Italy - naval aviation and armaments
Ca.314B
| Modification | Purpose | Deliveries | Number of commissioned | Discarding | Differences from the previous modification |
| Ca.316 | recon | 1941 | 14 | 1941 | --- |
| Modification |
Ca.316 |
|
Wing span, m |
15.87 |
|
Length, m |
12.89 |
|
Height, m |
5.11 |
|
Wings area, m2 |
38.00 |
|
Empty mass, kg |
4000 |
|
Full flying-off mass, kg |
4804 |
| Engine | 2 Piaggio P.VII |
| Power, h. p. | 2 x 460 |
| Maximal speed, km/h | 328 |
| Cruise speed, km/h | 260 |
| Flying range, km | 1600 |
| Vertical speed, m/s | |
| Maximal altitude, m | 6000 |
| Complement | 3 |
| Armament | 1 x 7.7 Breda-SAFAT MG, 400 kg of bombs |
Ca.314
