World navies yesterday

1900

Russia 01 January 1900

BATTLESHIPS

BB	Pyotr Velikiy	1	1	Pyotr Velikiy	1876		10460t, 103.5x19.0x8.3m, 12b,2vc, 8250hp, 14.3kts, 440p; iron- 356belt, 76deck, 356turrets; 2x2-305/17, 4x1-87/17, 6x1-47/40, 4x5-37/17, 2x4-25/40, 2-381TT
	Yekaterina II	4	2	Yekaterina II	1888		11048(2)-10930(3)-10181(4)-10750(5)t, 103.5x21.0x8.8m, 14b,2vc(2,3)-16b,2vte(4,5), 9100(2,3)-13000(4,5)hp, 15(2,3)-16(4)-16.5(5)kts, 633-645p; compound(2-4)-steel(5), 406belt, 38(2)-57(3-5)deck, 305redoubt, 292(2-4)-305(5)CT; 3x2-305/27(2,4), 3x2-305/32(3,5), 7x1-152/32, 2x1-63/17(3-5), 8x1-47/40(5), 8x5-47/22(2-4), 10x1-37/20(5), 4x5-37/17(2-4), 7-381TT, 100mines
			3	Chesma	1889
			4	Sinop	1889
			5	Georgiy Pobedonosets	1893
	Imperator Aleksandr II	2	6	Imperator Aleksandr II	1890		10010(6)-9672(7)t, 105.6x20.4x7.8m, 12b,2vc(6)-12b,2hte(7), 8500hp, 15.3kts, 616p; compound- 356belt, 63deck, 254barbette(6), 254turret(7), 254(6)-203(7)CT; 1x2-305/27, 4x1-229/32, 8x1-152/32, 4x1-63/17(6), 2x1-63/17(7), 10x5-47/22, 8x5-37/17, 5-381TT(6), 6-381TT(7)
			7	Imperator Nikolay I	1891
	Dvenadtsat Apostolov	1	8	Dvenadtsat Apostolov	1892		8709t, 104.2x18.3x8.4m, 8b,2vte, 8750hp, 15.7kts, 599p; compound- 356belt, 63deck, 305barbettes, 203CT; 2x2-305/27, 4x1-152/32, 12x1-47/40, 10x1-37/20, 4x5-37/17, 6-381TT
	Navarin	1	9	Navarin	1896		10206t, 109.0x20.4x8.4m, 12b,2vte, 9140hp, 15.5kts, 622p; compound- 406belt, 76deck, 305turrets, 254CT; 2x2-305/32, 8x1-152/32, 2x1-63/17, 8x1-47/40, 15x1-37/20, 6-381TT
	Sisoy Velikiy	1	10	Sisouy Velikiy	1896		10400t, 107.2x20.7x7.8m, 12b, 2vte, 8500hp, 15.7kts, 582p; NS- 406belt, 76deck, 305turrets, 203CT; 2x2-305/38, 6x1-152/44, 2x1-63/17, 12x1-47/40, 12x5-37/17, 6-381TT
	Poltava	3	11	Poltava	1896		11500(11)-11354(12)-11842(13)t, 114.3x21.3x7.9m, 14b,2vte(11,12)-16b,2vte(13), 10600hp, 16.5kts, 652p; NS(12)-Harvey(13) 368(11,13)-406(12)belt, 76deck, 254turrets, 229CT; 2x2-305/38, (4x2+4x1)-152/44, 12x1-47/40(11,13), 10x1-47/40(12), 28x1-37/20, 2-450TT, 4-381TT, 50mines
			12	Petropavlovsk	1897
			13	Sevastopol	1898
	Tri Svyatitelya	1	14	Tri Svyatitelya	1897		13318t, 115.1x22.3x8.7m, 14b,2vte, 11300hp, 753p; Harvey+NS- 457belt, 76deck, 406turrets, 305CT; 2x2-305/38, 14x1-152/44, 4x1-120/43, 2x1-63/17, 10x1-47/40, 10x1-37/20, 6-381TT
