World navies yesterday

1900



Netherlands 01 January 1900

BATTLESHIPS

BC Schorpionen 2 1 Schorpionen 1868 2140(1)-2078(2)t, 62.5x11.9x4.8(1)-5.1(2)m, 4b,2hrcr, 2225(1)-2260(2)hp, 13(1)-12.5(2)kts, 136p; iron- 152side, 25deck, 278turret, 144CT; 1x1-283/20, 5x1-37/20, 2x5-37/17
2 Stier 1868
Evertsen 3 3 Evertsen 1896 3464t, 86.2x14.3x5.2m, 6b,2vte, 4700hp, 16kts, 263p; steel- 150belt, 55deck, 240barbette, 240CT; (1x2+1x1)-209/32, 2x1-149/32, 6x1-75/27, 8x1-37/20, 3-450TT
4 Piet Hein 1896
5 Kortenaer 1895
MON Heiligerlee 2 1 Heiligerlee 1868 1520t, 57.0x13.5x3.1m, 4b,2hrcr, 630hp, 9kts, 117p; iron- 140side, 25deck, 285turret, 140CT; 1x1-283/20, 2x1-37/20, 2x5-37/17
2 Krokodil 1868
Bloedhond 2 3 Bloedhond 1870 1656(3)-1559(4)t, 55.7(3)-56.5(4)x14.2(3)-13.4(4)x3.2(3)-3.0(4)m, 4b,2hrcr, 680(3)-534(4)hp, 7.7(3)-7(4)kts, 117p; iron- 140side, 25deck, 285turret, 140CT; 1x1-283/20, 2x1-37/20, 2x5-37/17
4 Cerberus 1870
Adder 5 5 Haai 1872 1555(5,6,8,9)-1585(7)t, 58.6-59.6x13.4x3.0m, 4b,2hc, 560-740hp, 7-8kts, 117p; iron- 140side, 25deck, 285turrets, 140CT; 1x1-283/20, 2x1-37/20, 2x5-37/17
6 Hyena 1871
7 Luipaard 1878
8 Panter 1871
9 Wesp 1872
Draak 1 10 Draak 1878 2198t, 65.1x15.0x3.6m, 4b,2hc, 807hp, 8.4kts, 131p; iron- 205side, 23deck, 305turret, 140CT; 1x2-283/20, 2x1-37/20, 2x5-37/17
Matador 1 11 Matador 1879 1968t, 63.9x14.5x3.2m, 4b,2hc, 690hp, 7.5kts, 131p; iron- 140side, 25deck, 305turret, 140CT; 1x2-283/20, 2x1-37/20, 2x5-37/17
Reinier Claeszen 1 12 Reinier Claeszen 1894 2440t, 70.0x13.5x4.6m, 3b,2vc, 2315hp, 12.5kts, 161p; compound- 120belt, 75deck, 280turret, 280CT; 1x1-209/32, 1x1-173/32, 4x1-50/37, 2-356TT

