 1 Grondeur 1892 131t, 45.1x4.4x1.4m, 2b,2vte, 1750hp, 23.5kts; 2x1-47/40, 2-350TT
Agile 1 2 Orage 1892 119t, 43.6x4.6x1.1m, 2b,1vte, 1100hp, 27kts; 3x5-37/20, (1+1x1)-380TT
Avant-Garde 1 3 Grenadier 1892 129t, 41.9ppx4.5x1.3m, 2b,2vte, 1750hp, 21kts, 27p; 2x1-47/40, (1+1x1)-350TT
Chevalier 1 4 Chevalier 1894 135t, 43.8x4.5x1.5m, 2b,2vte, 2200hp, 24.5kts; 2x5-37/20, 2x1-450TT
Averne 1 5 Averne 1894 131t, 43.9x4.6x1.3m, 2b,2vte, 1750hp, 23.5kts; 2x1-47/40, (1+1x1)-380TT
Filibustier 2 6 Ariel 1895 123t, 42.0x4.5x1.7m, 2b,2vte, 2000hp, 23.5kts; 2x1-47/40, (1+1x1)-380TT
7 Aquilon 1896
Forban 1 8 Forban 1896 150t, 44.0x4.6x1.4m, 2b,2vte, 3260hp, 29kts, 29p; 2x1-37/20, 2x1-380TT
Cyclone 5 9 Cyclone 1899 150(9)-165(10-13)t, 46.4(9)-46.6(10-13)x4.7(9)-4.8(10-13)x1.5m, 2b,2vte, 4200(9)-3800(10-13)hp, 29kts; 2x1-47/40, 1x2-380TT
10 Bourrasque 1902
11 Rafale 1902
12 Borée 1901
13 Tramontane 1902
Mistral 6 14 Mistral 1901 183t, 45.0x5.2x1.6m, 2b,2vte, 4200hp, 26kts, 30p; 24belt, 9deck; 2x1-47/40, 2x1-380TT
15 Siroco 1901
16 Simoun 1901
17 Typhon 1903
18 Trombe 1902
19 Audacieux 1900
TB2 No130 1 1 No135 1890 52t, 34.0ppx3.5x0.9m, 1b,1vte, 720hp, 20kts, 18p; 2x1-37/20, 2x1-380TT
No145 1 2 No158 1892 78t, 35.9ppx3.9x1.2m, 1b,1vte, 1000hp, 21kts, 22-23p; 2x5-37/20, (1+1x1)-380TT
No201 46 3-48 No206, Marteau, Foyer, Ragas, Ringard, Rouable, 224, Etau, 231, Enclume, 238, 239, 6S, 243, 250, 252, 16S, 256, 258-260, 263-270, 273-276, 278-283, 17S-19S, 288, 289, 20S, 21S 1897-1904 83-90t, 37.0x4.2x1.2m, 2b,1vte(3-15, 17-48)-2b,1st(16), 1500-1800(3-15,17-48)-1900(16)hp, 24(3-35)-26(36-48)kts, 23p; 2x5-37/20, (1+1x1)-380TT
No295 73 49 No295 1906 103-105t, 38.0x4.4x1.9m, 2b,1vte, 1800-2000hp, 26kts, 23p; 2x5-37/20, (1+1x2)-450TT
50 No296 1906
51 No297 1906
52 No298 1906
53 No299 1906
54 No300 1908
55 No301 1906
56 No302 1906
57 No303 1905
58 No304 1906
59 No305 1906
60 No306 1905
61 No307 1905
62 No308 1906
63 No309 1906
64 No310 1906
65 No311 1906
66 No312 1905
67 No313 1905
68 No314 1906
69 No315 1905
70 No316 1906
71 No317 1906
72 No318 1907
73 No319 1907
74 No320 1907
75 No321 1907
76 No322 1906
77 No323 1906
78 No324 1906
79 No325 1906
80 No326 1907
81 No327 1907
82 No328 1907
83 No329 1907
84 No330 1908
85 No331 1908
86 No332 1907
87 No333 1907
88 No334 1907
89 No335 1907
90 No336 1907
91 No337 1908
92 No338 1906
93 No339 1906
94 No340 1907
95 No341 1906
96 No342 1906
97 No343 1906
98 No344 1906
99 No345 1906
100 No346 1906
101 No349 1906
102 No350 1906
103 No351 1906
104 No352 1907
105 No353 1907
106 No354 1907
107 No355 1906
108 No356 1907
109 No357 1907
110 No358 1907
111 No359 1906
112 No360 1906
113 No361 1906
114 No362 1906
115 No363 1906
116 No364 1906
117 No365 1908
118 No366 1909
119 No367 1907
120 No368 1907
121 No369 1908

