World navies yesterday

2017



Japan 01 January 2017

SUBMARINES

SS Harushio 1 TSS3601 Asashio 1997 2900/3700t, 87.0x10.5x7.7m, 2dg,2em/2se(1), 3400/7220/240hp, 75p, 350m; 6-533TT(inc Sub-Harpoon SSM(4)); ZPS-6 radar, ZQQ-5B sonar, ZLA-7 ECM, ZYQ-2B CCS
Oyashio 11 TSS3608 Oyashio 1998 2750/3500t, 81.7x10.3x7.9m, 2dg,2em(1), 5520/7750hp, 12/20kts, 61p, 400m; 6-533TT(inc Sub-Harpoon SSM(4)); ZPS-6D radar, ZQQ-6B, ZQR-1(591-600) sonars, ZLA-7 ECM, ZYQ-3 CCS
SS591 Michishio 1999
SS592 Uzushio 2000
SS593 Makishio 2001
SS594 Isoshio 2002
SS595 Narushio 2003
SS596 Kuroshio 2004
SS597 Takashio 2005
SS598 Yaeshio 2006
SS599 Setoshio 2007
SS600 Mochishio 2008
Soryu 7 SS501 Soryu 2009 2950/4200t, 83.7x9.1x8.5m, 2dg,1em/4Ste, 3900/8000/470hp, 13/20kts, 65p; 400m; 6-533TT(inc Sub-Harpoon SSM(4)); ZPS-6F radar, ZQQ-7, ZQR-1 sonars, NZLR-1B ECM, ZYQ-31 CCS
SS502 Unryu 2010
SS503 Hakuryu 2011
SS504 Kenryu 2012
SS505 Zuiryu 2013
SS506 Kokuryu 2015
SS507 Jinryu 2016

AIRCRAFT CARRIERS

CV Hyuga 2 DDH181 Hyuga 2009 19000t, 197.0x33.0x7.0m, 4gt(2), 100000hp, 30kts, 347p; 1x16 x4 ESSM SAM/ASROC VLA ASuR (16+12), 2x6-20/76, 4x1-12.7, 2x3-324TT, 11 helicopters (3 SH-60, 1 MCH-101); OPS-28D, OPS-20C, FCS-3 radars, OQS-21 sonar NOLQ-3C ECM, 6x SRBOC Mk 36 dl, ACDS CCS
DDH182 Ise 2011
Izumo 1 DDH183 Izumo 2015 24000t, 248.0x38.0x7.3m, COGAG:4gt(2), 112000hp, 30kts, 470p; 2x21 Sea RAM SAM(42), 2x6-20/76, 5x1-12.7, 14 helicopters (7 SH-60, 1 MCH-101); OPS-50, OPS-28D, FCS-3, OPS-20 radars, OQQ-23 sonar, NOLQ-3D-1 ECM, 6x SRBOC Mk 36 dl, OLQ-1 td, ACDS CCS

