France - naval aviation and armaments
H.43
| Modification | Purpose | Deliveries | Number of commissioned | Discarding | Differences from the previous modification |
| H.43 | recon | 2/1940 - 5/1940 | 20 | 8/1940 | --- |
| Modification |
H.43 |
|
Wing span, m |
16.00 |
|
Length, m |
11.00 |
|
Height, m |
3.85 |
|
Wings area, m2 |
36.00 |
|
Empty mass, kg |
1760 |
|
Full flying-off mass, kg |
3375 |
| Engine | 1 Hispano-Suiza 9Vb |
| Power, h. p. | 650 |
| Maximal speed, km/h | 222 |
| Cruise speed, km/h | 187 |
| Flying range, km | 850 |
| Vertical speed, m/s | |
| Maximal altitude, m | 6200 |
| Complement | 3 |
| Armament | 2 x 7.5 MG, 150 kg bombs |
H.43
