USA - Naval aviation and armament
McDonnel FH Phantom fighter
FH-1 Phantom
| Modification | Purpose | Deliveries | Number of commissioned | Discarding | Differences from the previous modification |
| FH-1 | fighter | 7/1947 - 5/1948 | 61 | 7/1950 | --- |
| Modification |
FH-1 |
|
Wing span, m |
12.42 |
|
Length, m |
11.81 |
|
Height, m |
4.32 |
|
Wings area, m2 |
25.64 |
|
Empty mass, kg |
3030 |
|
Full flying-off mass, kg |
5458 |
| Engine | 2 Westinghouse J30-WE-20 |
|
Force, kgf |
2 x 725 |
| Maximal speed, km/h |
771 |
| Cruise speed, km/h | 399 |
| Flying range, km | 1578 |
| Vertical speed, m/s | 21.5 |
| Maximal altitude, m | 12527 |
| Complement | 1 |
| Armament | 4 12.7-mm MG |
XFD-1 Phantom
FH-1 Phantom