CRUISERS

CL Sumatra 1 1 Sumatra 1891 1693t, 70.0x11.3x4.7m, 4b,2vte, 2350hp, 17kts, 181p; steel- 38deck, 100shields, 150CT; 1x1-209/32, 1x1-149/32, 2x1-120/32, 4x1-37/20, 2x5-37/17, 2-356TT
Koningin Wilhelmina der Nederlanden 1 2 Koningin Wilhelmina der Nederlanden 1894 4530t, 99.8x14.9x6.1m, 6b,2vte, 4600hp, 15.8kts, 296p; compound- 75slopes, 50deck, 280turret; 1x1-283/27, 1x1-209/32, 2x1-173/32, 4x1-75/37, 6x1-37/20, 4x5-37/17, 4-356TT
Holland 3 3 Holland 1898 3840t, 93.3x14.8x5.4m, 8b,2vte, 10000hp, 20kts, 371p; Harvey- 57deck, 152shields, 102CT; 2x1-149/37, 6x1-120/37, 6x1-75/37, 8x1-37/20, 4x5-37/17, 2-450TT
4 Zeeland 1898
5 Friesland 1898
CLL Alkmaar 1 1 Alkmaar 1874 No picture 1051t, 54.5x9.2x4.8m, 686hp, 10.3kts, 106p; 1x1-149/22, 6x1-120/16, 2x1-37/20, 2x5-37/17
Atjeh 3 2 Atjeh 1877 3425-3669t, 91.8-92.1x12.5x6.4-7.0m, 2700-3300hp, 13.5-14.8kts, 277-306p; 6x1-173/22, 8x1-120/16, 8x1-37/20, 6x5-37/17
3 Tromp 1878
4 Koningin Emma der Nederlanden 1880
Sommelsdijk 1 5 Sommelsdijk 1882 No picture 997t, 54.5x9.5x3.6m, 759hp, 11.4kts, 96p; 1x1-149/22, 3x1-120/16, 2x1-37/20, 2x5-37/17
Java 1 6 Java 1885 No picture 1280t, 62.6x9.5x3.7m, 1017hp, 12.6kts, 104p; 1x1-149/22, 3x1-120/16, 2x1-37/20

TORPEDO SHIPS

TB1cl Ardjoeno 10 1-10 Ardjoeno, Dempo, Habang, Krakatau, Cycloop, Batok, Foka, Idjen, Empong, Goentoer 1887-1892 79-90t, 38.4-39.2x4.0x1.8-2.1m, 1b,1vc, 725-1089hp, 19.1-22.8kts, 16p; 2x1-37/20, 2-450TT
No.XXIII 1 11 Cerberus 1888 82t, 38.2x4.0x1.8m, 1b,1vc, 912hp, 21.2kts, 16p; 2x1-37/20, (1+2x1)-450TT
Lamongan 3 12-14 Lamongan, Nobo, Makjan 1891 No picture 59t, 32.9x4.0x1.6m, 1b,1vc, 780hp, 20.4kts, 15p; 2x1-37/20, 2-450TT
TB2cl No.I 1 1 No.I 1876 29t, 23.2x3.2x1.6m, 1b,1hda, 250hp, 18kts, 11p; 2spar torpedoes
No.III 1 2 No.III 1876 29t, 23.2x3.2x1.6m, 1b,1hda, 250hp, 18kts, 11p; 2spar torpedoes
No.II 1 3 No.II 1877 29t, 23.2x3.2x1.6m, 1b,1hda, 250hp, 18kts, 11p; 2spar torpedoes
No.IV 1 4 No.IV 1879 29t, 23.2x3.2x1.6m, 1b,1hda, 250hp, 18kts, 11p; 2spar torpedoes
No.V 5 5-9 No.V-IX 1879 29t, 24.6x3.2x1.6m, 1b,1hda, 250hp, 18kts, 11p; 2spar torpedoes
No.X 3 10-12 No.X, XI, XII Argus 1879 29t, 24.6x3.2x1.6m, 1b,1hda, 250hp, 18kts, 11p; 2spar torpedoes
No.XIII 6 13-18 No.XIII-XVIII 1879-1881 30t, 24.6x3.2x1.6m, 1b,1hda, 250hp, 17-18kts, 11p; 1x1-37/20(15,16), 2-356TT(15,16), 2spar torpedoes(13,14,17,18)
No.XIX 2 19, 20 No.XIX, XX 1881 30t, 24.6x3.2x1.6m, 1b,1hda, 250hp, 18kts, 11p; 2spar torpedoes
No.XXI 2 21, 22 Hekla, Etna 1882 45t, 31.0x3.8x1.7m, 1b,1hc, 550hp, 21.4kts, 15p; 2x1-37/20, 2-356TT
No.III 3 23-24 No.III Jan Haring, No.XXI Jasper Leynssen, No.XXII Jacob Hobein 1891 37t, 25.6x3.2x1.6m, 1b,1vc, 440hp, 17.5kts; 2x1-37/20, 2-356TT

