USA - Naval aviation and armament
Douglas T2D torpedo bomber
T2D-1
| Modification | Purpose | Deliveries | Number of commissioned | Discarding | Differences from the previous modification |
| T2D-1 | torpedo bomber | 5/1927 - 6/1932 | 12 | 1933 | --- |
| Modification |
T2D-1 |
|
Wing span, m |
17.37 |
|
Length, m |
12.80 |
|
Height, m |
4.85 |
|
Wings area, m2 |
82.31 |
|
Empty mass, kg |
2726 |
|
Full flying-off mass, kg |
4773 |
| Engine | 2 Wright R-1750 |
| Power, h. p. | 2 x 525 |
| Maximal speed, km/h | 201 |
| Cruise speed, km/h | 186 |
| Flying range, km | 735 |
| Vertical speed, m/s | |
| Maximal altitude, m | 4215 |
| Complement | 4 |
| Armament | 2 x 7.6 MG, 1 734-kg torpedo or 750 kg of bombs |
P2D-1
T2D-1