	Rostislav	1	15	Rostislav	1898		10140t, 107.2x20.7x6.7m, 12b,2vte, 8700hp, 15.6kts, 632p; Harvey- 356belt, 76deck, 254turrets, 152CT; 2x2-254/43, 4x2-152/44, 2x1-63/17, 12x1-47/40, 14x1-37/20, 6-381TT
BC	Pervenets	3	1	Pervenets	1863		4000t, 67.6(1)-69.4(2)-67.3(3)x16.2x4.6m, 2b,1hda(1)-4b,1hda(2,3), 1067(1)-1232(2)-870(3)hp, 8(1,2)-9(3)kts, 394-459p; iron- 114belt, 29deck(3), 114battery, 114CT(2,3); 6x1-203/19(1), 12x1-203/19(2), 8x1-203/19(3), 2x1-152/32(1), 4x1-152/25(1), 2x1-152/25(2), 7x1-152/32(3), 2x1-120/43(1), 1x1-107/17(1), 2x1-87/17(1), 2x1-63/17, 2x1-47/40(1), 4x1-47/40(3), 4x1-37/20(3), 5x5-37/17(1)
			2	Ne Tron Menya	1865
			3	Kreml	1867
	Smerch	1	4	Smerch	1865		1460t, 57.4x11.6x3.7m, 2b,2hda, 700hp, 8kts, 155p; iron- 114side, 25deck, 152turrets; 2x1-229/19, 4x1-87/21, 4x5-37/17
	Admiral Lazarev	2	5	Admiral Lazarev	1869		3820(5)-3768(6)t, 77.7x13.1x6.2m, 4b,1hda, 2020hp, 10.5(5)-11(6)kts, 274p; iron- 114side, 114turrets, 127CT; 3x1-279/18, 2x1-63/17, 5x1-47/40, 2x1-37/20
			6	Admiral Greyg	1869
	Admiral Spiridov	2	7	Admiral Spiridov	1869		3925(7)-3851(8)t, 77.5x13.1x6.2m, 4b,1hda, 2030hp, 10.5kts, 260p; iron- 152side, 152(7)-178(8)turrets; 2x1-279/18, 2x1-63/17, 1x1-47/40, 4x1-37/20
			8	Admiral Chichagov	1869
	Rusalka	1	9	Charodeyka	1869		2100t, 62.9x12.8x3.8m, 2b,2hda, 875hp, 8.5kts, 178p; iron- 114side, 25deck, 152turrets; 2x2-229/19, 4x1-87/17, 5x5-37/17
	Novgorod	1	10	Novgorod	1874		2491t, 30.8x30.8x4.1m, 8b,4hc, 2000hp, 6kts, 149p; iron- 229sides, 70deck, 229barbette; 1x2-279/17, 2x1-87/17, 2x5-37/17
	Vitse-Admiral Popov	1	11	Vitse-Admiral Popov	1876		3550t, 36.6x36.6x4.1m, 8b,4hc, 3066hp, 6kts, 203p; iron- 406sides, 76deck, 406barbette; 1x2-305/17, 6x1-87/17, 2x5-37/17
	Admiral Ushakov	3	12	Admiral Ushakov	1897		4648(12)-4792(13)-4152(14)t, 86.4x15.9x6.1m, 4b,2hte, 4250hp, 16(12,13)-15(14)kts, 406p; Harvey- 254belt, 51deck, 178turrets, 178CT; 2x2-254/43(12,13), (1x2+1x1)-254/43(14), 4x1-120/43, 2x1-63/17, 6x1-47/40(12,13), 10x1-47/40(14), 18x1-37/20(12,13), 12x1-37/20(14), 4-381TT
			13	Admiral Senyavin	1897
			14	General-Admiral Apraksin	1899
MON	Bronenosets	10	1	Bronenosets	1865		1565t, 61.3x14.0x3.8m, 2b,1hda, 340-530hp, 6.5-8kts, 111p; iron- 229side, 25(10)deck, 254turret, 203CT; 1x2-229/19, 2x1-47/40, 2x5-37/17
			2	Uragan	1865
			3	Tifon	1865
			4	Veshchun	1865
			5	Koldun	1865
			6	Latnik	1865
			7	Edinorog	1865
			8	Strelets	1865
			9	Lava	1865
			10	Perun	1865

