Russia / USSR - naval aviation and armaments
Russia / USSR - naval aviation
Be-4
| Modification | Purpose | Deliveries | Number of commissioned | Discarding | Differences from the previous modification |
| Áå-4 <Be-4> (ex-ÊÎÐ-2 <KOR-2>) | recon | 1942 - 1945 | 44 | 1947 | --- |
| Modification |
Be-4 |
|
Wing span, m |
12.00 |
|
Length, m |
10.50 |
|
Height, m |
4.04 |
|
Wings area, m2 |
25.50 |
|
Empty mass, kg |
2055 |
|
Full flying-off mass, kg |
3468 |
| Engine | 1 M-62 |
| Power, h. p. | 1000 |
| Maximal speed, km/h | 358 |
| Cruise speed, km/h | 322 |
| Flying range, km | 1150 |
| Vertical speed, m/s | 7.0 |
| Maximal altitude, m | 7300 |
| Complement | 2 |
| Armament | 2 x 7.6 ShKAS MG, 200 - 400 kg bombs |
Be-4
