USA - Naval aviation and armament
DT-2
| Modification | Purpose | Deliveries | Number of commissioned | Discarding | Differences from the previous modification |
| DT-2 | torpedo bomber | 12/1922 - 1924 | 75, mostly on floats | 4/1928 | 2 seats, Liberty engine (450 h. p.) |
| Modification |
DT-2 |
|
Wing span, m |
15.24 |
|
Length, m |
11.47 |
|
Height, m |
4.14 |
|
Wings area, m2 |
65.68 |
|
Empty mass, kg |
1695 |
|
Full flying-off mass, kg |
3308 |
| Engine | 1 Liberty V-12 |
| Power, h. p. | 450 |
| Maximal speed, km/h | 161 |
| Cruise speed, km/h | 141 |
| Flying range, km | 440 |
| Vertical speed, m/s | |
| Maximal altitude, m | 2380 |
| Complement | 2 |
| Armament | 1 830-kg torpedo or 840 kg of bombs |
DT-2
DT-2