CRUISERS

CA	Knyaz Pozharskiy	1	1	Knyaz Pozharskiy	1869		5138t, 83.1x14.9x7.5m, 8b,1hda, 2835hp, 11.7kts, 495p; iron- 102belt, 114battery; 2x1-203/19, 2x1-152/23, 4x1-87/17, 2x1-63/17, 2x1-47/40, 6x5-37/17
	General-Admiral	2	2	General-Admiral	1875		5031(2)-4838(3)t, 91.0(2)-86.9(3)x14.6x7.0(2)-7.3(3)m, 5b,1vc(2)-4b,1vc(3), 4470(2)-5222(3)hp, 12.3(2)-13.2(3)kts, 490p; iron- 152belt, 25deck; 4x1-203/28(3), 5x1-152/25(3), 4x1-152/23(2), 6x1-87/21, 6x1-47/40(2), 8x1-37/20(2), 10x5-37/17(3), 1-381TT(2), 3-381TT(3)
			3	Gertsog Edinburgskiy	1877
	Minin	1	4	Minin	1878		6136t, 89.9x15.1x7.7m, 18b,1vte, 4000hp, 12.2kts, 545p; compound- 178belt, 25deck; 4x1-203/28, 6x1-152/44, 4x1-87/17, 6x1-75/48, 2x1-63/17, 8x1-47/40, 2-381TT, 150mines
	Vladimir Monomakh	1	5	Vladimir Monomakh	1883		6000t, 93.3x15.9x8.0m, 8b,2vc, 7000hp, 15.2kts, 566p; compound- 152belt, 13deck; 5x1-152/44, 6x1-120/43, 2x1-63/17, 16x1-47/40, 4x1-37/20, 3-381TT
	Dmitriy Donskoy	1	6	Dmitriy Donskoy	1885		6200t, 93.4x15.9x7.9m, 8b,1vc, 7000hp, 16.5kts, 571p; compound- 152belt, 13deck; 6x1-152/44, 10x1-120/43, 2x1-63/17, 6x1-47/40, 10x1-37/20, 5-381TT
	Admiral Nakhimov	1	7	Admiral Nakhimov	1888		8524t, 103.3x18.6x8.4m, 12b,2vc, 8000hp, 17kts, 570p; compound- 254belt, 76deck, 203barbettes, 152CT; 4x2-203/33, 10x1-152/32, 2x1-63/17, 12x1-47/40, 6x1-37/20, 3-381TT, 40mines
	Pamyat Azova	1	8	Pamyat Azova	1890		6674t, 117.2x17.2x8.2m, 6b,2vte, 8500hp, 17kts, 640p; compound- 152belt, 63deck, 51shields, 38CT; 2x1-203/33, 13x1-152/32, 2x1-63/17, 7x1-47/40, 8x5-37/17, 3-381TT
	Ryurik	1	9	Ryurik	1895		11690t, 132.6x20.4x7.9m, 8b,2vte, 13250hp, 18kts, 683p; steel- 254belt, 76deck, 51shields, 152CT; 4x1-203/33, 16x1-152/44, 6x1-120/43, 2x1-63/17, 10x1-47/40, 12x5-37/17, 6-381TT