ESCORTS

AFPV - 2 1 Dolfijn 1889
2 Zeehond 1892

OTHER FIGHTING SHIPS

PG Aruba 1 1 Aruba 1873 No picture 786t, 50.0x9.0x3.8m, 413hp, 9.5kts; 1x1-149/22, 2x1-120/16, 1x1-75/5, 2x1-37/20
Batavia 4 2 Makasser 1877 No picture 853t, 53.6x9.0x3.7m, 400-500hp, 8.4-9.3kts, 84-104p; 1x1-173/22(2), 1x1-149/22(3-5), 2x1-120/16(2), 3x1-120/16(3-5), 2x1-37/20(3-5)
3 Madura 1880
4 Bonaire 1877
5 Bali 1878
Suriname 1 6 Suriname 1877 No picture 884t, 54.0x9.0x3.6m, 450hp, 9.5kts, 90p; 1x1-149/22, 3x1-120/16, 2x1-37/20
Ceram 2 7 Ceram 1887 No picture 541t, 52.8x7.8x3.1m, 800hp, 12.8kts, 83p; 3x1-120/16, 2x1-37/20
8 Flores 1887
Lombok 2 9 Lombok 1891 No picture 600t, 52.4x8.3x3.4m, 960hp, 12.3kts, 87p; 3x1-120/16, 2x1-37/20
10 Sumbawa 1891
Borneo 1 11 Borneo 1892 No picture 800t, 53.8x9.5x4.1m, 1040hp, 13.2kts, 102p; 6x1-105/32, 2x1-37/20, 2x5-37/17
Nias 4 12 Nias 1895 810-820t, 53.9x9.4x3.7m, 2vte, 1300hp, 12.9kts, 97p; 2x1-105/32, 4x1-37/20, 2x5-37/17
13 Mataram 1896
14 Edi 1897
15 Serdang 1897
Koetei 2 16 Koetei 1898 788t, 53.7x9.4x3.7m, 2vte, 1380hp, 13.7kts, 97p; 2x1-105/32, 4x1-37/20, 2x5-37/17
17 Siboga 1898
Hydra 9 18 Hydra 1873 221t, 25.9x8.0x2.2m, 2b,1vc, 124-146hp, 7.5-8kts, 34p; 1x1-209/32, 2x1-37/20, 1x5-37/20
19 Ever 1873
20 Das 1876
21 Geep 1875
22 Gier 1875
23 Havik 1874
24 Brak 1875
25 Lynx 1875
26 Sperwer 1875
Wodan 16 27 Wodan 1877 264-280t, 27.8x8.2x2.3m, 2b,1vc, 101-171hp, 7-8.3kts, 34p; 1x1-283/27(35,38-41), 1x1-283/20(27-34,36,37,42), 2x1-37/20, 1x5-37/17
28 Balder 1879
29 Braga 1879
30 Freyr 1877
31 Heimdall 1879
32 Njord 1878
33 Thor 1877
34 Tyr 1878
35 Hefring 1880
36 Vali 1879
37 Vidar 1879
38 Bulgia 1884
39 Dufa 1879
40 Hadda 1880
41 Udur 1879
42 Ulfr 1879
PR Vahalis 1 1 Vahalis 1870 No picture 365t, 38.4x8.5x1.6m, 240hp, 7.5kts, 34p; iron- 100side, 13deck, 25turrets; 2x1-47/40
Isala 4 2 Isala 1876 No picture 373-388t, 48.6x7.6x1.4m, 306-400hp, 7.7-8kts, 44p; iron- 125side, 25deck, 125turrets; 2x1-120/16
3 Rhenus 1877
4 Mosa 1878
5 Merva 1879