PRINCIPAL SURFACE COMBATANTS

DD Shirane 1 DDH144 Kurama 1981 6800t, 158.8x17.5x5.3m, 2b,2gst, 70000hp, 32kts, 360p; 1x8 Sea Sparrow SAM(24), 1x8 ASROC ASuR(16), 2x1-127/54, 2x6-20/76, 2x3-324TT, 3 helicopters (SH-60); OPS-20, OPS-12, OPS-28, FCS-2-12, 2x FCS-1A, 2x Mk90 radars, OQS-101, SQS-35(J), SQR-18A sonars, NOLQ-1, OLR-9B ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, OYQ-3B CCS
Hatsuyuki 5 TV3519 Yamayuki 1985 3800t, 131.7x13.7x4.3m, COGOG:2gt/2gt(2), 50000/10000hp, 30kts, 170p; 2x4 Harpoon SSM(8), 1x8 Sea Sparrow SAM(16), 1x1-76/62, 2x6-20/76, 2x3-324TT, 1 helicopter (SH-60); OPS-18-1, OPS-14B, OPS-20, FCS-2-21A, FCS-2-12A(3519,130), FCS-2-12C(132,3513,3518), 2x Mk 90 radars, OQS-4A, OQR-1 sonar, NOLQ-6C, OLT-3 ECM, 2x Mk 36 SRBOC dl, type 3 td, OYQ-6 CCS
DD130 Matsuyuki 1986
TV3518 Setoyuki 1986
DD132 Asayuki 1987
TV3513 Shimayuki 1987
Hatakaze 2 DDG171 Hatakaze 1986 5600t, 150.0x16.4x4.8m, COGAG:2gt+2gt(2), 72000hp, 30kts, 260p; 2x4 Harpoon SSM(8), 1x1 Standard SM-1MR SAM(40), 1x8 ASROC ASuR(8), 2x1-127/54, 2x6-20/76, 2x1-12.7, 2x3-324TT, heldeck; OPS-28B, OPS-11C, SPS-52C, 2x SPG-51C, 2x FCS-2-21C, 2x Mk 90 radars, OQS-4-1 sonar, NOLQ-1-3, OLR-9B ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, OYQ-4-1 CCS
DDG172 Shimakaze 1988
Asagiri 8 DD151 Asagiri 1988 4900t, 136.5x14.6x4.5m, COGAG:4gt(2), 54000hp, 30kts, 220p; 2x4 Harpoon SSM(8), 1x8 Sea Sparrow SAM(18), 1x8 ASROC ASuR(16), 1x1-76/62, 2x6-20/76, 2x3-324TT, 1helicopter (SH-60); OPS-14C(151-154), OPS-24B(155-158), OPS-28C, OPS-20, FCS-2-12E(151-154), FCS-2-23(155-158), FCS-2-22A, 2x Mk 90 radars, OQS-4A, OQR-1 sonars, NOLR-6C(153-158), NOLR-8(151,152) ECM, 2x Mk 36 SRBOC dl, SLQ-25 td, OYQ-7 CCS
DD152 Yamagiri 1989
DD153 Yugiri 1989
DD154 Amagiri 1989
DD155 Hamagiri 1990
DD156 Setogiri 1990
DD157 Sawagiri 1990
DD158 Umigiri 1991
Kongo 4 DDG173 Kongo 1993 9500t, 161.0x21.0x6.2m, COGAG:4gt(2), 100000hp, 30kts, 310p; 2x4 Harpoon SSM(8), (1x61+1x29) Standard SM-2MR SAM / Standard SM-3 SAM / ASROC VLA ASuR(VLS,74+16), 1x1-127/54, 2x6-20/76, 2x1-12.7, 2x3-324TT, heldeck; SPY-1D, OPS-28D, 3x SPG-62, FCS-2-23, OPS-20, 2x Mk 90 radars, OQS-102, OQR-2 sonars, NOLQ-2, OLT-3, OPN-7B ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, OYQ-6 CCS
DDG174 Kirishima 1995
DDG175 Myoko 1996
DDG176 Chokai 1998
Murasame 9 DD101 Murasame 1996 6200t, 151.0x17.4x5.2m, COGAG:2gt+2gt(2), 60000hp, 30kts, 165p; 2x4 SSM-1B SSM(8), 1x16 ESSM SAM(VLS,16), 1x16 ASROC VLA ASuR(VLS,16), 1x1-76/62, 2x6-20/76, 2x3-324TT, 1 helicopter (SH-60); OPS-20, OPS-28D, OPS-24B, 2x FCS-2-31, 2x Mk 90 radars, OQS-5, OQR-1 sonars, NOLQ-2, NOLR-8 ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, OYQ-9 CCS
DD102 Harusame 1997
DD103 Yudachi 1999
DD104 Kirisame 1999
DD105 Inazuma 2000
DD106 Samidare 2000
DD107 Ikazuchi 2001
DD108 Akebono 2002
DD109 Ariake 2002
Takanami 5 DD110 Takanami 2003 6300t, 151.0x17.4x5.3m, COGAG:2gt+2gt(2), 60000hp, 30kts, 176p; 2x4 SSM-1B SSM(8), 4x8 Sea Sparrow SAM/ x4 ESSM SAM / ASROC ASuR (VLS,32), 1x1-127/54, 2x6-20/76, 4x1-12.7, 2x3-324TT, 1 helicopter (SH-60); OPS-20, OPS-28D, OPS-24B, 2x FCS-2-31B, 2x Mk 90 radars, OQS-5, OQR-2 sonars, NOLQ-3, NOLR-8 ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, OYQ-9 CCS
DD111 Onami 2003
DD112 Makinami 2004
DD113 Sazanami 2005
DD114 Suzunami 2006
Atago 2 DDG177 Atago 2007 10000t, 164.9x21.0x6.2m, COGAG:4gt(2), 100000hp, 30kts, 307p; 2x4 SSM-1B SSM(8), (1x64+1x32) Standard SM-2MR SAM / x4 ESSM SAM / ASROC VLA ASuR (96), 1x1-127/54, 2x6-20/76, 2x3-324TT, 2 helicopters (SH-60); SPY-1D(v), OPS-28E, 3x SPG-62, FCS-2-21, OPS-20, 2x Mk 90 radars, Mk 46 e/o, OQS-102 sonar, NOLQ-2B OLT-3 ECM, 4x Mk 36 SRBOC dl, SLQ-25 td, OYQ-6 CCS
DDG178 Ashigara 2008
Akizuki 4 DD115 Akizuki 2012 6800t, 151.0x18.3x5.4m, COGAG:2gt+2gt(2), 64000hp, 30kts, 210p; 2x4 SSM-4 SSM(8), 1x32 x4 ESSM SAM / ASROC VLA ASuR (64+16), 1x1-127/54, 2x6-20/76, 2x3-324TT, 1 helicopter (SH-60); OPS-20C, FCS-3A, 2x Mk 90 radars, OQQ-22, OQR-3 sonars, NOLQ-3D, NORC-4B ECM, 2x Mk 36 SRBOC dl, FAJ, MOD td, OYQ-11 CCS
DD116 Teruzuki 2013
DD117 Suzutsuki 2014
DD118 Fuyuzuki 2014
FF Abukuma 6 DE229 Abukuma 1989 2550t, 109.0x13.4x3.8m, CODOG:2gt/2d(2), 27000/6000hp, 27kts, 120p; 2x4 Harpoon SSM(4), 1x8 ASROC ASuR(8), 1x1-76/62, 1x6-20/76, 2x3-324TT; OPS-14C, OPS-28D, FCS-2-21, Mk 90 radars, OQS-8 sonar, NOLQ-6C, OLT-3 ECM, 2x Mk 36 SRBOC dl, OYQ-6 CCS
DE230 Jintsu 1990
DE231 Oyodo 1991
DE232 Sendai 1991
DE233 Chikuma 1993
DE234 Tone 1993
FFT Kashima 1 TV3508 Kashima 1995 5400t, 143.0x18.0x4.6m, CODOG:2gt/2d(2), 27000/12000hp, 25kts, 220+140p; 1x1-76/62, 2x1-12.7, 2x3-324TT, heldeck; OPS-18, OPS-20, OPS-14C, FCS-2-22F radars, OQS-4 sonar, 2x Mk 36 SRBOC dl, OYQ-6C CCS

