Japan - naval aviation and armaments
D1A2
| Modification | Purpose | Deliveries | Number of commissioned | Discarding | Differences from the previous modification |
| D1A1 | diving bomber | 1934 - 1937 | 163 | 1941 | 2 seats, 118 planes with Nakajima Kotobuki 2 KAI1 engine (580 hp), 44 with Kotobuki 3 (580 hp), 3 MG, 310 kg of bombs, 280 km/h |
| D1A2 | 1936 - 1940 | 428 | 1941 | Nakajima Hikari 1 engine (730 hp) |
| Modification |
D1A2 |
|
Wing span, m |
11.40 |
|
Length, m |
9.30 |
|
Height, m |
3.41 |
|
Wings area, m2 |
34.70 |
|
Empty mass, kg |
1516 |
|
Full flying-off mass, kg |
2610 |
| Engine | 1 Nakajima Hikari 1 |
| Power, h. p. | 730 |
| Maximal speed, km/h | 309 |
| Cruise speed, km/h | 222 |
| Flying range, km | 927 |
| Vertical speed, m/s | 6.4 |
| Maximal altitude, m | 6980 |
| Complement | 2 |
| Armament | 3 x 7.7 92-shiki MG, 310 kg of bombs (1 x 250-kg + 2 x 30-kg) |
D1A2
D1A2