	Rossiya	1	10	Rossiya	1897		12195t, 147.8x20.9x7.9m, 32b,3vte, 17000hp, 19.7kts, 839p; Harvey- 203belt, 76deck, 127casemates, 305CT; 4x1-203/43, 16x1-152/44, 12x1-75/48, 20x1-47/40, 18x1-37/20, 5-381TT
	Gromoboy	1	11	Gromoboy	1899		12455t, 146.6x20.9x7.9m, 32b,3vte, 14500hp, 19kts, 874p; 152belt, 76deck, 127casemates, 305CT; 4x1-203/43, 16x1-152/44, 24x1-75/48, 12x1-47/40, 18x1-37/20, 4-381TT
CL	Vityaz	1	1	Rynda	1886		3537t, 79.4x13.7x5.3m, 10b,1hc, 3000hp, 11.5kts, 396p; steel- 38deck; 4x1-152/25, 4x1-87/21, 2x1-47/40, 6x5-37/17, 1-381TT
	Admiral Kornilov	1	2	Admiral Kornilov	1888		5880t, 112.2x14.8x7.8m, 8b,2hte, 5977hp, 17.6kts, 479p; steel- 63deck, 76CT; 14x1-152/32, 6x1-47/40, 10x5-37/17, 6-381TT
	Svetlana	1	3	Svetlana	1898		3862t, 101.0x13.0x5.7m, 18b,2vte, 8500hp, 21.6kts, 401p; NS- 63slopes, 38deck, 102CT; 6x1-152/44, 10x1-47/40, 2-381TT, 20mines
CLL	Pamyat Merkuriya	1	1	Pamyat Merkuriya	1880		2997t, 90.0x12.4x6.0m, 6b,1hc, 3000hp, 14kts, 343p; 6x1-152/25, 2x1-63/17, 4x1-47/40, 2x1-37/20, 2x5-37/17, 2-381TT, 180mines
SL	Kreyser	8	1	Kreyser	1876		1334-1449t, 70.5x10.0-10.1x5.1m, 4b,1hc, 1383-1786hp, 10-13.5kts, 188-199p; 2x1-152/25(1,2), 1x1-152/25(4,6), 3x1-152/25(5,7,8), 2x1-152/23(3,4,6), 4x1-107/17(1-3), 4x1-87/21(4,6-8), 2x1-87/21(5), 1x1-63/17(1-3,6-8), 2x1-44/41(1,2), 4x1-44/41(3), 4x5-37/17(1,2), 6x5-37/17(3,6-8), 7x5-37/17(4), 1x5-37/21(5), 1-381TT(1,3,5-8), 2-381TT(4)
			2	Dzhigit	1877
			3	Razboynik	1879
			4	Naezdnik	1879
			5	Plastun	1879
			6	Strelok	1880
			7	Vestnik	1881
			8	Oprichnik	1881
	Zabiyaka	1	9	Zabiyaka	1879		1236t, 67.0ppx9.1x4.0m, 2b,1vc, 1426hp, 14.2kts, 155p; 2x1-152/25, 4x1-107/17, 1x1-63/17, 4x1-47/40, 6x5-37/17
AMC	-	2	1	Aziya	1874		2449t, 82.0x10.7xm, 1100hp, 15.6kts; 2x1-152/23, 7x1-107/17
			2	Afrika	1878		2590t, 90.2x10.9xm, 1417hp, 12.8kts; 5x1-152/23, 4x1-107/17, 2x1-87/21