PATROL AND COASTAL COMBATANTS

PM Hayabusa 6 PG824 Hayabusa 2002 240t, 50.1x8.4x1.7m, 3gt(3wj), 16200hp, 44kts, 21p; 2x2 SSM-1B SSM(4), 1x1-76/62, 2x1-12.7; OPS-19-3, OPS-20, FCS-2-31 radars, OAX-2 e/o, NOLR-9B ECM, 2x Mk 36 SRBOC dl, OYQ-8 CCS
PG825 Wakataka 2002
PG826 Otaka 2003
PG827 Kumataka 2003
PG828 Umitaka 2004
PG829 Shirataka 2004

AMPHIBIOUS

LPD Osumi 3 LST4001 Osumi 1998 14000t, 178.0x25.8x6.0m, 2d, 26000hp, 22kts, 135p; 2x6-20/76, 1x1-12.7, heldeck; 2 LCAC, 2 LCVP, 14tanks, 330troops; OPS-14C, OPS-28B, OPS-20, 2x Mk 90 radars, ECM
LST4002 Shimokita 2002
LST4003 Kunisaki 2003
LSM 1-go 2 LC2001 1-go 1988 no picture 540t, 52.0x8.7x1.6m, 2d, 3000hp, 12kts, 28p; 1x3-20/76; 60troops, cargo; OPS-9B radar
  LC2002 2-go 1992
LCAC LCAC1 6 LA2101 LA01 1997 180t, 26.8x14.3x0.8/0m, 4gt(2ap), 7910+7910hp, 40kts, 6p; 180troops; LN-66 radar
LA2102 LA02 1998
LA2103 LA03 2001
LA2104 LA04 2002
LA2105 LA05 2002
LA2106 LA06 2003
LC YF2121 10 YF2121, 2124, 2125, 2127-2129, 2132, 2135, 2138, 2141   1989-1997 56t, 17.1x4.4x1.2m, 2d, 450hp, 10kts, 4p; 80troops
YF2150 2 YF2150, 2151   2003-2005 no picture 50t, 19.8x5.4x2.3m, 2d(2wj), 3000hp, 16kts, 4p; 100troops

MINE WARFARE

ML Uraga 2 MST463 Uraga 1997 6850t, 141.0x22.0x5.4m, 2d, 19500hp, 22kts, 160p; 1x1-76/62(464), 2x1-20/70, 230 mines, 1 helicopter (MH-53E); OPS-14B, OPS-39, FCS-2-21A(464) radars, ZQS-1B sonar
MST464 Bungo 1998
MSO Yaeyama 1 MSO303 Hachijo 1994 1200t, 67.0x11.8x3.1m, 2d, 2400hp, 14kts, 60p; 1x3-20/76, S-7-2 USV, S-8 USV, magnetic, acoustic minesweeping gear; OPS-39Y radar, SQQ-32, AQS-14 sonars
MSC Uwajima 4 MCL729 Maejima 1993 570t, 57.7x9.4x2.9m, 2d, 1800hp, 14kts, 45p; 1x3-20/76, S-7-1 USV, mechanical, magnetic, acoustic minesweeping gear; OPS-39Y radar, ZQS-3-1 sonar, drone control equipment(729,730)
MCL730 Kumejima 1994
MSC679 Yugeshima 1996
MSC680 Nagashima 1996
Sugashima 12 MSC681 Sugashima 1999 590t, 57.7x9.4x3.0m, 2d, 1800hp, 14kts, 45p; 1x3-20/76, 2x PAP-104 Mk 5 USV, mechanical minesweeping gear; OPS-39Y radar, ZQS-4 sonar, Nautis-IIM CCS
  MSC682 Notojima 1999
  MSC683 Tsunoshima 2000
  MSC684 Naoshima 2001
  MSC685 Toyoshima 2002
  MSC686 Ukushima 2003
  MSC687 Izushima 2003
  MSC688 Aishima 2004
  MSC689 Aoshima 2005
  MSC690 Miyajima 2005
  MSC691 Shishijima 2006
  MSC692 Kuroshima 2007
Hirashima 3 MSC601 Hirashima 2008 650t, 57.0x9.8x3.0m, 2d, 2200hp, 14kts, 45p; 1x3-20/76, S-10 USV, mechanical minesweeping gear; OPS-39Y radar, ZQS-4 sonar, Nautis-M CCS
MSC602 Yakushima 2009
MSC603 Takashima 2010
Enoshima 3 MSC604 Enoshima 2012 660t, 63.0x10.1x2.5m, 2d, 2200hp, 14kts, 45p; 1x3-20/76, S-10 USV, mechanical minesweeping gear; OPS-39Y radar, ZQS-4 sonar, Nautis-M CCS
MSC605 Chichijima 2013
MSC606 Hatsushima 2015
MSB Namie 1 6 Namie 1-6   1998-1999 no picture 20t, 18.0x6.1x0.7m, 1d, 210hp, 8kts, 0/3p; magnetic or acoustic minesweeping gear

