Russia / USSR - naval aviation and armaments
Russia / USSR - naval aviation
Yu-20
| Modification | Purpose | Deliveries | Number of commissioned | Discarding | Differences from the previous modification |
| Þ-20 <Yu-20> (Ju-20) | recon | 1922 - 1923 | 20 | 1930 | --- |
| Modification |
Yu-20 |
|
Wing span, m |
15.35 |
|
Length, m |
8.30 |
|
Height, m |
|
|
Wings area, m2 |
32.00 |
|
Empty mass, kg |
1113 |
|
Full flying-off mass, kg |
1593 |
| Engine | 1 BMW IIIa |
| Power, h. p. | 185 |
| Maximal speed, km/h | 181 |
| Cruise speed, km/h | 158 |
| Flying range, km | 800 |
| Vertical speed, m/s | |
| Maximal altitude, m | 5000 |
| Complement | 2 |
| Armament | 1 x 7.6 MG |
Yu-20
© Ivan Gogin, 2009
