Japan - naval aviation and armaments
Ki.76
| Modification | Purpose | Deliveries | Number of commissioned | Discarding | Differences from the previous modification |
| Ki.76 | ASW | late 1943 - 1945 | no more than 50 | 1945 | --- |
| Modification | Ki.76 |
|
Wing span, m |
15.00 |
|
Length, m |
9.56 |
|
Height, m |
2.90 |
|
Wings area, m2 |
29.40 |
|
Empty mass, kg |
1110 |
|
Full flying-off mass, kg |
1620 |
| Engine | 1 Hitachi Ha.42 |
| Power, h. p. | 310 |
| Maximal speed, km/h | 178 |
| Cruise speed, km/h | 156 |
| Flying range, km | 750 |
| Vertical speed, m/s | |
| Maximal altitude, m | 5630 |
| Complement | 2 |
| Armament | 1 x 7.7 89-shiki MG, 120 kg of bombs (2 x 60-kg DC) |
Ki.76
© Ivan Gogin, 2008