AUXILIARY

AOR Mashu 2 AOR425 Mashu 2004 25000t, 221.0x27.0x8.3m, 2gt, 40000hp, 24kts, 145p; 2x6-20/76, 2x1-12.7, 2 helicopters(CH-101); 15000m3 dry and liquid cargo, 2x2 underway replenishment stations (liquid and dry cargo), 2x 30t cranes; 2x radars, 4x Mk 36 SRBOC dl
AOR426 Omi 2005
Towada 3 AOR422 Towada 1987 12100t, 167.0x22.0x8.1m, 2d, 26000hp, 22kts, 140p; 1x1-12.7, heldeck; 5700t fuel oil and dry cargo, 3x2 underway replenishment stations (liquid and dry cargoes); OPS-18 radar
AOR423 Tokiwa 1990
AOR424 Hamana 1990
AGS Shonan 1 AGS5106 Shonan 2010 4150t, 103.0x16.4x4.5m, 2dg,2em, 6660hp, 16kts, 80p; 2x radars
Nichinan 1 AGS5105 Nichinan 1999 4500t, 111.0x17.0x4.5m, 2dg,3em, 8600hp, 18kts, 90p; cable; 2x radars
Futami 1 AGS5104 Wakasa 1986 3200t, 96.8x15.0x4.2m, 2d, 4400hp, 16kts, 105p; RCV-225 USV, cable; OPS-18-3 radar
AGB Shirase 1 AGB5003 Shirase 2009 22000t, 146.0x28.0x9.2m, 4dg,4em(2), 30000hp, 19kts, 179+80p; 2 helicopters (CH-101); OPS-18, OPS-39 radars
AGE Kurobe 1 AGE4202 Kurobe 1989 2550t, 101.0x16.5x4.0m, 4d(2), 9100hp, 20kts, 143p; 1x1-76/62, 1 helicopter (UH-60); BQM-34J, MQM-74 target drones; OPS-18, OPS-14C, FCS-2-21, TMCATS radars
Tenryu 1 AGE4203 Tenryu 2000 2750t, 106.0x16.5x4.1m, 4d(2), 12500hp, 22kts, 140p; 1x1-76/62, 1 helicopter (UH-60); BQM-34J, MQM-74 target drones; OPS-19, OPS-14, FCS-2-22, TMCATS radars
Asuka 1 AGE6102 Asuka 1995 6200t, 151.0x17.3x5.0m, CODLAG:2gt+2dg,2em(2), 43000hp, 27kts, 70+100p; 1x8 SAM/ASuR VLA(8), 1 helicopter (SH-60J); FCS-3, OPS-19, OPS-14C radars, OQS-4 sonar
ASR Chiyoda 1 AS405 Chiyoda 1985 5400t, 112.5x17.6x4.6m, 2d, 11500hp, 17kts, 120p; heldeck; DSRV rescue submarine; OPS-16 radar, SQS-36D sonar
Chihaya 1 AS403 Chihaya 2000 6900t, 127.5x20.0x5.1m, 2d, 19500hp, 21kts, 125p; heldeck; DSRV rescue submarine; OPS-20 radar
AGOS Hibiki 2 AGOS5201 Hibiki 1991 3800t, 71.5x29.9x7.5m, 4dg,2em, 3000hp, 11kts, 40p; heldeck; OPS-18, OPS-19 radars, UQQ-2 sonar
AGOS5202 Harima 1992
AY Hashidate 1 AY91 Hashidate 1999 no picture 490t, 62.0x9.4x2.0m, 2d, 5500hp, 20kts, 29+130p; 2x radars
ACR Muroto 1 ACR483 Muroto 2013 6400t, 131.0x19.0x5.7m, 3dg,2em, 7300hp, 16kts; cable; 2x radars
YTR Hiuchi 5 YTF4301 Hiuchi 2002 1400t, 65.0x12.0x3.5m, 2d, 5000hp, 15kts, 40p; OPS-26B radar
YTF4302 Suo 2004
YTF4303 Amakusa 2004
YTF4304 Genkai 2008
YTF4305 Enshu 2008
YT YT58 29 YT63   1982 no picture 260t, 28.4x8.6x2.5m, 2d, 1800hp, 11kts, 10p; radar
YT65   1984
YT66   1985
YT67   1986
YT68   1987
YT69   1987
YT70   1988
YT71   1989
YT72   1990
YT73   1991
YT74   1991
YT78   1994
YT79   1994
YT81   1996
YT84   1998
YT86   2000
YT89   2001
YT90   2001
YT92   2006
YT94   2007
YT95   2010
YT96   2010
YT97   2011
YT99   2012
YT01   2013
YT02   2013
YT03   2015
YT04   2015
YT06   2016
YOG YG203 5 YG203   1988 no picture 270t, 37.7x6.8x2.6m, 1d, 350hp, 9kts, 5p; petrol
YG204   1989
YG205   1990
YG206   2007
YG207   2015
YO YO29 15 YO29   1991 no picture 750t, 46.4x7.8x2.2m, 2d, 460hp, 10kts, 10p; 340t oil; radar
YO30   1992
YO31   1992
YO33   1993
YO34   1995
YO35   1995
YO36   1997
YO37   1998
YO38   1998
YO39
YO40
YO41
YO42
YO43
YO44
YO28 2 YO28   1990 no picture 270t, 27.7x6.8x2.6m, 2d, 360hp, 9kts
YO32   1992
YO21 3 YO25   1988 no picture 694t, 45.5x7.8x2.9m, 2d, 460hp, 10kts, 10p; 520t oil; radar
YO26   1988
YO27   1989
YW YW17 8 YW17   1988 no picture 450t, 37.7x6.8x2.8m, 2d, 360hp, 9kts; 310t water; radar
YW18   1989
YW19   1992
YW20   1994
YW21   1997
YW22   1998
YW23   2000
YW24   2000
YXT Tokiwa 1 YTE12 Tokiwa 1983 no picture 180t, 35.0x7.5x1.5m, 2d, 1100hp, 14kts, 18p
YTE13 1 YTE13   2002 no picture 179t, 35.3x7.4x1.7m, 2d, 2200hp, 16kts
YDT YDT01 6 YDT01   2000 no picture 300t, 46.0x8.6x2.2m, 2d, 1500hp, 15kts, 15+15p
YDT02   2000
YDT03   2001
YDT04   2001
YDT05   2002
YDT06   2003
YF YL09 7 YL11   1988 no picture 121t, 27.0x7.0x1.0m, 2d, 560hp, 9kts, 5p; 50t cargo
YL12   1993
YL13   1994
YL14   1995
YL15   1998
YL16   2015
YL17   2015