TORPEDO SHIPS

PGT	Leytenant Ilyin	1	1	Leytenant Ilyin	1887		714t, 72.3x7.4x3.2m, 6b,2vte, 3500hp, 20.8kts, 128p; steel- 19deck; 7x1-47/40, 6x5-47/22, 6x5-37/17, (5+2x1)-381TT
	Kapitan Saken	1	2	Kapitan Saken	1889		742t, 71.6x7.4x3.1m, 6b,2vte, 3000hp, 18.3kts, 102p; steel- 13deck; 6x1-47/40, 4x5-37/17, (1+2x1)-381TT
	Kazarskiy	6	3	Kazarskiy	1890		432t, 60.2x7.4x3.5m, 2b,1vte, 3500hp, 21-22.5kts, 65p; 6x1-47/40, 3x1-37/20, (1+1x1)-381TT
			4	Voevoda	1892
			5	Posadnik	1892
			6	Vsadnik	1894
			7	Gaydamak	1894
			8	Griden	1895
	Abrek	1	9	Abrek	1897		675t, 65.5x7.8x3.4m, 4b,2vte, 4500hp, 21.2kts, 88p; 2x1-75/48, 4x1-47/40, (1+1x1)-450TT
DD	Sokol	1	1	Sokol	1895		240t, 57.9x5.6x2.3m, 8b,2vte, 3800hp, 29kts, 54p; 1x1-75/48, 3x1-47/40, 2x1-381TT
TB	Vzryv	1	1	Vzryv	1877		160t, 39.6x4.9x3.4m, 2b,1vc, 800hp, 13.5kts, 33p; 4x5-37/17, 2-381TT
	Batum	1	2	No251	1880		48t, 30.6x3.7x1.9m, 1b,1vc, 500hp, 15.2kts, 21p; 2x5-37/17, 2-381TT
	Sukhum	1	3	No257	1883		64t, 34.4x3.8x2.0m, 1b,1vc, 704hp, 17.9kts, 16p; 2x5-37/17, 2-381TT
	Poti	1	4	No258	1883		63t, 38.0x3.1x2.0m, 1b,1vc, 575hp, 18.5kts, 18p; 2x5-37/17, 2-381TT
	Gagry	1	5	No254	1884		80t, 36.8x4.1x2.0m, 1b,1vc, 600hp, 17.8kts, 18p; 1x1-37/20, 1x5-37/17, 2-381TT
	Gelendzhik	1	6	No255	1884		75t, 37.4x3.8x2.1m, 1b,1vc, 520hp, 18kts, 16p; 1x1-37/20, 1x5-37/17, 2-381TT
	No1	1	7	No101	1885		68t, 38.8x3.9x1.4m, 1b,2vc, 472hp, 16.5kts, 21p; 2x5-37/17, 2-381TT
	No17	3	8-10	No106, 107, 267	1886-1888		74(8,9)-77(10)t, 38.9x3.5x2.3m, 1b,1vc, 296(8,9)-520(10)hp, 15.8(8,9)-17.5(10)kts, 21p; 4x5-37/17(8,9), 2x5-37/17(10), 2-381TT
	Sveaborg	2	11	No205	1886		96(11)-108(12)t, 46.8x3.4(11)-3.7(12)x2.6(11)-2.5(12)m, 1b,1vte, 737(11)-837(12)hp, 19.2(11)-19.7(12)kts, 21p; 2x5-37/17, 2-381TT
			12	No206	1886
	Vyborg	1	13	No102	1886		150t, 45.1x5.2x2.1m, 2b,2vc, 1300hp, 20kts, 24p; 2x5-37/17, 2-381TT
	Abo	3	14-16	No108-110	1886		76t, 38.5x4.5x1.9m, 1b,1vc, 640hp, 19.3-20kts, 21p; 4x5-37/17, 2-381TT
	Yalta	6	17-22	No261-266	1886		85-90t, 38.6x4.6x2.0m, 1b,1vte, 900hp, 20-20.8kts, 18p; 2x5-37/17, 2-381TT
	Yanchikhe	2	23, 24	No201, 202	1889		76t, 39.0x4.5x1.9m, 1b,1vc, 970hp, 16.8-17.2kts, 21p; 2x5-37/17, 2-381TT
	Adler	1	25	No259	1890		164t, 46.9x5.1x2.0m, 2b,2vte, 2000hp, 26.7kts, 25p; 2x5-37/17, (1+2x1)-381TT
	Anakriya	1	26	No260	1890		100t, 38.6x4.8x2.1m, 2b,1vte, 1100hp, 21kts, 21p; 2x5-37/17, (1+1x1)-381TT
	Nargen	2	27	No203	1891		153t, 47.3x5.0x2.6m, 2b,2vte, 2039(27)-1956(28)hp, 19.5(27)-20.3(28)kts, 21p; 3x5-37/17, (1+2x1)-381TT
			28	No204	1891
	Biorke	4	29-32	No111-114	1891-1892		81t, 38.4x4.5x2.6m, 1b,1vte, 1000-1100hp, 17.8-19kts, 21p; 2x5-37/17, 2x1-381TT
	Borgo	2	33	No207	1891		118t, 41.7x4.5x2.6m, 1b,1vte, 1245hp, 20kts, 21p; 2x5-37/17, (1+1x1)-381TT
			34	No117	1891
	Anapa	2	35, 36	No252, 253	1891-1892		96t, 38.4x4.5x2.6m, 1b,1vte, 1000-1100hp, 17.2-19kts, 18p; 2x5-37/17, 2x1-381TT