SUBMARINES

SS Sirène 4 1 Sirène 1901 157/213t, 32.5x3.9x2.5m, 1b,1vte/em, 250/100hp, 9.8/5.8kts, 13p, 30m; 4-450TC
2 Triton 1901
3 Espadon 1902
4 Silure 1902
Aigrette 2 5 Aigrette 1905 178/253t, 35.9x4.0x2.6m, 1d/em, 150/130hp, 9.3/6.2kts, 14p, 30m; 4-450TC
6 Cigogne 1905
Émeraude 6 7 Émeraude 1908 392/425t, 44.9x3.9x3.6m, 2d/em, 600/200hp, 11.5/9.2kts, 21p, 40m; 6-450TT
8 Opale 1908
9 Rubis 1909
10 Saphir 1909
11 Topase 1910
12 Turquoise 1910
Pluviôse 17 13 Pluviôse 1908 398/550t, 51.1x4.9x3.0m, 2b,2vte/em, 700/450hp, 12/8kts, 24p, 40m; 1-450TT(14-16,21,23), 6-450TC
14 Ventôse 1908
15 Germinal 1908
16 Floréal 1909
17 Prairial 1909
18 Messidor 1909
19 Papin 1909
20 Fresnel 1909
21 Monge 1909
22 Thermidor 1910
23 Fructidor 1910
24 Berthelot 1910
25 Ampère 1910
26 Gay-Lussac 1911
27 Watt 1910
28 Cugnot 1910
29 Giffard 1910
Argonaute 1 30 Argonaute 1911 306/409t, 48.9x4.2x2.8m, 2b,1vte/em, 350/230hp, 10.2/6kts, 22p, 30m; 2-450TT, 4-450TC
Archimède 1 31 Archimède 1911 598/811t, 60.5x5.6x4.1m, 2b,2vte/em, 1700/1230hp, 14.9/11kts, 26p, 40m; 1-450TT, 6-450TC
Brumaire 15 32 Brumaire 1913 397/551t, 52.1x5.1x3.1m, 2d/em, 840/660hp, 13/8.8kts, 29p, 40m; 1-450TT, 6-450TC
33 Frimaire 1913
34 Nivôse 1913
35 Foucault 1914
36 Euler 1914
37 Franklin 1914
38 Faraday 1913
39 Volta 1913
40 Newton 1914
41 Montgolfier 1914
42 Bernouilli 1913
43 Joule 1913
44 Coulomb 1914
45 Arago 1914
46 Le Verrier 1914
Circé 1 47 Circé 1909 351/491t, 47.1x4.9x3.0m, 2d/em, 630/460hp, 11.9/7.7kts, 22p, 40m; 1x1-47/50, 6-450TC
Mariotte 1 48 Mariotte 1913 531/627t, 64.7x4.3x3.8m, 2d/em, 1400/1000hp, 14.3/11.7kts, 29p, 40m; 4-450TT, 2-450TC
Charles Brun 1 49 Charles Brun 1913 356/450t, 44.0x4.0x3.3m, 4b,2vte, 1300hp, 13.5/7.2kts, 24p, 40m; 2-450TT, 4-450TC
Amiral Bourgois 1 50 Amiral Bourgois 1914 556/735t, 56.2x5.5x3.6m, 2d/em, 1400/1000hp, 13.9/8.7kts, 25p, 40m; 4-450TT
Gustave Zédé 1 51 Gustave Zédé 1914 849/1098t, 74.0x6.0x3.7m, 2b,2vte/em, 3500/1640hp, 17.6/11.4kts, 47p, 50m; 1x1-75/34, 1x1-47/50, 2-450TT, 6-450TC

OTHER FIGHTING SHIPS

PG Achéron 1 1 Styx 1892 1767t, 58.7x12.3x3.6m, 4b,2hc, 1600hp, 11.6-13kts, 110p; compound- 200belt, 50deck, 200turret; 1x1-274/29, 1x1-139/28, 2x1-47/40, 7x5-37/20
Surprise 2 2 Surprise 1896 617-637t, 56.0-56.3ppx7.9-8.0x3.7m, 2b,1hte, 900hp, 13kts, 99p; 2x1-100/45, 4x1-65/50, 4x1-37/20
3 Décidée 1898
PR Vigilante 3 1 Argus 1900 No picture 123t, 44.2x7.3x0.6m, 2b,2vte, 500hp, 13kts, 53p; 2x1-90/24, 4x1-37/20
2 Vigilante 1900
3 Peï-Ho 1901
Doudart de la Grée 1 4 Doudart de la Grée 1909 183t, 54.4x6.7x1.0m, 2b,2vte, 900hp, 14kts, 66p; 6x1-37/20

MINE WARFARE SHIPS

ML Pluton 2 1 Pluton 1913 660t, 59.0x8.3x3.3m, 1vte, 3000hp, 20kts, 90p; 2x1-100/45, 1x1-75/63, 120mines
2 Cerbère 1912
MS Herse 4 1 Charrue 1914 No picture 255t, 34.0x6.8x2.4m, 1vte, 600hp, 12kts; 2x1-47/40, sweeps
2 Herse 1914
3 Pioche 1914
4 Rateau 1914
ATL - 5 1 Orient     385t
2 Damier     155t
3 Lorientais     433t
4 Alcyon I     300t
5 Iroise 1907   240t





Custom Search

© Ivan Gogin, 2014