MARITIME SAFETY AGENCY

WPSO Soya 1 PLH01 Soya 1978 4089t, 98.6x15.6x5.2m, 2d, 15600hp, 21kts, 71p; 1x1-40/60, 1x1-20/70, 1helicopter (Bell 212); 2x JMA1596, JMA1576 radars
Tsugaru 6 PLH02 Tsugaru 1979 4037t, 105.4x14.6x4.9m, 2d, 15600hp, 22kts, 71p; 1x1-40/60(02,03), 1x1-35/90(04-07), 1x1-20/70(02,05-07), 1 helicopter (Bell 212); JMA1596, JMA1576, hel.control radars
PLH03 Osumi 1979
PLH04 Uruma 1980
PLH05 Zao 1983
PLH06 Okinawa 1983
PLH07 Settsu 1984
Mizuho 2 PLH21 Mizuho 1986 5300t, 130.0x15.5x5.3m, 2d, 18200hp, 23kts, 130p; 1x1-35/90, 1x3-20/76, 2helicopters (Bell 212); 2x JMA3000, JMA8303 radars
PLH22 Yashima 1988
Echigo 3 PLH08 Echigo 1990 3900t, 105.0x15.0x4.9m, 2d, 17950hp, 22kts, 71p; 1x1-35/90, 1x3-20/76, 1 helicopter (Bell 212); JMA1596, JMA1576, helicopter control radars
PLH09 Ryukyu 2000
PLH10 Daisen 2001
Ojika 7 PL02 Erimo 1991 2006(02-04)-2055(05-08)t, 91.4(02-04)-93.5(05-08)x11.0(02-04)-11.5(05-08)x3.5(02-04)-4.0(05-08)m, 2d, 7000hp, 20kts, 38p; 1x1-35/90(03-08), 1x3-20/76, heldeck; 2x JMA1596 radars
PL03 Kudaka 1994
PL04 Yahiko 1995
PL05 Dejima 1998
PL06 Kurikoma 1999
PL07 Satsuma 1999
PL08 Tosa 2000
Shikishima 2 PLH31 Shikishima 1992 9350t, 150.0x17.0x6.0m, 2d, 20800hp, 25kts, 140p; 2x2-35/75, 2x3-20/76, 2x1-12.7, 2 helicopters (Bell 212); OPS-14, JMA1576, JMA1596, JMA3000, JMA8303 radars, 2x e/o directors
PLH32 Akitsushima 2013
Kojima 1 PL21 Kojima 1993 3136t, 115.2x14.0x3.5m, 2d, 8000hp, 18kts, 44+40p; 1x1-35/90, 1x3-20/76, 1x1-12.7, heldeck; 2x JMA1596 radars
Izu 1 PL31 Izu 1997 3768t, 110.4x15.0x5.3m, 2d, 12000hp, 20kts, 40+30p; 1x3-20/76, heldeck; 2x JMA radars
Miura 1 PL22 Miura 1998 3167t, 115.2x14.0x4.8m, 2d, 8000hp, 18kts, 40+150p; 1x3-20/76, heldeck; 3x JMA radars
Hida 3 PL51 Hida 2006 2000t, 95.0x12.6x4.0m, 4d(4wj), 30kts; 1x1-40/60, 1x3-20/76, heldeck; 2x JMA radars, e/o
PL52 Akashi 2006
PL53 Kiso 2008
WPS Takatori 1 PM94 Kumano 1979 631t, 46.5x9.2x3.9m, 2d, 3000hp, 15.7kts, 34p; JMA1596, JMA1576 radars
Teshio 14 PM02 Kitakami 1980 670(02,04,05,07-11,13,14)-692(12)t, 67.8x7.9x2.7m, 2d, 3000hp, 18kts, 33p; 1x3-20/76; 2x JMA159B radars
PM04 Tokachi 1981
PM05 Hitachi 1981
PM07 Isazu 1982
PM08 Chitose 1982
PM09 Mabechi 1983
PM10 Sorachi 1984
PM11 Yubari 1985
PM12 Motoura 1986
PM13 Kurose 1986
PM14 Takatori 1988
Nojima 1 PL01 Oki 1989 1500t, 87.0x10.5x3.5m, 2d, 7000hp, 20kts, 39p; 1x3-20/76, heldeck; 2x JMA1596 radars
Teshio 1 PM15 Teshio 1995 883t, 54.9x10.6x3.3m, 2d, 3600hp, 14.5kts, 35p; 1x3-20/76; 2x JMA radars
Aso 3 PL41 Aso 2005 1000t, 79.0x10.0x4.0m, 4d(4wj), 30kts; 1x1-40/60; 2x JMA radars
PL42 Dewa 2006
PL43 Hakusan 2006
Hateruma 9 PL61 Hateruma 2008 1350t, 89.0x11.0x4.0m, 4d(2wj), 30kts, 30p; 1x1-30/80, heldeck; 2x JMA radars, e/o
PL62 Ishigaki 2009
PL63 Kunigami 2009
PL64 Shimokita 2009
PL65 Shiretoko 2009
PL66 Shikine 2009
PL67 Amagi 2010
PL68 Suzuka 2010
PL69 Koshiki 2010
Kunigami 16 PL09 Kunisaki 2012 1700t, 96.6x11.5x5.2m, 2d, 23kts, 42p; 1x3-20/76, heldeck; 2x JMA radars, e/o
PL10 Buko 2012
PL11 Rishiri 2016
PL12 Esan 2016
PL13 Motobu 2016
PL14 Yonakuni 2016
PL81 Taketomi 2014
PL82 Nagura 2014
PL83 Kabira 2014
PL84 Zanpa 2015
PL85 Tarama 2015
PL86 Ikema 2015
PL87 Irabu 2015
PL88 Tokashiki 2016
PL89 Aguni 2016
PL90 Izena 2016
Iwami 6 PL71 Iwami 2013 no picture 1250t, 92.0x11.0x5.0m, 2d, 8000hp, 21kts, 30p; 1x1-30/80; 2x JMA radars, e/o, FLIR e/o
PL72 Rebun 2014
PL73 Kii 2014
PL74 Matsushima 2014
PL75 Wakasa 2015
PL76 Sado 2015
Katori 1 PM51 Katori 2016 no picture 650t, 72.0x10.0xm, 2d(2wj), 25kts; 1x3-20/76; 2x JMA radars, e/o
WPC Amami 4 PM95 Amami 1992 350t, 56.0x7.5x2.0m, 2d, 7000hp, 25kts, 30p; 1x3-20/76; 2x radars