	Dago	4	37	No118	1892		101-105t, 46.5-46.8x3.9x2.3-2.6m, 1b,1vte, 1000-1030hp, 16.2-19kts, 21p; 2x5-47/22(37), 2x5-37/17(38-40), (1+1x1)-381TT
			38	No256	1892
			39	No123	1892
			40	No124	1892
	Pernov	1	41	No103	1892		120t, 42.0x4.5x2.1m, 2b,2vte, 2000hp, 26kts, 21p; 2x5-37/17, (1+2x1)-381TT
	Tosna	2	42, 43	No115, 116	1893		85-87t, 38.7x4.6x2.0m, 1b,1vte, 1000hp, 20kts, 21p; 2x5-47/22, (1+1x1)-381TT
	Aspe	4	44	No121	1895		105t, 38.8x4.8x2.1m, 2b,1vte, 1300hp, 20kts, 21p; 2x5-37/17, (1+1x1)-381TT
			45	No122	1895
			46	No125	1894
			47	No126	1894
	Sestroretsk	1	48	No104	1894		80t, 36.8x4.2x2.6m, 1b,1vte, 1300hp, 23kts, 21p; 2x5-37/17, (1+1x1)-381TT
	No119	19	49	No119	1895		120t, 42.0x4.5x2.1m, 2b,2vte, 2000hp, 19.5-23.2kts, 21p; 2x5-37/17, (1+2x1)-381TT
			50	No120	1895
			51	No127	1898
			52	No128	1898
			53	No129	1899
			54	No133	1897
			55	No134	1897
			56	No135	1897
			57	No136	1897
			58	No137	1897
			59	No138	1897
			60	No139	1897
			61	No140	1897
			62	No141	1897
			63	No142	1897
			64	No270	1897
			65	No271	1897
			66	No272	1899
			67	No273	1899
	No131	3	68	No131	1897		100t, 38.7x5.2x2.0m, 2b,2vte, 1000hp, 21kts, 18p; 2x5-37/17, (1+1x1)-381TT
			69	No132	1896
			70	No268	1895
	No208	3	71	No208	1899		130t, 42.0x4.5x2.1m, 2b,2vte, 1460hp, 18.5kts, 21p; 2x5-37/17, (1+2x1)-381TT
			72	No209	1899
			73	No210	1899
TB2cl	No2	1	1	No88	1874		25t, 22.9x3.1x1.5m, 1b,1hda, 112hp, 14kts; 1x1-381TT
	No5	1	2	No89	1877		11t, 19.8x2.6x0.6m, 1b,1vte, 120hp, 16kts, 9p; 1x1-381TT
	Vorona	1	3	No151	1877		23t, 22.9x2.6x1.1m, 1b,1vc, 220hp, 12kts, 11p; 1x1-381TT
	Oryol	70	4-73	No1-12, 15, 17-22, 25-40, 42-73, 95, 97, 143	1877-1878		23t, 21.7x2.7x1.7m, 1b,1vc, 220hp, 16kts, 7p; 1x1-381TT
	Kefal	1	74	No90	1877		13t, 17.4x2.3x0.9m, 1b,1hda, 90hp, 12kts, 9p; 1x1-381TT
	Chizhik	4	75-78	No82, 91-93	1877-1878		23t, 21.7x3.0x1.1m, 1b,1vc, 220hp, 16kts, 9p; 1x1-381TT
	Galka	1	79	No13	1878		34t, 22.1x3.1x1.6m, 1b,1vc, 220hp, 13kts, 9p; 1x1-381TT
	Kasatka	1	80	No14	1878		28t, 21.8x3.0x1.9m, 1b,1vc, 312hp, 13kts, 9p; 1x1-381TT
	Podorozhnik	1	81	No94	1878		20t, 21.5x2.8x0.8m, 1b,1vc, 200hp, 14kts, 9p; 1x1-381TT
	Selezen	1	82	No41	1878		33t, 22.7x3.4x1.8m, 1b,1vc, 200hp, 13kts, 9p; 1x1-381TT
	Mech	4	83-86	No75, 76, 78, 81	1878		20t, 20.1x3.4x1.3m, 1b,1vte, 260hp, 15kts, 9p; 1x1-381TT
	Samopal	2	87, 88	No23, 24	1878		30t, 25.6x3.3x1.9m, 1b,1vc, 250hp, 15kts, 8p; 1x1-381TT
	Shchuka	3	89-90	No83-85	1878		24t, 22.9x3.1x1.4m, 1b,1hda, 220hp, 16kts, 9p; 1x1-381TT
	Skumbriya	2	91, 92	No86, 87	1878		31t, 20.0x3.2x1.1m, 1b,1hda, 220hp, 13.5kts, 9p; 1x1-381TT
	Sirena	1	93	No16	1879		29t, 25.3x3.4x0.9m, 1b,1vc, 220hp, 14.5kts, 9p; 1x1-381TT
	Skorpion	1	94	No96	1879		31t, 19.2x3.1x1.2m, 1b,1hda, 220hp, 14kts, 9p; 1x1-381TT
	No46	1	95	No74	1889		15t, 18.2x2.6x1.3m, 1b.1vc, 200hp, 16.5kts; 1x4-25/41, 1x1-381TT

