Japan - naval aviation and armaments
E8N2
| Modification | Purpose | Deliveries | Number of commissioned | Discarding | Differences from the previous modification |
| E8N1 | recon | 10/1935 - 1939 | 755 | 1945 | 2 seats, Nakajima Kotobuki 2 KAI 1 engine (580 hp), 2 MG, 60 kg of bombs |
| E8N2 | 1938 - early 1940 | Kotobuki 2 KAI 2 engine (630 hp) |
| Modification | E8N2 |
|
Wing span, m |
10.98 |
|
Length, m |
8.81 |
|
Height, m |
3.84 |
|
Wings area, m2 |
26.50 |
|
Empty mass, kg |
1320 |
|
Full flying-off mass, kg |
1900 |
| Engine | 1 Nakajima Kotobuki 2 KAI 2 |
| Power, h. p. | 630 |
| Maximal speed, km/h | 300 |
| Cruise speed, km/h | 185 |
| Flying range, km | 900 |
| Vertical speed, m/s | 7.7 |
| Maximal altitude, m | 7270 |
| Complement | 2 |
| Armament | 2 x 7.7-mm 92-shiki MG, 60 kg of bombs (2 x 30-kg) |
E8N2
© Ivan Gogin, 2008