PM96 Kurokami 1995
PM97 Ishikari 1998
PM98 Horobetsu 1998
Matsunami 1 PC01 Matsunami 1995 no picture 204t, 38.0x8.0x2.0m, 2d(2wj), 5300hp, 25kts, 30p; radar
Tokara 20 PM21 Tokara 2003 350t, 56.0x8.5x3.0m, 3d(3wj), 15000hp, 30kts, 20p; 1x3-20/76, 1x1-12.7; radar
PM22 Fukue 2003
PM23 Oirase 2004
PM24 Fuji 2008
PM25 Echizen 2008
PM26 Kikuchi 2009
PM27 Yoshino 2009
PM28 Isuzu 2009
PM29 Yamakuni 2009
PM30 Kano 2009
PM31 Abakuma 2010
PM32 Minabe 2010
PM33 Matsuura 2010
PM34 Chikugo 2010
PM35 Miyako 2011
PM36 Okitsu 2011
PM37 Kunashiri 2012
PM38 Oomi 2012
PM39 Okushiri 2013
PM40 Matsui 2013
Tsurugi 6 PS201 Tsurugi 2001 220t, 50.0x8.0x4.0m, 3d(3wj), 15000hp, 40kts; 1x3-20/76; 2x radars, e/o
PS202 Hotaka 2001
PS203 Norikura 2001
PS204 Kaimon 2004
PS205 Asama 2004
PS206 Houou 2005
WPB Akizuki 2 PC81 Tamanami 1981 no picture 77t, 26.0x6.3x1.1m, 3d, 3000hp, 22kts, 10p; 1x1-12.7; FRA Mk 2 radar
PC82 Awagiri 1983
Murakumo 4 PC216 Iseyuki 1981 no picture 125t, 31.0x6.3x1.7m, 2d, 4800hp, 31kts, 11p; 1x1-12.7; radar
PC220 Hamayuki 1982
PC222 Umigiri 1983
PC223 Asagiri 1983
Mihashi 4 PS01 Shinzan 1988 no picture 200t, 43.0x7.5x1.7m, 3d(2+1wj), 8800hp, 34kts, 13p; 1x3-20/76; Furuno radar, e/o director
PS02 Saroma 1989
PS03 Inasa 1990
PS04 Kirishima 1991
Shimagiri 3 PC83 Shimagiri 1985 no picture 50t, 23.0x5.3x1.9m, 3d, 3000hp, 30kts, 10p; 1x1-20/70(85), 1x1-12.7(83,84); FRA 10 Mk 2 radar
PC84 Okinami 1985
PC85 Hayagiri 1985
Isokaze 2 CL03 Nadakaze 1991 no picture 21t, 17.0x4.3x1.0m, 2d, 1400hp, 29kts, 6p; radar
CL04 Kotokaze 1991
Takatsuki 2 PS108 Takatsuki 1992 no picture 180t, 35.0x6.7x1.2m, 2d(2wj), 5200hp, 35kts, 10p; 1x1-12.7; radar, e/o
PS109 Katsuragi 1993
Kamui 15 PS05 Kamui 1994 no picture 197t, 46.0x7.5x1.7m, 3d(2+1wj), 8800hp, 35kts, 13p; 1x3-20/76; Furuno radar, e/o
PS06 Raizan 1994
PS07 Ashitaki 1994
PS08 Kariba 1995
PS09 Arase 1997
PS10 Sanbe 1997
PS11 Mizuki 2000
PS12 Koya 2004
PS13 Tsukuba 2009
PS14 Akagi 2009
PS15 Bizan 2011
PS16 Nobaru 2011
PS17 Takachiho 2011
PS18 Sanrei 2012
PS19 Asaji 2012
Natsugiri 2 PC86 Natsugiri 1990 no picture 70t, 27.0x5.6x1.2m, 2d, 3000hp, 27.5kts, 9p; radar
PC87 Suganami 1990
Suzukaze 168 CL01 Satsukaze 2016 no picture 23t, 20.0x4.2x1.0m, 2d, 1820hp, 30kts, 5p; 1x1-12.7; radar
CL02 Rindou 2016
CL05 Himehikari 2000
CL06 Matsuhikari 2000
CL07 Hayagiku 2000
CL08 Yodogiku 2001
CL09 Tobiume 2002
CL11 Himegiku 1992
CL12 Asakaze 1992
CL13 Hamegiku 1992
CL14 Fujikaze 1992
CL15 Miyakaze 1992
CL16 Hibakaze 1992
CL17 Satakaze 1992
CL18 Tomakaze 1993
CL19 Yurikaze 1993
CL20 Fusakaze 1993
CL21 Umekaze 1993
CL22 Shigikaze 1993
CL23 Uzukaze 1993
CL24 Akikaze 1993
CL25 Himetsubaki 1993
CL26 Mojikaze 1993
CL27 Sodekaze 1993
CL28 Kinukaze 1993
CL29 Mayakaze 1993
CL30 Setokaze 1993
CL31 Makikaze 1993
CL32 Himekaze 1993
CL33 Kugakaze 1993
CL34 Kamikaze 1994
CL35 Umikaze 1994
CL36 Kirikaze 1994
CL37 Hakaze 1994
CL38 Shachikaze 1994
CL39 Isekaze 1994
CL40 Nijikaze 1994
CL41 Kishikaze 1994
CL42 Kikukaze 1994
CL43 Otokaze 1994
CL44 Hirokaze 1994
CL45 Ashikaze 1994
CL46 Toyokaze 1994
CL47 Satsukaze 1994
CL48 Shiokaze 1994
CL49 Awakaze 1994
CL50 Hamakaze 1994
CL51 Miyagiku 1994
CL52 Tomokaze 1994
CL53 Kubikaze 1994
CL54 Nachikaze 1994
CL55 Mitsukaze 1994
CL56 Hatakaze 1994
CL57 Sekikaze 1994
CL58 Terukaze 1995
CL59 Shimakaze 1995
CL60 Sasakaze 1995
CL61 Kiikaze 1995
CL62 Ikikaze 1995
CL63 Minekaze 1995
CL64 Torikaze 1995
CL65 Amakaze 1995
CL66 Aokaze 1995
CL67 Kunikaze 1995
CL68 Tachikaze 1995
CL69 Niikaze 1995
CL70 Hinagiku 1995
CL71 Karatachi 1995
CL72 Kijikaze 1996
CL73 Hatsukaze 1996