OTHER FIGHTING SHIPS

PG	Opyt	1	1	Mina	1862	No picture	270t, 37.7x6.8x1.8m, 1b,2hp, 195hp, 9kts, 28p; iron- 114breastwork; 2x1-87/17
	Pishchal	1	2	Pishchal	1872	No picture	346t, 40.8x7.7x2.2m, 1b,1hda, 172hp, 8kts, 48p; 6x1-87/17
	Yorsh	1	3	Yorsh	1875		321t, 30.1x8.7x2.2m, 2b,2hc, 240hp, 8kts, 44p; 1x1-279/17, 2x1-44/41
	Burun	4	4	Burun	1880		424(4-6)-383(7)t, 36.4x8.8x2.4m, 2b,2hc, 240-283hp, 7.5kts, 54p; 1x1-279/18(6), 3x1-107/17(5), 6x1-107/17(7), 4x1-87/21(4), 5x1-87/21(5), 2x1-75/48(7), 3x1-37/20(4), 2x1-37/20(6,7)
			5	Tucha	1880
			6	Burya	1881
			7	Groza	1881
	Dozhd	4	8	Dozhd	1880		402(8,10,11)-390(9)t, 33.5x10.5(8,10,11)-11.6(9)x2.2m, 2b,2hc, 300(8,10,11)-445(9)hp, 9-9.3kts, 54p; 1x1-279/17(9,11), 1x1-279/18(10), 6x1-37/20(8), 2x1-37/20(9-11)
			9	Vikhr	1880
			10	Grad	1881
			11	Sneg	1881
	Sivuch	2	12	Sivuch	1884		1134(12)-1187(13)t, 60.3x10.7x3.5(12)-3.7(13)m, 6b,2hc, 1100hp, 11kts, 188p; steel- 13deck; 1x1-229/27, 1x1-152/25, 6x1-107/17, 1x1-63/17, 4x5-37/17
			13	Bobr	1886
	Koreets	2	14	Koreets	1887		1334(14)-1418(15)t, 66.3(14)-66.6(15)x10.7x3.5(14)-3.8(15)m, 6b,2hc, 1500hp, 13kts, 179p; 2x1-203/33, 1x1-152/32, 4x1-107/17, 1x1-63/17, 2x1-47/40, 4x5-37/17, 1-381TT
			15	Mandzhur	1887
	Kubanets	6	16	Kubanets	1887		1505t, 67.2(16-18)-64.5(19-21)x12.2x3.8m, 6b,2hc(16-18)-6b,2hte(19-21), 1500hp, 11-14kts, 180p; 2x1-203/33, 1x1-152/32, 6x5-47/22, 2-381TT
			17	Terets	1887
			18	Uralets	1888
			19	Zaporozhets	1888
			20	Chernomorets	1889
			21	Donets	1889
	Grozyashchiy	3	22	Grozyashchiy	1892		1627(22)-1700(23)-1854(23)t, 72.3x12.7x4.0(22,23)-4.4(24)m, 6b,2vte, 2050(22,23)-2500(24)hp, 14-14.5kts, 178-188p; steel- 127belt, 38deck, 25CT; 1x1-229/32, 1x1-152/32, 6x1-47/40, 4x5-37/17, 2-381TT, 20mines
			23	Gremyashchiy	1893
			24	Otvazhny	1893
	Khrabry	1	25	Khrabry	1897		2100t, 72.3x12.7x3.8m, 8b, 2vte, 2100hp, 14kts, 188p; 2x1-203/43, 1x1-152/44, 5x1-47/40, 4x1-37/20, 1-450TT, 20mines
	Gilyak	1	26	Gilyak	1899		1251t, 63.1x11.1x3.3m, 6b,2vte, 1000hp, 12kts, 170p; steel- 13deck; 1x1-120/43, 5x1-75/48, 2x1-63/17, 4x1-47/40, 2x1-37/20, 1-450TT

MINE WARFARE SHIPS

ML	Aleut	1	1	Aleut	1886		892t, 49.4x9.4x3.5m, 2b,1vc, 730hp, 11.9kts, 100p; 4x5-37/17, 250mines
	Bug	2	2	Bug	1892		1490t, 62.2x10.4x4.6m, 4b,2vte, 1400hp, 13kts, 226p; 4x1-47/40, 545mines
			3	Dunay	1893

BOARD GUARD SHIPS