CL74 Yurakaze 1996
CL75 Mutsugiku 1996
CL76 Kitakaze 1996
CL77 Mutsukaze 1996
CL78 Tonekaze 1996
CL79 Shizukaze 1996
CL80 Hatsugiku 1996
CL81 Yukikaze 1996
CL82 Nakakaze 1996
CL83 Kawakaze 1996
CL84 Kiyokaze 1996
CL85 Hamagiku 1996
CL86 Osakaze 1996
CL87 Wakakaze 1996
CL88 Ikekaze 1996
CL89 Nomokaze 1996
CL90 Yumikaze 1996
CL91 Kumakaze 1996
CL92 Harukaze 1996
CL93 Sarubia 1996
CL94 Oitsukaze 1997
CL95 Kochikaze 1997
CL96 Hamanasu 1997
CL97 Akashia 1997
CL98 Tosamizuki 1997
CL99 Mokuren 1997
CL100 Sachikaze 1997
CL101 Ogikaze 1997
CL102 Natsukaze 1997
CL103 Sawakaze 1999
CL104 Benibana 1999
CL105 Yamazakura 1999
CL106 Kaido 1999
CL107 Sazanka 1999
CL108 Aoi 1999
CL109 Nogekaze 1999
CL110 Yaezakura 1999
CL111 Yanakaze 1999
CL112 Yukitsubaki 1999
CL113 Sagikaze 1999
CL114 Getto 2000
CL115 Imakaze 2001
CL116 Miekaze 2001
CL117 Tosatsubaki 2001
CL118 Katsukaze 2001
CL119 Satsuke 2001
CL120 Yaguruma 2002
CL121 Murokaze 2002
CL122 Fuyo 2002
CL123 Tsubaki 2002
CL124 Higokaze 2002
CL125 Shirahagi 2002
CL126 Ashibi 2002
CL127 Suiren 2002
CL128 Kobai 2002
CL129 Yamayuri 2002
CL130 Kurikaze 2002
CL131 Sorakaze 2002
CL132 Murakaze 2002
CL133 Aikaze 2002
CL134 Ayame 2002
CL135 Isogiku 2007
CL136 Yamabuki 2007
CL137 Miokaze 2007
CL138 Komokaze 2007
CL139 Tokikusa 2007
CL140 Hidakaze 2007
CL141 Shiragiku 2007
CL142 Himezakura 2007
CL143 Suzukaze 2008
CL144 Sugikaze 2008
CL145 Satozakura 2008
CL146 Hikokaze 2008
CL147 Suizen 2008
CL148 Mihogiku 2008
CL149 Kochikaze 2008
CL150 Washikaze 2008
CL151 Rurikaze 2009
CL152 Okeyuri 2009
CL153 Diego 2009
CL154 Adan 2009
CL155 Yuna 2009
CL156 Shirokaze 2009
CL157 Hokokaze 2009
CL158 Sakurakaze 2009
CL159 Mihokaze 2009
CL160 Isegiku 2009
CL161 Kurekaze 2009
CL162 Iyozakura 2009
CL163 Matsukaze 2009
CL164 Tamakaze 2010
CL165 Terugiku 2010
CL166 Kozaura 2011
CL167 Ezokaze 2011
CL168 Yamagiku 2011
CL169 Kotozakura 2011
CL170 Suzuran 2011
CL171 Chiyokaze 2011
Hayanami 11 PC11 Hayanami 1993 no picture 190t, 35.0x6.3x2.3m, 2d, 4000hp, 25kts, 13p; 1x1-12.7; radar
PC12 Setogiri 1994
PC13 Mizunami 1994
PC14 Ionami 1994
PC15 Kurinami 1995
PC16 Hamanami 1996
PC17 Shinonome 1996
PC18 Harunami 1996
PC19 Kiyozuki 1996
PC20 Ayanami 1996
PC21 Tokinami 1996
Asogiri 4 PC101 Asogiri 1994 no picture 100t, 33.0x6.3x1.4m, 2d, 5200hp, 30kts, 10p; 1x1-12.7; radar, e/o
PC102 Murozuki 1995
PC103 Urazuki 1996
PC104 Kagayuki 1997
Hamagumo 4 PC22 Hamagumo 1999 no picture 190t, 35.0x6.3x2.3m, 2d, 4000hp, 24kts, 13p; 1x1-12.7; radar
PC23 Ayuzuki 1999
PC24 Yufugiri 2000
PC25 Tomonami 2000
Kagayuki 20 PC105 Hayagumo 1999 no picture 100t, 32.0x6.5x2.0m, 2d(2wj), 5200hp, 30kts, 10p; 1x3-20/76(108-124), 1x1-12.7(105-107); radar, e/o
PC106 Murakumo 2002
PC107 Izunami 2003
PC108 Yaegumo 2008
PC109 Natsugumo 2008
PC110 Akigumo 2008
PC111 Haginami 2009
PC112 Ikigumo 2009
PC113 Natsuzuki 2009
PC114 Okigumo 2009
PC115 Awagumo 2009
PC116 Shimagumo 2009
PC117 Yukigumo 2011
PC118 Kitagumo 2011
PC119 Komayuki 2011
PC120 Kawagiri 2012
PC121 Wakazuki 2012
PC122 Isonami 2014
PC123 Nagozuki 2014
PC124 Yaezuki 2014
Yodo 10 PC51 Yodo 2002 no picture 190t, 37.0x6.7x1.5m, 2d, 5200hp, 25kts; radar, e/o
PC52 Kotobiki 2003
PC53 Ryuo 2003
PC54 Nunobiki 2003
PC55 Fudo 2013
PC56 Ryusei 2013
PC57 Takataki 2013
PC58 Aotaki 2013
PC59 Nachi 2013
PC60 Minoo 2013
Kotonami 8 PC31 Kotonami 2012 no picture 64t, 27.0x5.6x2.8m, 2d, 25kts; radar
PC32 Hatagumo 2012
PC33 Urayuki 2014
PC34 Yuzuki 2014
PC35 Isozuki 2014
PC36 Tobagiri 2014
PC37 Shimanami 2014
PC38 Minegumo 2014
Shimoji 1 PS31 Shimoji 2016 no picture 200t, 43.0x7.8xm, 2d(2wj), 25kts; 1x3-20/76; 2x radars, e/o

MARITIME SAFETY AGENCY AUXILIARIES

AGS Shoyo 1 HL01 Shoyo 1998 3128t, 98.0x15.2x3.6m, 2d, 4200hp, 17kts, 60p
Takuyo 1 HL02 Takuyo 1983 no picture 3370t, 96.0x14.2x4.5m, 2d, 5200hp, 18kts, 64p
Meiyo 2 HL03 Meiyo 1990 no picture 1076t, 60.0x10.5x3.4m, 2d, 2200hp, 15kts, 38p
HL05 Kaiyo 1993
Tenyo 1 HL04 Tenyo 1986 no picture 770t, 56.0x9.8x2.9m, 2d, 1300hp, 13kts, 43p; 2x JMA 1596 radars
YTR Hiryu 1 FL01 Hiryu 1997 no picture 322t, 35.1x12.2x5.5m, 2d, 4000hp, 14kts, 15p

AIRCRAFT

NAVY

Ship-based

 37 SH-60J Seahawk, 48 SH-60K Seahawk, 2 MH-53E Sea Dragon, 8 MCH-101, 2 CH-101, 15 TH-135

Land-based combat capable

 9 P-1, 66 P-3C Orion, 5 EP-3C Orion

ARMY

Land-based combat capable

12 AH-64D Apache, 59 AH-1S Cobra, 33 OH-1, 44 OH-6D

AIR FORCE

Combat capable

201 F-15J Eagle, 92 F-2A/B, 54 F-4EJ Phantom II, 1 EC-1, 2 YS-11EA, 13 RF-4J Phantom II, 4 YS-11EB, 13 E-2C Hawkeye, 4 Boeing E-767 AWACS, 196 T-4

MARITIME SAFETY AGENCY

Ship-based

5 Bell 412 Twin Huey, 5 S-76D, 3 AS-332 Super Puma, 5 H225 Super Puma, 18 AW139, 3 Bell 206B JetRanger II, 6 Bell 212, 3 S-76C
Land-based combat capable 2 Falcon 900MPAT



© Ivan Gogin, 2017
